Tascam SERIES 102i USB Audio/MIDI Interface, 10 Inputs and 2 Outputs

SKU: TSSER102I MFR: SERIES 102I
Earn VIP Reward Points

Key Features

  • Record pristine audio with this Tascam interface's high-quality mic preamps.
  • Achieve ultra-low latency for seamless tracking and overdubbing using this interface.
  • Connect mics, guitars, and more with versatile inputs on this audio interface.
  • Enjoy stable driver performance for uninterrupted recording sessions on Mac & PC.
  • Capture every detail with high-resolution 192kHz audio on this USB interface.
  • Easily integrate MIDI keyboards and controllers via the MIDI interface ports.
See More Product Details
Pre Order Now?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$29.99

2 Year

$49.99

3 Year

$59.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Tascam SERIES 102i Specifications

Sampling Frequency

Sampling Frequency

Jump to...
  • Sampling Frequency

    44.1k/48k/88.2k/96k/176.4k/192k Hz

Quantization Bit Rate

Jump to...
  • Quantization Bit Rate

    16/24-bit

Analog Audio Inputs: MIC IN

Jump to...
  • MIC IN (Balanced)

    1-2 (when the input switch is set to MIC/LINE)

  • Connector

    XLR-3-31 equivalent (1: GND, 2: HOT, 3: COLD)

  • Input Impedance

    1.5kOhms

  • Nominal Input Level

    GAIN: MAX: -64dBu (0.0005Vrms)
    GAIN: MIN: -6dBu (0.388Vrms)

  • Maximum Input Level

    +10dBu (2.45Vrms)

  • Gain Range

    58dB

Analog Audio Inputs: Instrument IN

Jump to...
  • INSTRUMENT IN (Unbalanced)

    1-2 (when the input switch is set to INST)

  • Connector

    1/4" (6.3mm) TS jack (Tip: HOT, Sleeve: GND)

  • Input Impedance

    1MOhms or more

  • Nominal Input Level

    GAIN: MAX: -64dBV (0.0006Vrms)
    GAIN: MIN: -6dBV (0.501Vrms)

  • Maximum Input Level

    +10dBV (3.162Vrms)

  • Gain Range

    58dB

Analog Audio Inputs: Line IN

Jump to...
  • LINE IN (Unbalanced)

    1-2 (when the input switch is set to MIC/LINE)

  • Connector

    1/4" (6.3mm) TRS jack (Tip: HOT, Ring: COLD, Sleeve: GND)

  • Input Impedance

    10kOhms

  • Nominal Input Level

    GAIN: MAX: -54dBu (0.0015Vrms)
    GAIN: MIN: +4dBu (1.228Vrms)

  • Maximum Input Level

    +24dBu (12.282Vrms)

  • Gain Range

    58dB

Digital Audio Inputs

Jump to...
  • OPTICAL IN (S/MUX)

    Connector: OPTICAL (JEITA RC-5720C)
    Signal Format: Multi-channel Optical Format (Supports S/MUX at 88.2k/96k/176.4k/192kHz)

Analog Audio Outputs: Monitor Out

Jump to...
  • MONITOR OUT (Balanced)

    LINE OUT 1-2

  • Connector

    1/4" (6.3mm) TRS jack (Tip: HOT, Ring: COLD, Sleeve: GND)

  • Output Impedance

    230 Ohms

  • Nominal Output Level

    +4dBu (1.228Vrms)

  • Maximum Output Level

    +20dBu (7.75Vrms)

Analog Audio Outputs: Headphone Out

Jump to...
  • HEADPHONE OUT

    PHONES 1-2

  • Connector

    1/4" (6.3mm) Stereo jack

  • Maximum Output Power

    18mW + 18mW (THD+N 0.1% or less, into 32O load)

Control Input/Output

Jump to...
  • USB

    Connector: 4-pin, USB B type
    Format: USB 2.0 HIGH SPEED (480Mbps)

  • MIDI IN

    Connector: 5-pin, DIN
    Format: Standard MIDI

  • MIDI OUT

    Connector: 5-pin, DIN
    Format: Standard MIDI

Mic Amp EIN

Jump to...
  • Mic Amp EIN

    -129dBu or lower

Frequency Response

Jump to...
  • Frequency Response

    Fs 44.1k/48kHz: 20Hz to 20kHz, +0/-1dB (MIC/LINE thru LINE OUT, JEITA)
    Fs 88.2k/96kHz: 20Hz to 40kHz, +0/-2dB (MIC/LINE thru LINE OUT, JEITA)
    Fs 176.4k/192kHz: 20Hz to 80kHz, +0/-12dB (MIC/LINE thru LINE OUT, JEITA)

Total Harmonic Distortion

Jump to...
  • Total Harmonic Distortion

    0.005% or less (MIC/LINE thru LINE OUT, 1kHz sine wave, full-scale -2dB input level, MONITOR knob at maximum)

Signal-to-Noise Ratio

Jump to...
  • Signal-to-Noise Ratio

    106dB or higher (MIC/LINE IN thru LINE OUT, Gain knob at minimum, JEITA)

Crosstalk

Jump to...
  • Crosstalk

    100dB or higher (MIC/LINE IN thru LINE OUT, 1kHz sine wave, Gain knob at minimum)

Computer System Requirements

Jump to...
  • Windows

    Compatible: Computers Windows computer with a USB 2.0 or USB 3.0
    CPU: Dual core (x86), 2GHz or faster
    Memory: 2GB or more
    Driver: USB Audio Class2.0, ASIO2.2, SERIES 102i, WDM (MME), MIDI

  • Macintosh

    Compatible: Computers Macintosh computer with a USB 2.0 or USB 3.0
    CPU: Dual core, 2GHz or faster
    Memory: 2GB or more
    Driver: Core Audio, Core MIDI

  • iOS

    Driver: Core Audio for iOS

Supported OS

Jump to...
  • Supported OS

    Windows: Windows 10 (October 2018 Update) , Windows 10 (April 2018 Update) , Windows 8.1 , Windows 7
    Mac: macOS Mojave , macOS (10.13) , macOS Sierra (10.12)
    iOS: iOS 12 , iOS 11 , iOS 10

General

Jump to...
  • Power

    DC 12V (AC Adapter PS-P1220E included)

  • Power Consumption

    7.2 W

  • Operating Temperature Range

    41 to 95 deg. F (5 to 35 deg. C)

  • Dimensions (WxHxD)

    7.32 x 2.56 x 6.30" (185.93 x 65.02 x 160.02mm)

  • Weight

    2.43 lbs (1.10kg)

  • UPC Code

    043774034000

2 Accessories for Tascam SERIES 102i USB Audio/MIDI Interface, 10 Inputs and 2 Outputs

  • All Accessories (2)
  • Microphones (2)

About Tascam SERIES 102i

Tascam SERIES 102i Audio Interface

It all starts with the best sound: TEAC and TASCAM have more than 60 years of high grade audio design experience.
TASCAM Ultra-HDDA (High Definition Discrete Amplifier) mic preamp circuitry guarantees transparent natural tone with ultra-low noise. A new-generation TASCAM audio interface engine delivers high-definition, 24-bit/192 kHz recording and solid stability.

TASCAM SERIES audio interfaces feature a large, easy-to-grab Monitor control knob that ensures you can quickly adjust the monitor output level. Their angled tabletop design offers easy access to all front-panel controls. A handy Monitor Balance control enables mixing live input with computer playback for zero-latency monitoring. Each analog input channel is served by an individually switched +48 volt phantom power supply for condenser microphones.

TASCAM SERIES audio interfaces

Features at a Glance

  • Two XLR/TRS combo mic/line/instrument inputs
  • Two transparent, natural-sounding, ultra-low noise TASCAM Ultra-HDDA mic preamplifiers
  • One optical S/MUX expansion port that accepts up to 8 channels of audio input (10 total inputs)
  • 2 ¼-inch analog outputs and dual headphone outputs for versatile monitoring
  • Built-in effects: reverb, compressor, 4-band EQ
  • Flexible DSP input/output mixer controlled via free TASCAM Control software
  • Software control of faders, routing, effects, and phase invert
  • Up to 24-bit/192 kHz sample resolution
  • Includes Steinberg DAW software and IK Multimedia world-class guitar effects/modeling and mastering software
  • MIDI interface
  • Dual headphone outputs
  • USB 2.0 connection and custom USB driver with high stability
TASCAM SERIES audio interface

Start Making Music Immediately with Bundled Software

TASCAM SERIES audio interfaces are bundled with world-class software. Record with Steinberg Cubase LE DAW for Windows and Mac computers and Steinberg Cubasis LE DAW for iPad. Then process your audio with IK Multimedia AmpliTube guitar/bass modeling and effects software. Finish your high-quality, polished recording projects with IK Multimedia T-RackS mastering software. Both free standing and plug-in versions of AmpliTube and T-RackS are included.

Steinberg Cubase LE DAW for Windows and Mac computers

The new Tascam SERIES audio interface family provides professional quality
Expandability, both internal and bundled effects processing, internal mixing, external software control and more for studio, home and live recording. With a new look, including an angled tabletop design and large, easy-to-grab knobs, Tascam sets a new standard for mid-grade audio interfaces.

Supreme Audio Fidelity
It all starts with the best sound: TEAC and Tascam have more than 60 years of high grade audio design experience. Tascam Ultra-HDDA (High Definition Discrete Amplifier) mic preamp circuitry guarantees transparent natural tone with ultra-low noise.

24-bit/192 kHz
A new-generation Tascam audio interface engine delivers high-definition, 24-bit/192 kHz recording and solid stability.

Expandable input capability to grow into
Easily add more input channels to accommodate future growth by using external microphone preamplifiers with S/MUX optical inputs to record drums, guitars, keyboards, vocals and more. Each S/MUX optical port can accept up to 8 channels of audio input from an ADAT- or S/MUX-compatible device.

Well-designed interface for quick production
Tascam SERIES audio interfaces feature a large, easy-to-grab Monitor control knob that ensures you can quickly adjust the monitor output level. Their angled tabletop design offers easy access to all front-panel controls. A handy Monitor Balance control enables mixing live input with computer playback for zero-latency monitoring. Each analog input channel is served by an individually switched +48 volt phantom power supply for condenser microphones.

Dual headphone monitoring
The SERIES interface has 2 individual headphone amplifiers which offer powerful enough dual headphone monitoring.

Control Software for Matrix Mixing, Effects Processors and More
Free, easy-to-use Tascam Control software manages faders, processing and the ability to route any audio input (analog, optical and USB) to any audio output.

Built-in DSP Effects and Processing
A DSP input and output mixer is complemented with digital reverb, compressor, phase invert and 4-band EQ for each channel. Having these processors included internally eliminates all latency issues and takes the load off the computer allowing the PC/Mac to process the audio more efficiently.

Mobility
Tascam SERIES interfaces support tablets and other mobile devices and are compatible with many applications to meet your recording needs now and in the future.

Start Making Music Immediately with Bundled Software
Tascam SERIES audio interfaces are bundled with world-class software. Record with Steinberg Cubase LE DAW for Windows and Mac computers and Steinberg Cubasis LE DAW for iPad. Then process your audio with IK Multimedia AmpliTube guitar/bass modeling and effects software. Finish your high-quality, polished recording projects with IK Multimedia T-RackS mastering software. Both free standing and plug-in versions of AmpliTube and T-RackS are included.

Tascam house made genuine audio driver and app
A new USB driver offers very high stability, ensuring highly reliable performance every time.

Routing facility for flexible usage
Allows any input like analogue, OPTICAL and USB audio to assign any output port(s) as the user wants.

SERIES 8p Dyna
8 channel mic preamplifier with analog compressor.

Tascam SERIES 102i Features

  • Two XLR/TRS combo mic/line/instrument inputs
  • Two transparent, natural-sounding, ultra-low noise Tascam Ultra-HDDA mic preamplifiers
  • One optical S/MUX expansion port that accepts up to 8 channels of audio input (10 total inputs)
  • 2 1/4" analog outputs and dual headphone outputs for versatile monitoring
  • Built-in effects: reverb, compressor, 4-band EQ
  • Flexible DSP input/output mixer controlled via free TASCAM Control software
  • Software control of faders, routing, effects and phase invert
  • Up to 24-bit/192 kHz sample resolution
  • Includes Steinberg DAW software and IK Multimedia world-class guitar effects/modeling and mastering software
  • MIDI interface
  • Dual headphone outputs
  • Compatible with Windows / Mac computers and iOS devices (supports UAC2.0)
  • USB 2.0 connection and custom USB driver with high stability
  • Easy-to-understand operation
  • Automatic update function available for software/driver/firmware updates
  • Information window function(shown in the Settings Panel screen)
  • Direct monitor option for low latency monitoring
  • Compatible with mainstream DAW software (Pro Tools, Live, Cubase, Studio One, GarageBand)

Product Documents

User Manual

Key Features

  • Record pristine audio with this Tascam interface's high-quality mic preamps.
  • Achieve ultra-low latency for seamless tracking and overdubbing using this interface.
  • Connect mics, guitars, and more with versatile inputs on this audio interface.
  • Enjoy stable driver performance for uninterrupted recording sessions on Mac & PC.
  • Capture every detail with high-resolution 192kHz audio on this USB interface.
  • Easily integrate MIDI keyboards and controllers via the MIDI interface ports.

What's in the box:

  • Tascam SERIES 102i USB Audio/MIDI Interface
  • Tascam 1 Year Parts and 90 Day Labor Limited Warranty
