Tascam US-20X20 Specifications
USB2.0
44.1k/48k/88.2k/96kHz
USB3.0
44.1k/48k/88.2k/96k/176.4k/192kHz
Quantization bit rate
16/24bit
Analog audio inputs (Front)
Mic In (Balanced): IN 1-8
Connector: XLR-3-31(1:GND, 2:HOT, 3:COLD)
Input impedance: 2.4kOhms
Gain Max: -68dBu (0.0003Vrms)
Gain Min: -12dBu (0.195Vrms)
Maximum input level: +8dBu (1.947Vrms)
Gain: 56dBAnalog audio inputs (Front) 1
Inst In (Unbalanced): IN 1-2
Connector: 6.3mm(1/4") TS-jack(T:HOT, S:GND) (When set to "INST" at LINE/INST switch)
Input impedance: 1MOhms or more
Gain Max: -68dBV (0.0004Vrms)
Gain Min: -12dBV (0.251Vrms)
Maximum input level: +8dBV (0.2512Vrms)
Gain: 56dB
Line In (Balanced): IN 3-8
Connector: 6.3mm(1/4") TRS-jack(T:HOT, R:COLD, S:GND)
Input impedance: 10kOhms
Gain: Min: +4dBu (1.228Vrms)
Maximum input level: +24dBu (12.282Vrms)
Gain: 56dBAnalog audio inputs (Rear)
Line In (Unbalanced): IN 9-10
Connector: 6.3mm(1/4") TS-jack(T:HOT, S:GND) (When set to "-10dBV" at LEVEL switch)
Input impedance: 10kOhms or more
Nominal input level: -10dBV (0.3162Vrms)
Maximum input level: +10dBV (3.162Vrms)
Line In (Balanced): IN 9-10
Connector: 6.3mm(1/4") TRS-jack(T:HOT, R:COLD, S:GND) (When set to "+4dBu" at LEVEL switch)
Input impedance: 10kOhms
Nominal input level: +4dBu (1.228Vrms)
Maximum input level: +24dBu (12.1282Vrms)Digital audio inputs
Coaxial Connector: RCA pin jack
Format: IEC60958-3(S/PDIF)
Input impedance: 75Ohm
Input level: 0.5Vp-p / 75Ohm
Optical (S/MUX) Connector: OPTICAL (JEITA RC-5720C)
Optical (S/MUX) Format: Multi-channel optical format (S/MUX4 is available in 88.2k/96k/176.4k/192kHzAnalog audio outputs
Line Out (Balanced): OUT 1-10
Connector: 6.3mm(1/4") TRS-jack(T:HOT, R:COLD, S:GND)
Output impedance: 100Ohms
Nominal output level: +4dBu (1.228Vrms)
Maximum output level: +24dBu (12.277Vrms)Digital audio outputs
Coaxial Connector: RCA pin jack
Coaxial Format: IEC60958-3(S/PDIF) / IEC60958-4(AES/EBU)
Input impedance: 75 ohm
Input level: 0.5Vp-p / 75 ohm
Optical (S/MUX) Connector: OPTICAL (JEITA RC-5720C)
Optical (S/MUX) Format: Multi-channel optical format (S/MUX4 is available in 88.2k/96k/176.4k/192kHz)MIDI In/Out
Connector: Din 5-pin
Format: Standard MIDI formatWord In
Connector: BNC, Permissible frequency deviation at the time of external synchronization
Input voltage: 2.0Vpp to 5.0Vpp
Input impedance: 75Ohm +/-10%
Input level: +/-100ppmWord Out
Connector: BNC, with OUT/THRU select switch
Output voltage: 2.0Vpp (75Ohm loaded)
Output impedance: 75Ohm +/-10%
Sampling frequency: 44.1k/48k/88.2k/96k/176.4k/192kHzUSB
Connector: USB3.0/2.0 B type
Format: USB3.0 SuperSpeed (5Gbps)/USB2.0 HIGH SPEED (480Mbps)Phone
Connector: 6.3mm(1/4") stereo phone jack
Maximum output level: 70mW+70mW or more (THD+N 0.1% or less, 32Ohms loaded)Power
Dedicated AC adapter (GPE248-120200-Z, included)
Power consumption
20W
Operating temperature
5 to 35 deg. C / 41 to 95 deg. F
Frequency response
Line Out (Balanced):
44.1k/48k Hz: 20Hz to 20kHz, +/-0.3dB(JEITA)
88.2k/96k Hz: 20Hz to 40kHz, +/-0.3dB(JEITA)
176.4k/192k Hz: 20H to 80kHz +/-0.5dB(JEITA)THD
0.005% or less
S/N ratio
104dB or more
Crosstalk
100dB or more
Computer System requirements
Windows:
OS: Windows 7(32-bit SP1, 64-bit SP1), Windows 8.0(32-bit, 64-bit), Windows 8.1(32-bit, 64-bit), Windows 10(32-bit, 64-bit)
Compatible computers: Windows-compatible computer with a USB 2.0 or USB3.0 port
CPU type/speed: Dual core/2 GHz or faster
Memory: 2GB or more
Driver: USB Audio Class 2.0, ASIO2.0, WDM(MME), MIDI
Screen resolution: 1280 x 800 Dot or moreComputer System requirements 1
Macintosh:
OS: OS X Mountain Lion(10.8), OS X Mavericks(10.9), OS X Yosemite(10.10)
Compatible computers: Apple Mac computer with a USB 2.0 or USB3.0 port
CPU type/speed: Dual core/2 GHz or faster
Memory: 2GB or more
Driver: Core Audio, Core MIDI
Screen resolution: 1280 x 800 Dot or more
iOS:
OS: iOS 7Dimensions (W x H x D)
52 x 2.32 x 8.7" / 132.08 x 5.89 x 22.10cm
Weight
5.95lbs / 2.70kg
UPC Code
043774031184
About Tascam US-20X20
What's in the box:
- Tascam 20x20 USB 3.0 Audio MIDI Interface with Mic Preamps & Digital Mixer Modes
- Rackmount Adapters and Hex Keys
- Dedicated AC Adapter
- USB2.0 Cable
- USB3.0 Cable
- User's Manual
- Tascam 1 Year Limited Warranty
