New Arrival

Turtle AV Pro Dual-Channel Dante to Analog Line Output Adapter, Turtle Aqua

SKU: TUD2LDEPRO MFR: TAV-D2LDE-PRO
Earn VIP Reward Points

Key Features

  • Experience superior "audio quality" with crystal-clear sound for all your professional applications.
  • Enjoy flexible "connectivity options" with Dante to analog line output for seamless integration.
  • Benefit from a versatile "input/output count" to manage multiple audio streams effortlessly.
  • Achieve flawless synchronization with ultra-low "latency performance" for live sound and recording.
  • Ensure broad compatibility with various systems thanks to robust "software compatibility."
  • Rely on exceptional "build quality" for durable and consistent performance in any environment.
See More Product Details
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Turtle AV Pro Dante-Analog Adapter Specifications

Technical

Technical

Jump to...
  • Input

    Dante 2CH digital audio

  • Output

    Two-channel balanced/unbalanced analog audio

  • Control

    Dante Controller

  • Network Bandwidth

    100M

  • Audio Latency

    Configurable Dante device latency (Supports 1, 2 or 5ms configurable using Dante Controller)

  • Audio Formats

    Dante In (Digital audio input, PCM 2CH 44.1K-96KHz 16/24bit)
    Line Out (Analog audio output, Balanced/unbalanced 2CH, Max output level +18dBu)

  • Audio Parameters

    Line Out

    Input Impedance: 600 Ohm balanced, 300 Ohm unbalanced
    Line Output Level (Maximum): +18dBu (6.15Vrms) @balanced audio, +12dBu (3.08Vrms) @unbalanced audio
    Frequency Response: 20Hz to 20kHz (-/+0.5dB)
    Dynamic Range: >100dB@0dBu, 1kHzA-weighted
    Audio S/N Ratio: >100dB@0dBu, 1kHzA-weighted
    Audio THD+N: <0.01% at +4dBu, 1KH
    Audio Output Sync Delay: <10ms

  • ESD Protection

    IEC 61000-4-2: +/-8kV (Air-gap discharge) & +/-4kV (Contact discharge)

Connections

Jump to...
  • Input

    1x DANTE (RJ45 LAN, PoE)
    1x POWER (2-pin phoenix, 3.81mm)

  • Output

    1x CH1/CH2 LINE OUT (6pin-3.5mm phoenix connector)

Mechanical

Jump to...
  • Housing

    Metal enclosure

  • Power Supply

    PoE: PoE IEEE802.3af Class 0
    USB: 5V/500mA

  • Power Consumption

    2W (MAX)

  • Operating Temperature

    32 - 104 Degree F (0 - 40 Degree C)

  • Relative Humidity

    20% - 90% RH (no condensing)

Physical

Jump to...
  • Color

    Turtle Aqua

  • Dimensions (W x D x H)

    4.72 x 1.85 x 1.02" (120 x 47 x 26mm)

  • Weight

    6.56 oz (186g)

  • UPC Code

    9309002545078

About Turtle AV Pro Dante-Analog Adapter

Dante to Analog. Plug in. Play Anywhere.
Unlock the power of pristine digital audio with the Dante 2CH Line Output Adapter. Built on the cutting-edge Dante Ultimo 2x2 solution, this adapter converts crystal-clear Dante digital audio into two-channel balanced or unbalanced analog audio.

Built tough with all metal chassis.
Dante Pro Dual Line Output is housed in an all-metal chassis for maximum ruggedness. Andyes, we painted it Turtle Aqua so you know it looks cool even if mounted under a table where no one can see it.

Dante Ultimo. Accept no substitutes.
In networked audio, precision is essential, and Dante by Audinate delivers with unmatched synchronization and ultra-low latency performance. Leveraging advanced Precision Time Protocol (PTP), Dante ensures every audio packet arrives at exactly the right moment, maintaining audio quality and eliminating jitter, even in complex networks. Turtle AV adapters, powered by the genuine Dante Ultimo chipset, provide seamless compatibility and full interoperability with any Dante-compatible device, ensuring flawless, professional-grade sound for all installations, from live performances to intricate broadcast environments.

100% Dante Software compatible.
Turtle AV Dante Adapters are fully compatible with Dante Controller, Dante Domain Manager, and all Dante software applications.

Easy Control.
Take command with Dante Controller. Our adapters are fully controllable through this intuitive platform, allowing you to easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle.

Audio stuff.
This adapter converts Dante 2CH digital audio into two-channel analog audio, supporting both balanced and unbalanced analog outputs. It offers a versatile Dante audio sampling rate of 44.1, 48, 88.2, and 96KHz at 24-bit, ensuring high-quality sound. The configurable Dante audio delay can be set to 1, 2, or 5 milliseconds, while the analog audio input features 3 levels of sensitivity adjustment, +18dBu, 0dBu, and -10dBV

TAA Compliant.
Turtle AV products sold in the USA are TAA compliant, meeting U.S. government standards for procurement. This ensures they can be confidently used in federal contracts, adhering to strict ethical sourcing and manufacturing regulations.

Turtle AV Pro Dante-Analog Adapter Features

  • Dante 2CH digital audio to two-channel analog audio
  • Balanced/unbalanced analog audio output
  • Dante audio sampling rate supports 24bit 44.1/48/88.2/96KHz
  • Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
  • Supports AES67 RTP audio transmission
  • Analog audio output with support for 3-level gain adjustment: +18dBu, 0dBu (default), and -10dBV
  • PoE and 12V DC power via phoenix connector
  • All-Metal Chassis
  • TAA Compliant

Key Features

  • Experience superior "audio quality" with crystal-clear sound for all your professional applications.
  • Enjoy flexible "connectivity options" with Dante to analog line output for seamless integration.
  • Benefit from a versatile "input/output count" to manage multiple audio streams effortlessly.
  • Achieve flawless synchronization with ultra-low "latency performance" for live sound and recording.
  • Ensure broad compatibility with various systems thanks to robust "software compatibility."
  • Rely on exceptional "build quality" for durable and consistent performance in any environment.

What's in the box:

  • Turtle AV Pro Dual-Channel Dante to Analog Line Output Adapter (Turtle Aqua)
  • 6-Pin 3.81mm Phoenix Connector (Male)
  • 2-Pin 3.81mm Phoenix Connector (Male)
  • Turtle AV 5 Year Limited Warranty
