Universal Audio Apollo x8 Heritage Edition Rackmount 18x24 Thunderbolt 3 Audio Interface with Realtime UAD HEXA Core Processing for Mac and Windows

SKU: UAPX8HE MFR: APX8-HE
Earn VIP Reward Points

Key Features

  • Experience pristine audio quality with the Apollo x8's premium AD/DA converters.
  • Harness UAD HEXA Core processing for real-time effects while you're recording.
  • Achieve ultra-low latency for seamless tracking and overdubbing in your DAW.
  • Expand your studio with 18x24 Thunderbolt 3 connectivity for versatile I/O.
  • Elevate your mixes with included UAD plug-ins, adding warmth and character.
  • Integrate easily with Mac & Windows; ideal for professional music production.
See More Product Details
Special Order?Estimated to Ship: 08/19/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$249.00

2 Year

$409.00

3 Year

$649.00

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Universal Audio Apollo x8 Specifications

General

General

Jump to...
  • Form Factor

    Rackmount

  • Display

    10x Multi-Segment LED Meter

  • Channels of I/O

    Analog:
    8 Inputs / 14 Outputs at 192 kHz

    Digital:
    10 Inputs / 10 Outputs at 96 kHz

  • Max Sample Rate/Resolution

    192 kHz / 24-Bit

  • Number of Mic Preamps

    4

  • Input Level Adjustment

    1x Knob

  • Expansion Slots

    None

  • Pad

    -20 dB (Switchable per Channel)

  • Gain/Trim Range

    Inputs:
    +10 to +65 dB

  • High-Pass Filter

    75 Hz, 12 dB/Octave

  • Solo/Mute

    Mute per Master

Connectivity

Jump to...
  • Analog Audio I/O

    4x XLR 3-Pin Balanced Mic Input
    2x 1/4" TS Unbalanced Hi-Z Input (Front Panel)
    8x 1/4" TRS Balanced Line Input
    2x 1/4" TRS Balanced Monitor Output
    8x 1/4" TRS Balanced Line Output
    2x 1/4" TRS Unbalanced Headphone Output

  • Phantom Power

    48 V, Selectable On/Off (Selectable on Individual Inputs)

  • Digital Audio I/O

    2x TOSLINK Optical ADAT Input (S/MUX4 Support)
    2x TOSLINK Optical ADAT Output (S/MUX4 Support)
    1x RCA Coaxial S/PDIF Input
    1x RCA Coaxial S/PDIF Output

  • Host Connection / USB

    1x USB Type-C (Thunderbolt 3)

  • USB (Non-Host)

    None

  • Sync I/O

    1x BNC Word Clock Input
    1x BNC Word Clock Output

  • Network I/O

    None

  • MIDI I/O

    None

  • Wireless Connectivity

    None

Performance

Jump to...
  • Frequency Response

    Mic Inputs:
    20 Hz to 20 kHz +/-0.05 dB

    Hi-Z Inputs:
    20 Hz to 20 kHz +/-0.04 dB

    Line Inputs:
    20 Hz to 20 kHz +/-0.05 dB

    Monitor Outputs:
    20 Hz to 20 kHz +/-0.06 dB

    Line Outputs:
    20 Hz to 20 kHz +/-0.07 dB

    Headphone Outputs:
    20 Hz to 20 kHz +/-0.05 dB

  • Max Input Level

    Mic Inputs:
    +26 dBu (with Pad)

    Hi-Z Inputs:
    +12.4 dBu

    Line Inputs:
    +24 dBu (with Pad)

  • Max Output Level

    Line/Monitor Outputs:
    +24 dBu

  • Headphone Output Power

    150 mW into 300 Ohms

  • Impedance

    Hi-Z Inputs:
    1 Megohm

    Line Inputs:
    10 Kilohms

    Line Outputs:
    100 Ohms

    Mic Inputs:
    5.5 Kilohms

    Monitor Outputs:
    100 Ohms

    Word Clock :
    75 Ohms

  • Dynamic Range

    Mic Inputs:
    122 dBA

    Hi-Z Inputs:
    121 dBA

    Line Inputs:
    123 dBA

    Monitor Outputs:
    129 dBA

    Line Outputs:
    127 dBA

    Headphone Outputs:
    125 dBA

  • THD+N

    Mic Inputs:
    -114 dB / 0.0002% (1 kHz)

    Hi-Z Inputs:
    -111 dB / 0.00028% (1 kHz)

    Line Inputs:
    -113 dB / 0.00022% (1 kHz)

    Monitor Outputs:
    -118 dB / 0.00012% (1 kHz, at -1 dBFS)

    Line Outputs:
    -119 dB / 0.00011% (1 kHz, at -1 dBFS)

    Headphone Outputs:
    -102 dB / 0.0008% (1 kHz, at -1 dBFS)

Digital Audio

Jump to...
  • Sample Rates

    Up to 192 kHz

  • Sample Rate Conversion

    None

  • Bit Depths

    24-Bit (AD/DA Conversion)

  • Latency

    1.1 ms at 96 kHz (Input to Output)

  • Sync Sources

    ADAT, Internal, S/PDIF, Word Clock

  • Clocking

    Word Clock:
    Input Termination: 75 Ohms (Switchable)
    Lock Range: 44.1 to 192 kHz +/-4% of Sample Rate

  • Memory Card Slot

    None

Compatibility

Jump to...
  • OS Compatibility

    macOS 10.12 / 10.13 / 10.14 / 10.15
    Windows 10 (64-Bit, Only)

  • Included Software

    LUNA Mac Only

  • Compatible Software

    Any Core Audio (Mac) Compliant Software (Not Included)

  • Supported Drivers/API & Plug-Ins

    Proprietary

  • Processor Requirement

    Intel Core i7

  • Storage Requirements

    6 GB

  • Mobile Device Compatibility

    None

  • Required Hardware

    Available Thunderbolt 3 Port
    Thunderbolt Cable (Not Included)

  • Internet Connection

    Required for Registration and Software/Driver Download

  • Power Requirements

    AC/DC Power Adapter (Included)

  • AC Input Power

    100 to 240 VAC, 50 / 60 Hz

  • AC/DC Power Adapter

    12 VDC at 6 A (Included)

  • Power Consumption

    30 W (Typical)
    72 W (Maximum)

Physical

Jump to...
  • Rackmount Size

    1 RU

  • Operating Temperature

    32 to 104 Degree F (0 to 40 Degree C)

  • Dimensions

    19 x 13.5 x 1.8" (48.3 x 34.3 x 4.6cm) (Including Controls and Protrusions)

  • Weight

    9.0 lbs (4.1kg)

  • UPC Code

    819937003066

About Universal Audio Apollo x8

Why settle for less when you can have the best The Apollo x8 Heritage Edition Rackmount 18x24 Thunderbolt 3 Audio Interface is a high-quality, professional-grade audio interface that offers advanced, innovative, and sophisticated features for both Mac and Windows users.

This audio interface is designed for music producers, project studios, and post-production studios, providing elite-class A/D and D/A conversion, HEXA Core UAD plug-in processing, Dual-Crystal clocking, and 7.1 surround sound monitoring. It's built on UA's 60-year heritage of audio craftsmanship, ensuring top-notch audio quality and performance.

The Apollo x8 stands out with its four Unison-enabled mic preamps and all-new HEXA Core processing, which provides 50% more DSP for running UAD Powered Plug-Ins in real time. It also includes the LUNA Recording System, a fully-integrated music production application that enhances your recording and mixing capabilities.

With its elite-class 24-bit/192 kHz converters and all-new analog circuitry, the Apollo x8 offers an ultra-pristine signal path for superior audio quality. It also features new Dual-Crystal clocking for stunningly low jitter and pure, artifact-free recordings.

The Apollo x8 also boasts new HEXA Core processing, with six DSP chips and 50% more UAD plug-in processing power than previous Apollos. This allows you to run more UAD plug-ins, whether you're tracking in real time with channel strips from Neve, Manley, or API, or running high UAD plug-in counts when mixing in your DAW.

Unison technology, a Universal Audio exclusive, allows you to track through exacting mic preamp emulations from Neve, API, Manley, Helios, SSL, and Universal Audio. This technology nails the tone of these sought-after tube and solid state mic pres, including their input impedance, gain stage "sweet spots," and the component-level circuit behaviors of the original hardware.

The Apollo x8 also includes the Realtime Analog Classics Plus plug-in bundle, so you can record and mix with the world's only authentic Teletronix LA-2A, 1176LN, and Fairchild compressors, the Unison-enabled UA 610-B Tube Preamp & EQ, and iconic guitar and bass amps from Marshall and Ampeg.

In addition to the included Realtime Analog Classics Plus plug-ins, the Apollo x8 lets you tap into the full UAD Powered Plug-In library of legendary vintage EQs, compressors, reverbs, tape machines, channel strips, and more.

The Apollo x8 Heritage Edition Rackmount 18x24 Thunderbolt 3 Audio Interface is more than just an audio interface; it's a complete audio solution that brings the power of a professional recording studio right to your desktop.

Universal Audio Apollo x8 Features

  • 18 x 24 Thunderbolt 3 audio interface with class-leading 24-bit/192 KHz conversion (backwards compatible with Thunderbolt 1 & 2 on Mac)
  • Realtime UAD HEXA Core Processing for tracking through UAD plug-ins at near-zero latency, regardless of audio buffer size
  • Record through 4 Unison-enabled mic/line preamps - giving you fully authentic preamp emulations from Neve, API, Manley, SSL, and moref
  • Includes access to LUNA Recording System for a fully-integrated, analog inspired Apollo workflow
  • Surround monitor controller up to 7.1 format
  • Includes the "Realtime Analog Classics Plus" UAD plug-in bundle. Other UAD plug-ins sold separately
  • UAD HEXA Core processing onboard for additional mixing horsepower for Pro Tools, Logic, Cubase, Ableton, and other major DAWs
  • Combine up to 4 Thunderbolt-equipped Apollos and 6 total UAD devices
  • Selectable +24 dBu operation for easy compatibility with professional mixing consoles and tape machines
  • Convenient front panel monitoring functions including Alt Speakers, Talkback mic, and assignable Dim or Mono
  • Free, industry-leading technical support - on the phone and online - from knowledgeable audio engineers

Product Documents

User Manual

Key Features

  • Experience pristine audio quality with the Apollo x8's premium AD/DA converters.
  • Harness UAD HEXA Core processing for real-time effects while you're recording.
  • Achieve ultra-low latency for seamless tracking and overdubbing in your DAW.
  • Expand your studio with 18x24 Thunderbolt 3 connectivity for versatile I/O.
  • Elevate your mixes with included UAD plug-ins, adding warmth and character.
  • Integrate easily with Mac & Windows; ideal for professional music production.

What's in the box:

  • Universal Audio Apollo x8 Heritage Edition Rackmount 18x24 Thunderbolt 3 Audio Interface with Realtime UAD HEXA Core Processing
  • External Power Supply
  • IEC Power Cable
  • 4x Rackmount Screws
  • 34x UAD Plug-Ins (Download)
  • LUNA Recording Software for Mac (Download)
  • (Thunderbolt Cable Not Included)
  • Universal Audio 1 Year Limited Warranty
