Ubiquiti Networks 6-Port PoE EdgeRouter with EdgeMAX Technology

SKU: UBER6P

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?TOM C : PO Daley ElecLes W : Need new router for GB internet connection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Ubiquiti Networks EdgeRouter 6P Specifications

EdgeRouter

EdgeRouter

Jump to...
  • Button

    Reset

  • LEDs: Data Ports

    Speed/Link/Activity, PoE

  • LEDs: SFP Data Port

    Link/Activity

  • Networking Interfaces

    Management:(1) RJ45 Serial Port; (6) Ethernet Ports (Default eth0)
    Networking: (5) 10/100/1000 RJ45 Ports with PoE; (1) 1 Gbps SFP Port

  • Processor

    4-Core 1GHz, MIPS64

  • System Memory

    1GB DDR3 RAM

  • On-Board Flash Storage

    4GB eMMC, 8MB SPI NOR

  • Rack-Mountable

    Yes

  • Operating Temperature

    -10 to 50 deg. C (14 to 122 deg. F)

  • Operating Humidity

    10 - 90% Noncondensing

  • Certifications

    CE, FCC, IC

  • Max. Power Consumption

    16 W (Excludes PoE Output)

  • Power

    External AC Power Adapter, 60W (24V, 2.5A)

  • Power Input

    110 - 240VAC

PoE with Power Adapter

Jump to...
  • PoE Interfaces

    (5) 24V Passive PoE Ports, 2-pair (4, 5+; 7, 8-) and 4-pair

  • Passive PoE

    Max. Wattage Per Port: 24W (24V/1A, 4-pair)

  • Voltage Range Passive PoE

    24V

  • Interface/Encapsulation

    Ethernet
    802.1q VLAN
    PPPoE
    GRE
    IP in IP
    Bridging
    Bonding (802.3ad

  • Addressing

    Static IPv4/IPv6 Addressing
    DHCP/DHCPv6

  • Routing

    Static Routes
    OSPF/OSPFv3
    RIP/RIPng
    BGP (with IPv6 Support)
    IGMP Proxy
    MPLS

  • Security

    ACL-Based Firewall
    Zone-Based Firewall
    Application Identification with Deep Packet Inspection (DPI)
    NAT

  • VPN

    IPSec Site-to-Site and Remote Access
    OpenVPN Site-to-Site and Remote Access
    PPTP Remote Access
    L2TP Remote Access
    PPTP Client

  • Services

    DHCP/DHCPv6 Server
    DHCP/DHCPv6 Relay
    Dynamic DNS
    DNS Forwarding
    VRRP
    RADIUS Client
    Web Caching
    PPPoE Server

  • QoS

    FIFO
    Stochastic Fairness Queueing
    Random Early Detection
    Token Bucket Filter
    Deficit Round Robin
    Hierarchical Token Bucket
    Ingress Policing

  • Management

    Web UI
    Ubiquiti Network Management System (UNMS)
    CLI (GUI, Console, SSH, Telnet)
    SNMP
    NetFlow
    LLDP
    NTP
    UBNT Discovery Protocol
    Syslog

General

Jump to...
  • Dimensions

    EdgeRouter: 229 x 136.5 x 31.1mm (9.02 x 5.37 x 1.22")

  • Weight

    EdgeRouter: 1.61 lbs (0.73kg)

  • UPC Code

    817882020626

About Ubiquiti Networks EdgeRouter 6P

Discover the power of advanced routing technology with the EdgeRouter 6P, a high-tech product from Ubiquiti Networks. This sophisticated router is part of the next generation of devices for the EdgeMAX platform, offering a blend of carrier-class reliability and enterprise-level features in a compact, affordable unit.

The EdgeRouter 6P is designed to handle high-speed internet connections and large file transfers with ease, thanks to its gigabit 10/100/1000 transfer rate. It features six ports, allowing you to connect multiple devices such as computers, printers, and other networking equipment to your network.

Five of these ports are configurable PoE ports, designed to power airMAX products. The router is capable of routing up to 3.4 million packets per second and boasts a line rate of 6 Gbps. It also includes a Gigabit SFP port for added connectivity options.

The EdgeRouter 6P is powered by EdgeOS, a proprietary and intuitive graphical interface that simplifies the configuration of routing, security, and management features. For advanced network professionals, an integrated CLI is available for quick and direct access using familiar commands.

The UNMS app offers even greater convenience and flexibility, allowing you to manage the EdgeRouter remotely from your mobile device. This powerful router also includes a range of monitoring tools and security features, including firewall policies, NAT rules, and DHCP services.

The EdgeRouter 6P is housed in a compact, durable metal case and operates silently, making it an ideal choice for home or small office settings. Experience the future of routing technology with the EdgeRouter 6P.

Ubiquiti Networks EdgeRouter 6P Features

  • High-tech EdgeRouter 6P with advanced EdgeMAX platform technology
  • Powerful performance with gigabit 10/100/1000 transfer rate
  • Six ports for connecting multiple devices, including five configurable PoE ports
  • Proprietary EdgeOS interface for easy configuration of routing, security, and management features
  • Integrated CLI for direct access by advanced network professionals
  • Remote management capability via the UNMS mobile app for added convenience and flexibility

Key Features

  • Experience seamless connectivity with this Ubiquiti EdgeRouter, perfect for small businesses.
  • Enjoy robust security features, including advanced firewall, protecting your network from threats.
  • This 6-Port PoE EdgeRouter offers Gigabit speeds for fast data transfers and reliable performance.
  • Easily manage your network with the intuitive EdgeOS, designed for straightforward configuration.
  • Ideal for powering devices like IP cameras, thanks to its integrated 24V passive PoE ports.
  • Get wide coverage and stable connections, perfect for homes needing a reliable WiFi network.

What's in the box:

  • Ubiquiti Networks 6-Port PoE EdgeRouter
  • 2x Wall Mount Screws
  • 2x Wall Mount Anchors
  • Ground Screw
  • Power Cord
  • Power Adapter (24V/2.5A)
  • Cable Clip
  • Quick Start Guide
  • Ubiquiti Networks 1 Year Limited Warranty
