Ubiquiti Networks US-48-750W Specifications

  • Total Non-Blocking Throughput

    70Gbps

  • Switching Capacity

    140Gbps

  • Forwarding Rate

    104.16Mpps

  • Maximum Power Consumption

    Including PoE Output: 750 W
    Excluding PoE Output: 64W

  • Power Method

    100 to 240VAC, 50 to 60Hz, Universal Input

  • Power Supply

    AC/DC, Internal, 750W DC

  • LEDs

    SFP Data Ports: Speed/Link/Activity

  • Ethernet Networking Interfaces

    48x 10/100/1000 Mb/s RJ45 Ethernet Ports
    2x 1/10 Gb/s SFP+ Ethernet Ports
    2x 1 Gb/s SFP Ethernet Ports

  • Management Interface

    1x RJ45 Serial Port (Reserved for Future Use), Ethernet In/Out Band

  • Certifications

    CE, FCC, IC

  • Rackmount

    Yes, 1U High

  • ESD/EMP Protection

    Air: +/-24 kV, Contact: +/-24 kV

  • Shock and Vibration

    ETSI300-019-1.4 Standard

  • PoE Interfaces

    POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
    24 VDC Passive PoE (Pins 4, 5+; 7, 8-)
    Maximum PoE+ Wattage per Port by PSE: 34.2W

  • Voltage Range

    802.3at Mode: 50 to 57V
    24V Passive PoE: 20 to 27V

  • Maximum PoE Wattage Per Data Port

    17W

  • System Requirements

    Linux, Mac OS X, or Microsoft Windows 7/8
    Java Runtime Environment 1.6 (or above)
    Web Browser: Mozilla Firefox, Google Chrome, or Microsoft Internet Explorer 8 (or above)

  • Operating Temperature

    23 to 104 deg. F / -5 to 40 deg. C

  • Operating Humidity

    5 to 95%, non-condensing

  • Dimensions

    485 x 43.7 x 374.6mm / 19.09 x 1.72 x 14.75"

  • Weight

    6.5kg / 14.33lbs

  • UPC Code

    810354020797

About Ubiquiti Networks US-48-750W

Are you looking to build and expand your network with a high-performance, reliable, and efficient solution Look no further than the 750W UniFi Managed PoE+ Gigabit Switch with SFP+ and 48x RJ45 Ports. This advanced switch, a proud member of the Ubiquiti Networks UniFi product line, delivers robust performance and intelligent switching capabilities, making it an ideal choice for growing networks.

This fully managed, PoE+ Gigabit switch offers non-blocking throughput switching performance, ensuring seamless data transfer without any packet loss. It features both Gigabit Ethernet RJ45 and SFP+/SFP ports, providing a wide range of connectivity options. With auto-sensing IEEE 802.3af/at PoE support, this switch can power a variety of devices, including IP cameras, VoIP phones, and other PoE-enabled devices, simplifying your network infrastructure.

The UniFi Switch is a 1U rackmount device, making it a compact and space-saving solution for your networking needs. It supports both 802.3af and 802.3at PoE standards, ensuring compatibility with a wide range of devices. With a high throughput capacity of 70 Gbps, this switch guarantees fast and efficient data transfer.

The switch also offers fiber connectivity options for easy network expansion. Each model includes two SFP ports for uplinks of up to 1 Gbps, while the 48-port model adds two SFP+ ports for high-capacity uplinks of up to 10 Gbps. This allows you to connect directly to a high-performance storage server or deploy a long-distance uplink to another switch.

The UniFi Switch integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform, creating a highly scalable, end-to-end system of network devices across multiple locations, all controlled from a single interface. The UniFi Controller software provides a user-friendly graphical interface for easy configuration and monitoring of the UniFi Switch and other UniFi devices.

In conclusion, the 750W UniFi Managed PoE+ Gigabit Switch with SFP+ and 48x RJ45 Ports is a robust, efficient, and advanced solution for your networking needs, offering high-speed connectivity, PoE+ support, and seamless integration with the UniFi SDN platform.

Ubiquiti Networks US-48-750W Features

  • High-performance 750W UniFi Managed PoE+ Gigabit Switch with SFP+ and 48x RJ45 Ports
  • Advanced non-blocking throughput switching performance for seamless data transfer
  • Supports auto-sensing IEEE 802.3af/at PoE, ideal for powering devices like IP cameras and VoIP phones
  • Compact 1U rackmount design for space-efficient networking
  • High-capacity uplinks with two SFP+ ports for up to 10 Gbps, perfect for connecting to storage servers or other switches
  • Seamless integration into the UniFi Software-Defined Networking (SDN) platform for easy management and monitoring

Key Features

  • High-performance 750W UniFi Managed PoE+ Gigabit Switch with SFP+ and 48x RJ45 Ports
  • Advanced non-blocking throughput switching performance for seamless data transfer
  • Compact 1U rackmount design for space-efficient networking

What's in the box:

  • Ubiquiti Networks 750W UniFi Managed PoE+ Gigabit Switch
  • Power Cord
  • 4x #10-32 x 5/8 " Mounting Screws
  • 4x #10-32 x 5/8 " Cage Nuts
  • Quick Start Guide
  • Ubiquiti Networks 1 Year Limited Warranty
