Ubiquiti Networks UniFi AC In-Wall Indoor 802.11ac Wi-Fi Dual Radio Access Point, 2x2 MIMO, 5 Pack

SKU: UBUAPACIW5

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the three Gigabit Ethernet ports on the UniFi AC In-Wall Access Point?

The three Gigabit Ethernet ports on the UniFi AC In-Wall Access Point allow you to connect multiple devices directly to the access point for reliable, high-speed internet access. One of these ports also offers Power over Ethernet (PoE), enabling you to power and connect an 802.3af device to your network seamlessly.

How does the UniFi Controller software enhance the functionality of the UniFi AC In-Wall Access Point?

The UniFi Controller software provides a user-friendly interface for configuring and managing your UniFi AC In-Wall Access Point. You can monitor device and client activity, track data usage, and maintain network security. It also offers features for advanced network management, such as RF map and performance features for optimal access point placement and configuration.

What is the benefit of the Wi-Fi 802.11AC MIMO technology in the UniFi AC In-Wall Access Point?

Wi-Fi 802.11AC MIMO technology allows the UniFi AC In-Wall Access Point to provide faster and more reliable internet access. It improves the efficiency of your Wi-Fi network by allowing multiple data signals to be sent and received at the same time, resulting in better performance, especially in environments with multiple connected devices.

Can I limit the internet usage of guests using the UniFi AC In-Wall Access Point?

Yes, the UniFi AC In-Wall Access Point offers a Guest Portal/Hotspot feature that allows you to set up custom authentication methods and limit bandwidth rates, total data usage, and duration of use. This feature also includes built-in support for billing integration and voucher-based authentication.

Is the UniFi AC In-Wall Access Point suitable for large-scale deployments?

Absolutely. The UniFi AC In-Wall Access Point is designed with scalability in mind. You can start with a single unit and expand to thousands as needed, all while maintaining a single unified management system through the UniFi Controller software. This makes it an ideal solution for large-scale deployments.

Reviews about this item

Review Summary

2021-01-05T07:45:53

Rated 3 out of 5

Ubiquiti Networks UniFi AC In-Wall Indoor 802.11ac Wi-Fi Dual Radio Rating

I prefer the older model and they seem to work better and fit in wall instead of external. The newer model also seems to have an issue with interference and will disconnect frequently or not come online at all unless you reset it to factory numerous times. Once it is set up correctly, it seems to work well.

DAVID L.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Ubiquiti Networks UniFi AC In-Wall Specifications

  • Package Quantity

    5

  • Environment

    Indoor

  • Networking Interface

    3x 10/100/1000 Ethernet Ports

  • Buttons

    Reset

  • Power Method

    802.3at PoE+ Supported

  • Power Supply

    UniFi PoE Switch (Not Included)

  • Power Save

    Supported

  • PoE Out

    48V Pass-Through (Pins 1, 2+; 3, 6-)

  • Maximum Power Consumption

    With PoE Pass-through:
    7W
    19W (Requires 802.3at PoE+ switch)

  • Maximum TX Power

    2.4 GHz: 20 dBm
    5 GHz: 20 dBm

  • Antennas

    One Dual-Band Antenna, Single-Polarity
    2.4 GHz: 1 dBi
    5 GHz: 2 dBi

  • Wi-Fi Standards

    802.11 a/b/g/n/ac

  • Wireless Security

    WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)

  • BSSID

    Up to 8 per Radio

  • MIMO

    2.4GHz: 2x2
    5GHz: 2x2

  • Mounting

    1-Gang Electrical Wall Box (Not Included)

  • Operating Temperature

    -10 to 50 deg. C (14 to 122 deg. F)

  • Operating Humidity

    5 to 95% Noncondensing

  • Certifications

    CE, FCC, IC

  • Advanced Traffic Management

    VLAN: 802.1Q
    Advanced QoS: Per-User Rate Limiting
    Guest Traffic Isolation: Supported
    WMM: Voice, Video, Best Effort and Background
    Concurrent Clients: 250+

  • Standard Data Rates

    802.11ac: 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
    802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
    802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11b: 1, 2, 5.5, 11 Mbps

  • Dimensions

    139.7 x 86.7 x 25.75mm (5.50 x 3.41 x 1.01")

  • Weight

    200g (7.05 oz)

  • UPC Code

    810354026201

About Ubiquiti Networks UniFi AC In-Wall

Take your Wi-Fi connectivity to the next level with the UniFi AC In-Wall Indoor 802.11ac Wi-Fi Dual Radio Access Point. This sleek and modern device is designed to transform an Ethernet wall jack into a dual-band 802.11AC Wi-Fi access point, complete with three Gigabit Ethernet ports. One of these ports offers PoE, enabling you to power and connect an 802.3af device to your network seamlessly.

This innovative access point is perfect for both new installations and retrofitting, offering dedicated Wi-Fi for each room. It's not just about connectivity; it's about speed too. With two radios and 802.11ac technology, you can enjoy fast and reliable internet access.

The UniFi AC In-Wall Access Point also offers versatile data and PoE output. Your Ethernet wall jack becomes a multi-functional tool, serving as an access point, a gigabit switch, and a PoE power source. Whether you need to wire a workstation or power a VoIP phone, this device has got you covered.

Managing your device is simple and scalable with the UniFi Controller. This graphical user interface allows for easy configuration and monitoring of your UniFi Switch and other UniFi devices. Download the app and set up your unit in under 60 seconds. You can easily keep track of your devices, clients, and data usage, ensuring your network stays secure with constant reporting.

The UniFi 802.11AC Dual-Radio Access Points feature the latest in Wi-Fi 802.11AC MIMO technology, offering powerful hardware for your connectivity needs. The intuitive UniFi Controller Software allows you to configure and manage your APs with an easy-to-learn user interface. Plus, with unlimited scalability, you can build wireless networks as big or small as needed.

Extend your coverage with the UniFi Controller software. Whether running in a NOC or in the cloud, administrators can manage multiple sites, making it ideal for multiple, distributed deployments and multi-tenancy for managed service providers.

The UniFi AC In-Wall Access Point also offers a breakthrough RF map for monitoring and analyzing radio frequencies. This ensures optimal AP placement, configuration, and troubleshooting. Advanced RF performance and configuration features include spectral analysis, airtime fairness, and band steering.

The device also supports a Guest Portal/Hotspot with easy customization and options. You can limit bandwidth rates, total data usage, and duration of use. Plus, it offers built-in support for billing integration using major credit cards and voucher-based authentication.

The UniFi AC In-Wall Access Point is not just a device; it's a comprehensive solution for your Wi-Fi needs. Its sleek design allows for seamless integration into any environment, and its unique provisioning and status LED provides administrator location tracking and alerts for each device. With compatibility with an 802.3at PoE+ compliant switch, this access point is a powerful addition to your network.

Ubiquiti Networks UniFi AC In-Wall Features

  • Manage Your Networks from a Single Control Plane
  • Intuitive and Robust Configuration, Control and Monitoring
  • Remote Firmware Upgrade
  • Users and Guests
  • Guest Portal/Hotspot Support

Key Features

  • Dual-band 802.11AC Wi-Fi access point with seamless in-wall design
  • Three Gigabit Ethernet ports with PoE support for versatile connectivity
  • Quick and easy setup with the intuitive UniFi Controller software
  • Advanced Wi-Fi 802.11AC MIMO technology for high-performance networking
  • Scalable solution with unlimited network expansion capabilities
  • Guest Portal/Hotspot support with customizable authentication and bandwidth limits

What's in the box:

  • Ubiquiti Networks 5x UniFi AC In-Wall Indoor 802.11ac Wi-Fi Dual Radio Access Point
  • Cover Plates
  • Back Plates
  • Screws
  • Quick Start Guide
  • Ubiquiti Networks 1 Year Limited Warranty
