Used TOA Electronics 8-Channel Rack-mount Mixer, Modular, 20-20000Hz Frequency Response

Item Note: Item powers on but item has NOT been fully tested.

SKU: US1116409 MFR: M900MK2UL
Be the first to review this item
$30.00
$33.00
Save: $3 (9%)
Earn VIP Reward Points
See all Used options (1) from $30

What`s in the box:

  • TOA Electronics 8-Channel Rack-mount Mixer
  • 4 Volume Control Covers (YA-920)
  • Original Box ** Item Note: Item powers on but item has NOT been fully tested. **

INCLUDES FREE WARRANTY

  • This used item comes with a free 90-day warranty. ?
Calculate Shipping

See Options

Add to List

Protect your gear with Adorama Protect.* Learn more

1 Year

$5.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

Browse our FAQ

See Terms & Conditions

TOA Electronics 8-Channel Rack-mount Mixer - SKU#1116409 Specifications

  • Type

    8-channel mixer preamplifier

  • Power Requirement

    AC mains, 120 V, 60 Hz

  • Rated Output

    +4 dBm, +20 dBm (max.)

  • Power Band Width

    30 - 20,000 Hz, +20 dBm 0.5% THD
    25 - 20,000 Hz, +18 dBm 0.5% THD

  • Frequency Response

    20 - 20,000 Hz, +/- 1 dB

  • Total Hamonic Distortion

    0.01% at 1 kHz, rated output

  • Inputs

    Eight Input Ports: Each port accepts any input module.
    One Bridging Input/Output

  • Input Sensitivity/Impedance

    Input Port #1 to #8: 100 mV/10k ohms
    Bridging Input/Output:100 mV/3.3k ohms

  • Outputs

    Main: Balanced, 150/600 ohms
    Aux: Unbalanced, 10k ohms, 0 dBm

  • Output Regulation (1 kHz)

    Less than 1 .5 dB, no load to full load

  • Signal to Noise Ratio

    Master volume min: 90 dB
    Master volume max: 77 dB

  • Tone Controls

    Bass: +/- 10 dB at 100 Hz, Treble: +/- 10 dB at 10 kHz

  • Controls

    8 Input gain controls
    1 Master gain control
    1 Bass tone control 1 Treble control
    1 Power ON/OFF switch
    1 Tone defeat switch

  • Indicators

    1 Power LED, 1 Protect LED, 1 Signal LED, 1 Normal LED, 1 Peak LED

  • Protection

    Self-protection, with AC fuse (inside)

  • Connectors

    Input No.1 to No. 8: Card-edge connector
    Bridging, Aux output: RCA phono jack
    Output: Screw-terminal strip
    Mute, Remote VR: Screw-terminal strip
    AC power cord/plug: SJT, 3-prong type
    AC outlet: 3-pin grounding type

  • Power Consumption

    18W

  • Temperature Range

    -10 to +60 deg. C(12 to 140 deg. F)

  • Dimensions (W x H x D)

    16.5 x 3.9 x 12.1" / 419.1 x 99.06 x 307.34 mm

  • Weight

    11.7lbs / 5.30 kg

About TOA Electronics 8-Channel Rack-mount Mixer - SKU#1116409

The TOA Electronics 8-Channel Rack-mount Mixer controls and mixes up to eight independent input signals and delivers up to +20 dBm of output power. Optional plug in modules are available for use with mixer preamplifier to provide versatility for a wide range of operating design allows fast and easy custom for high performance with wide frequency response.

Very low noise and distortion and excellent output Module Slots accept any combination of TOA plug-in modules for unmatched Mute Bus permits multiple levels of paging priority using optional mute-type Master Volume controlled with an external 10k ohm linear-taper, Transformer-Isolated Output with screw terminal connector and protective cover plate.

TOA Electronics 8-Channel Rack-mount Mixer - SKU#1116409 Features

  • Individual Channel and Master Volume Controls
  • Bass/Treble Tone Controls with Tone Defeat Switch
  • Normal, Peak, Power, Protect and Signal LEDs provide instantly recognizable status indication
  • Auxiliary Output for connecting an external mixer or recording device
  • Bridging Input/Output Jack for fast and easy system expansion
  • Volume Control Security Covers included (4), model YA-920
  • Optional Rack-Mount Kit, model MB-25B (2 RU)
  • UL / CSA Listed
