Master or Slave Sync with SMPTE Time Code: The R-4 Pro accepts SMPTE time code which enables it to slave to video cameras or VTRs. Four channels of high quality audio can be fully synchronized with video. In addition, the R-4 Pro can also act as the master, sending out time code to slave devices.
AES/EBU Input/Output: The R-4 Pro is equipped with XLR style AES/EBU digital Input and Output.
Instant Backup via USB 2.0: The USB host terminal of R-4 Pro enables high speed and instant backup of recorded data to affordable and easy obtainable media like Flash Memory, Memory Cards via card reader or HDD storage.
DC Input for External Battery Power Supply: The R-4 Pro is equipped with a 4-pin XLR type battery power input. This enables power supplies from industry standard battery manufacturers for video cameras such as Anton-Bauer, etc.
Individual Monitoring of 4 channels: Individual monitoring of all channels is enabled via the four analog outputs. This allows precise monitoring of all recorded audio.
Extended Recording with 80GB Hard Disk Drive: Equipped with a 80GB hard disk drive, the R-4 Pro can record a stereo audio file for approximately116 hours at 16bit/44.1kHz/ 106 hours at 16bit/48kHz, 70 hours at 24bit/48kHz, 34 hours at 16bit/96kHz and 30 hours at 24bit/96kHz.
Superior 24-bit/96-kHz Linear Recording: Totally uncompressed recording assures outstanding sound quality. Choose 16-bit or 24-bit quantization and a sampling rate of 44.1 kHz, 48 kHz, 88.2kHz, 96 kHz or 192kHz. Save data as WAV files.
Simultaneous 4-Channel Recording: The 4 XLR/Phone combo jacks come with switchable phantom power and give you a choice of MONO, STEREO, STEREO X2, or 4CH recording. Digital input/output is also provided.
On-Board Limiter: The built-in Limiter helps deliver a stable and reliable recording free of clipped noise from sudden input surges.
Built-In Nondirectional Stereo Microphones: The R-4 Pro's omnidirectional, back electret condenser microphones offer superb transient characteristics and vibration resistance.
Pre-Recording Function: When the REC button is pressed, the current material is appended to a buffer that contains recorded material from a few seconds earlier. This helps prevent missed recording opportunities or sound bites at the beginning of a recording.
Five High-Quality Effects: The R-4 Pro lets you tailor the sound during both recording and playback.
Waveform Editing Using Only the R-4 Pro: The R-4 Pro is all you need to edit waveforms. Just watch the waveform on the LCD as you edit. Scrubbing playback with the shuttle dial lets you set the edit points precisely by sound.
Index Any Point Instantly: Press the mark button anytime during recording or playback to mark that point for easy, instant indexing later. With the A-B repeat function you can set two points and repeatedly play back the material between them.
Easy Playback with the Jog Dial: Use the jog dial to fast-forward or rewind at any of seven speed levels.
Built-In Stereo Speakers: The R-4 Pro's built-in speakers make it easy to monitor recorded sound without headphones.
USB 2.0 Terminal Provides a High-Speed Computer Data Link: The USB 2.0 high-speed mode transfers data about 20 times faster than DAT. You can also use the R-4 Pro as a 80GB storage device. Edit R-4 Pro files directly from DAWs and other applications.
Advanced Linking with the Roland DV-7DL: A USB cable is all you need to connect directly to an Roland DV-7DL Video Editor and exchange files.
Soft Carrying Case: The R-4 Pro comes with a soft carrying case with a shoulder strap for safe, comfortable use in the field.
