JVC GY-HD100U MiniDV High Definition Professional Camcorder - 470H SKU#1357503

Picture does not represent the actual item
See what's in the box

See all JVC items

Used JVC GY-HD100U High Definition 3-CCD Mini DV Professional Digital Video Camcorder with 16x Pro HD Fujinon Lens, 24-Frame Progressive Recording (470 Hours)

SKU: US1357503

This item is no longer available.

Recommended Items

JVC GY-HM250U: Picture 1 regular
JVC GY-HM250U 12.4MP 4K UHD Compact Handheld Camcorder w/Integrated 12x UHD Lens
$2,660.00
JVC : Picture 1 regular
JVC GY-HD200CHU 1/3" 3-CCD Professional HDV Camcorder with 60/24-Frame Progressive Recording (without Lens)
$164.00$145.00
JVC : Picture 1 regular
JVC GY-DV550U Pro DV Camcorder
$59.00
Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

JVC GY-HD100U MiniDV High Definition Professional Camcorder - 470H SKU#1357503 Specifications

  • Power requirements:

    DC 7.2 V

  • Power consumption:

    Approx.17 W (in the Record mode)

  • Image pickup device:

    1/3" interline-transfer CCDs

  • Color separation

    optical system:F1.4,3-color separation prism

  • Number of total pixels:

    Approx.1,110,000 pixels

  • Color bars:

    SMPTE type

  • Sync system:

    Internal sync (built-in SSG)

  • Lens mount:

    1/3" bayonet system

  • ND filter:

    1/4ND,+1/16ND

  • Gain:

    0,3,6,9,12,15,18 dB,ALC

  • Electronic shutter

    Standard value:59.94 Hz
    Fixed values:7.5 - 10,000 Hz,11 steps (HDV HD30p/HDV SD60p/DV 60i mode)
    6 - 10,000 Hz,12 steps (HDV HD24p/ DV 24p mode)
    Variable scan:60.2 to 1,998.0 Hz (HDV HD30p/HDV SD60p/DV 60i mode)
    , 48.12 to 1,998.0 Hz (HDV 24p/DV 24p mode)

  • Recording format:

    720/24p,720/25p,720/30p,576/50p,480/60p,480/24p,480/60i

  • Video Format [HDV]:

    HDV720p format,8-bit,19.7 Mbps MPEG-2 video (profile & level:MP@H-14)

  • [DV]Video signal recording formt Comprs:

    DV format,8-bit,25 Mbps DV compression,4:1:1

  • [HDV]Audio signal recording format:

    MPEG1 Audio Layer II

  • [DV]Audio signal recording format:

    16-bit (locked audio),48 kHz PCM for 2 channels or 12-bit,32 kHz PCM for 4 channels

  • Usable tape:

    Mini DV tape

  • Tape speed:

    18.8 mm/sec.

  • Record/play time:

    63 minutes (with an M-DV63PROHD tape)

  • Connectors

    ..

  • Analog composite output:

    1.0 V (p-p),75 ohms,unbalanced (RCA

  • Analog component output:

    Y:1.0 V (p-p),75 ohms,unbalanced (RCA)
    PB/PR:0.7 V (p-p),75 ohms,unbalanced (RCA)
    PB/PR:0.7 V (p-p),75 ohms,unbalanced (RCA)

  • Audio inputs

    Mic:-60 dBs,3 kohms,balanced (XLR),+48 V output for phantom power supply Line:+4 dBs,10 kohms,balanced (XLR)

  • Audio outputs:

    -6 dBs,low impedance,unbalanced (stereo mini-jack) -17 dBs to -60 dBs,8-ohm impedance (stereo mini-jack x2) Earphone jack

  • IEEE1394

    connector:6-pin

  • Dimensions:

    9-1/4" (W) x 9-1/8" (H) x 12-3/8" (D)/235 (W) x 232 (H) x 315 (D) mm

  • Weight:

    6.9 lbs./3.1 kg. (including lens (Th16x5.5BRMU),viewfinder,battery,microphone and tape

  • Temperature

    Operating:32°F to 104°F/0°C to 40°C Storage:-4F° to 140°F/-20°C to 60°C

  • Humidity

    Operating:30% to 80% RH Storage:85% RH or less

About JVC GY-HD100U MiniDV High Definition Professional Camcorder - 470H SKU#1357503

JVC GY-HD100U MiniDV High Definition Professional Camcorder - 470H SKU#1357503 Features

  • True HD. Real 24 frame progressive. Interchangeable lenses. This camera sets a new standard in digital cinematography.
  • Professional form factor
  • Film-Like 24 frame progressive capture and recording
  • Bayonet Mount Interchangeable Lenses
  • Focus Assist Function
  • Extensive user adjustable parameters
  • Superior signal processing
  • Progressive Scanning
  • Advanced encoding system from the leader in MPEG-2 technology
  • Reliable Dual Media Recording Capability
  • 2 XLR Audio Inputs
  • Compact shoulder mount
  • Smooth Motion Function (patented)
  • This Version Includes Fujinon 16x Lens

Used Guarantee

30-day money back!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • GY-HD100U Digital Video Camcorder
  • Fujinon Th16x5.5BRMU Zoom Lens
  • Lens Hood
  • Shotgun Mic
  • Item Note: Item has a couple of malfunctions; The firewire port fails to work; Lit pixel in top right corner at 0db gain and 1/60 shutter speed; Viewfinder is cracked near the elbow; Missing BN-V428 Battery; AC Adapter/Battery Charger (AA-P30); DC Cable; Audio Cable. Cosmetic condition is V.
