Muxlab 4K/60 HDMI to HDMI with Audio Extraction
Muxlab 500436: Picture 1 thumbnail
Muxlab 500436: Picture 2 thumbnail
Muxlab 500436: Picture 3 thumbnail
Muxlab 500436: Picture 4 thumbnail
Muxlab 500436: Picture 5 thumbnail
See all Muxlab items
CloseoutUsed Condition: Excellent

Used Muxlab 4K/60 HDMI to HDMI with Audio Extraction

SKU: US1382701 MFR: 500436
Be the first to review this item
$28.00
New: $134.95
Used Savings: $106.95 (79%)
Earn VIP Reward Points
See all Used options (1) from $28
Buy NEW from $135

Key Features

  • Enjoy seamless 4K UHD HDMI extension with this Muxlab extender, supporting resolutions up to 3840 x 2160.
  • Extract audio via Toslink or 3.5mm stereo jack, perfect for custom sound setups and enhanced audio fidelity.
  • Experience low latency and transparent transmission, ensuring your video and audio are always in sync.
  • This HDMI extender supports a broad compatibility with devices like DVD, Blu-Ray, PCs, and projectors.
  • Get stable connection with HDCP 2.2 revision, maintaining content protection for premium media playback.
  • This HDMI extender is a good value, offering high-quality performance and easy setup for your devices.
See More Product Details

INCLUDES FREE WARRANTY

  • This used item comes with a free 180-day warranty. ?
Calculate Shipping

See Options

1
Add to List

Protect your gear with Adorama Protect.* Learn more

1 Year

$2.99

2 Year

$5.99

3 Year

$7.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Muxlab 500436 Specifications

  • Environment

    HDMI 2.0

  • Devices

    DVD/Blu-Ray, plasma, projectors, monitors, TV, PC, laptops

  • Transmission

    Transparent to the user

  • Video Bandwidth

    18Gbps

  • Signals

    HDMI 2.0 protocol

  • Connectors

    HDMI Type A 19-pin female, Toslink & 3.5mm Stereo Jack

  • LEDs

    One (1) Power: Green
    One (1) Sync: Green

  • Resolution

    480i to 1080p @ 50/60 Hz
    1080p @ 24/50/60 Hz
    3840 X 2160 @ 24/25/30/50/60 Hz
    VGA to UXGA

  • Color

    8, 10 & 12 bit

  • Audio Format

    HDMI Output: LPCM 7.1CH, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-HD-Master Audio, and DTS:X
    Optical Output: LPCM, Dolby Digital, Dolby Digital Plus*, DTS, and Dolby Atmos digital audio via S/PDIF TosLink
    Stereo Output: 2CH analogue audio

  • Sampling Rate

    HDMI Output: 192 KHz
    Optical Output: 192 KHz
    Stereo Output: 48 KHz

  • HDCP

    Revision 2.2

  • Cables

    HDMI Cable
    Audio cables: Optical with TosLink and 2CH analog with 3.5mm connectors.

  • Temperature

    Operating: 32 Degree to 104 Degree F (0 Degree to 40 Degree C)
    Storage: -4 Degree to 140 Degree F (-20 Degree to 60 Degree C)
    Humidity: Up to 90% non-condensing

  • Enclosure

    Metal enclosure

  • Power Supply

    5VDC, 1A with interchangeable blade for US, UK and Euro

  • Compliance

    Regulatory: FCC, CE, RoHS

  • Dimensions

    2.83 x 2.36 x 1" (72 x 60 x 25mm)

  • Weight

    11.64 oz (330g)

About Muxlab 4K/60 HDMI to HDMI with Audio Extraction

The HDMI to HDMI with Audio Extraction, 4K/60 allows one (1) HDMI source to be distributed to one (1) HDMI display. The device supports up to 4K (3840 x 2160) video resolution at 60Hz, 8-bit color and HD audio. The unit extracts LPCM, Dolby Digital, DTS, Dolby Digital Plus and Atmos digital audio from the S/PDIF TosLink port and 2CH analog audio from the 3.5mm 2CH audio port. The product is HDCP 2.2 compliant and features LED diagnostics.

Applications:
Commercial and residential AV systems, classroom projector systems, digital signage, boardroom systems, collaborative PC systems.

Muxlab 4K/60 HDMI to HDMI with Audio Extraction Features

  • Allows one HDMI 2.0 source to be repeated and distributed to one HDMI display
  • HDMI supports 4K video at 60Hz, 8-bit color depth
  • HDMI supports LPCM 7.1CH, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-HD-Master Audio, and DTS:X
  • Extracts LPCM, Dolby Digital, Dolby Digital Plus, DTS, and Dolby Atmos digital audio via S/PDIF TosLink
  • Extracts 2CH analog audio via 3.5mm jack
