NewTek TriCaster Mini X HDMI Specifications

TriCaster Mini X HDMI

TriCaster Mini X HDMI

Jump to...
  • Network Video Input

    8x IP video inputs via NDI, resolution-independent

  • Digital Video Input

    4x HDMI video connections supporting video input in any combination of standard formats, resolutions, and frame rates
    2160p: 29.97, 25
    1080p: 59.94, 50, 29.97, 25
    1080i: 59.94, 50
    720p: 59.94, 50, 29.97, 25
    SD: 59.94, 50, 25

  • PTZ

    Support for up to 8 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422, and IP, with integrated controls and preset system

  • Skype TX

    Native support for up to 2 simultaneous Skype video call inputs via Skype TX software integration, including tally and Talk Back communication

  • Network Video Output

    IP video output via NDI, optionally configurable for:
    4x independent video mix outputs
    1x 4K UHD video mix output

  • Stream Output

    2x streaming video output, independently configurable, with simultaneous stream archive

  • Monitor Outputs

    4x mini display port with output adapters
    3x of the outputs support multiviewers using standard display resolutions

  • Mix/Effect Buses (M/E)

    4x M/E buses supporting video re-entry
    1x Mix/Effect channel per bus with support for up to 2 sources
    2x KEY layers per bus

  • DSK Channels

    2x DSK channels

  • Media

    5x Media Players (2x DDR, 2x GFX, 1x Sound)
    15x Media Buffers (10x Live Link or Animation Buffers, 5x Graphics Buffers)

  • Keyers

    Integrated LiveMatte chroma and luma keying technology on all source channels and M/E buses
    8x input keyers
    2x media player keyers
    4x M/E keyers
    15x buffer keyers

  • Virtual Sets

    Integrated LiveSet technology with 30+ live virtual sets and box effects included

  • DataLink

    Integrated DataLink technology enabling real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII and more

  • Macros

    Record, store, edit and automate commands and user-configured operation sequences
    Attach to control panel buttons, keyboard shortcuts, hotspots, MIDI and X-keys buttons or GPI triggers
    Attach to internal events and state changes, including audio, media playback, tally and specific switcher actions
    Supports control via web-based interface

  • Recording

    4x recording channels from either NDI inputs or Mix outputs
    Records and retains alpha channel data
    4x QuickTime archival video recorders (Native NDI Codec for recording)

  • Storage

    Capacity varies by format, resolution and file specification Supports recording to external storage via USB 3.0

  • Grab

    Grab full-resolution, deinterlaced still images from external video sources and outputs

  • Export

    Export video and image files to social media, FTP, local or external volumes, and network servers, with optional transcoding

  • Audio Mixing

    Integrated multi-channel audio mixer with support for stereo audio, and DSP's

  • Local Audio Input

    2x embedded digital audio inputs through HDMI conversion
    1x 1/4" (6.35 mm) balanced mic
    2x 1/4" (6.35 mm) balanced line

  • Local Audio Output

    2x embedded digital audio outputs through HDMI conversion
    2x 1/4" (6.35 mm) balanced line
    1x 1/4" (6.35 mm) stereo headphones jack

  • Network Audio

    Native support for network audio input and output via NDI
    Embedded audio supported for all NDI input and output video signals
    Integrated support for Dante networking protocol from Audinate

  • Supported Media File Formats

    Import, store, and play back multimedia files, with optional transcoding, including:
    Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more
    Image: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more
    Audio: AIFF, MP3, WAV, and more

  • Processing Video

    Floating Point YCbCr +A 4:4:4:4 Audio: Floating Point, 96 kHz

  • Latency

    Processing Latency: -1.0-1.5 frames
    Practical Throughput Latency: 4 frames

  • Tally

    Support for network tally via NDI

  • MIDI

    Support for standard MIDI protocol enabling third-party device control

  • NIC

    2x 1 Gigabit NIC

  • Dimensions

    4.23 x 9.08 x 7.89" (10.74 x 23.1 x 20.1cm) (Including adjustable handle and cable retention bracket)

  • Weight

    8.4 lbs (3.8kg)

TriCaster Mini Control Surface

Jump to...
  • Controls

    14x Backlit Buttons
    1x Multimode T-Bar

  • Connectors

    1x USB

  • Dimensions

    16.6 x 8 x 2.3" (42.1 x 20.3 x 5.7cm)

  • Weight

    4.6 lbs (2.1kg)

About NewTek TriCaster Mini X HDMI Bundle with TriCaster Mini Control Surface #1790148

Make your live productions sleek, stylish, and effortlessly professional with the TriCaster Mini X HDMI Bundle. This high-tech, user-friendly bundle is designed to give producers of all levels the freedom to create and share high-quality video content, from anywhere and at any time. Whether you're using a smartphone or a 4K camera, the TriCaster Mini X HDMI Bundle empowers you with the tools for software-defined visual storytelling.

The TriCaster Mini X HDMI Bundle unlocks the potential of professional live video production without the need for substantial infrastructure investments. Its flexibility is unparalleled, allowing you to connect off-the-shelf HDMI devices directly to the Mini X in minutes. This means you can create professional-level productions without the need to purchase additional equipment.

As part of the NewTek ecosystem of products, the TriCaster Mini X HDMI Bundle offers scalability to suit any production need. It's easy to set up and comes with hundreds of capabilities, putting expert tools at your fingertips without requiring you to be a production expert.

The bundle introduces TriCaster Live Link, a revolutionary tool that allows users to render web pages directly into the TriCaster and incorporate any web page elements into a production. Whether it's graphics, images, or videos from your organization's internal training platforms, Live Link offers unmatched production agility and freedom.

The TriCaster Mini X HDMI Bundle is designed to help you tell your story better than ever. It offers a range of tools, including video switching, media playback, virtual sets, and the ability to add graphics, record, and stream. It supports modern resolutions up to 4Kp30 and provides access to 8 external sources with 4 integrated HDMI inputs.

The bundle also includes the TriCaster Mini Control Surface, a portable, professional control for live productions of any size. It's the perfect traveling partner for the TriCaster Mini, providing studio-style control and a small footprint. This makes it an ideal solution for delivering professional results from the office, an event, or anywhere else.

In summary, the TriCaster Mini X HDMI Bundle is a durable, all-in-one desktop solution that continues the form factor of the TriCaster Mini with increased power and capabilities. It's everything you need and more, all in one place.

NewTek TriCaster Mini X HDMI Bundle with TriCaster Mini Control Surface #1790148 Features

  • TriCaster Mini X HDMI Features
  • Live Link - bringing the power of the internet directly into TriCaster
  • HD switching, streaming, and recording
  • 8 external video inputs and 4 mix outputs
  • Connect to compatible IP devices via NDI
  • Streaming to Facebook Live, Twitch, and more
  • Real-time social media publishing
  • Multi-channel recording and internal storage
  • Video playback without any additional hardware
  • Built-in live tilting and motion graphics
  • Multi-channel audio mixing
  • TriCaster Mini Control Surface Features
  • Intuitive layout mapped to the TriCaster Mini live desktop
  • Large, backlit buttons and premium T-Bar for confident, comfortable performance
  • Faster, more accurate interaction than point and click
  • Attractive, compact design and simple, plug-and-play setup

What's in the box:

  • NewTek TriCaster Mini X HDMI
  • TriCaster Mini Control Surface
  • Keyboard
  • Mouse
  • 4x Mini DisplayPort to HDMI Adapter
  • Power Cable
  • Custom Travel Case
