Used dB Technologies SUB 615 Active Bass-Reflex Subwoofer with 15" Woofer, 600W RMS Power

SKU: US1792065

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

dB Technologies SUB 615 Specifications

Speaker Type

Speaker Type

Jump to...
  • Speaker Type

    Active Subwoofer

Acoustical Data

Jump to...
  • Frequency Response [-10dB]

    42 - 124 Hz

  • Max SPL (1m)

    131 dB

  • Directivity

    Omnidirectional

  • LF

    15" (38.10cm)

  • LF Voice Coil

    2.5" (6.35cm)

Amplifier

Jump to...
  • Amp Technology

    SMSP digital amplifier

  • Amp Class

    Class D

  • RMS Power

    600W

  • Peak Power

    1200W

Processor

Jump to...
  • Controller

    28/56 bit DSP

  • Limiter

    Peak, Thermal, RMS

  • Controls

    Subwoofer level, Outputs mode, Polarity, Subwoofer mode

Input/Output

Jump to...
  • Signal Input

    2x XLR (balanced)

  • Signal Output

    2x XLR (balanced)

Mechanics

Jump to...
  • Housing

    Plywood

  • Grille

    Full Metal Grille

  • Handles

    2 on sides

  • Pole Mount

    M20

  • Dimensions (WxHxD)

    430 x 580 x 600mm (16.93 x 22.83 x 23.62")

  • Weight

    25.5kg (56.22 lbs)

About dB Technologies SUB 615 Active Bass-Reflex Subwoofer with 15" Woofer, 600W RMS Power

Before you settle on just any subwoofer, consider the SUB 615 Active Bass-Reflex Subwoofer, a powerful and high-quality audio equipment designed to deliver outstanding sound pressure levels. Despite its compact size, this subwoofer is capable of producing impressively precise low-end reproduction, making it an ideal choice for those seeking superior audio quality.

Engineered with a robust 15" transducer, the SUB 615 is an active subwoofer that features a 600W RMS Class D SMPS Power Amplifier. This innovative technology ensures that the system delivers unmatched sound pressure levels, reaching up to 131 dB, all while maintaining a clean and precise low-end reproduction.

The SUB 615 Active Bass-Reflex Subwoofer stands out with its ability to build most of the PA systems with just a single sub and two full-range speakers. This eliminates the need for any external processing or crossover, thanks to a balanced X-Over signal to left and right speakers. The amp panel controls allow users to operate with Mono or Stereo audio feed, activate polarity inversion, and choose Outputs link mode (True Bypass or X-Over).

For those moments when you need an extra punch, the SUB 615 offers a low-frequencies boost EQ setting through the Sub Mode switch. This feature allows you to customize your audio experience to suit your preferences.

The SUB 615 is not just about performance; it also boasts a sleek design. It comes with a full grille design housed in a lightweight wood cabinet that weighs just 56.22 lbs. The cabinet is strengthened with a hardwearing, scratch-resistant black covering, ensuring its durability. For ease of transport, the subwoofer is equipped with side handles. The top side design facilitates easy stacking for larger systems and features a M20 pole mount thread to stack full-range speakers.

In conclusion, the SUB 615 Active Bass-Reflex Subwoofer with 15" Woofer and 600W RMS Power is a reliable, durable, and innovative choice for those seeking superior sound quality and functionality in their audio equipment.

dB Technologies SUB 615 Active Bass-Reflex Subwoofer with 15" Woofer, 600W RMS Power Features

  • 600W RMS Class-D Amplifier
  • Selectable Stereo Balanced Input
  • LINK or X-Over balanced stereo output mode
  • Compact and sturdy wood cabinet
  • Lightweight
  • Polarity Switch
  • FLAT or BOOST Mode Switch

What's in the box:

  • dB Technologies SUB 615 Active Bass-Reflex Subwoofer
  • VDE Power Cable
