Edirol/Roland R-26 6-Channel Digital Field Audio Recorder
Edirol/Roland R-26: Picture 1 thumbnail
Edirol/Roland R-26: Picture 2 thumbnail
Edirol/Roland R-26: Picture 3 thumbnail
Edirol/Roland R-26: Picture 4 thumbnail
Edirol/Roland R-26: Picture 5 thumbnail
Edirol/Roland R-26: Picture 6 thumbnail
Edirol/Roland R-26: Picture 7 thumbnail
Edirol/Roland R-26: Picture 8 thumbnail
Edirol/Roland R-26: Picture 9 thumbnail
Edirol/Roland R-26: Picture 10 thumbnail
Edirol/Roland R-26: Picture 11 thumbnail
See all Edirol/Roland items
Used Condition: Excellent

Used Edirol/Roland R-26 6-Channel Digital Field Audio Recorder

SKU: US1959977 MFR: R-26
(2)
$271.00
OR
$46/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points
See all Used options (2) from $271

Key Features

  • Compact design ideal for professional applications
  • 6-Channel Recording
  • 2 Types of Built-in Mics
  • External Mic Inputs
  • Ultimate Flexibility
  • Multiple File Types
See More Product Details

INCLUDES FREE WARRANTY

  • This used item comes with a free 90-day warranty. ?
Free Shipping

See Options

1
Add to List

Need help? Ask our experts.

Overview
Compare
Learn
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

2016-09-26T08:36:12

Rated 3 out of 5

This and the Tascam DR-100 are highly similar recorders

This and the Tascam DR-100 are highly similar recorders. Some of the few differences are important in actual use: Roland: 4 AA batteries Tascam: 2 AAs and/or a rechargeable Li-Ion battery Roland: no locking XLR connectors Tascam: locking XLR connectors Boom.

ACCOUNTS P.

2013-03-16T21:00:00

Rated 4 out of 5

Portable goodness

I like the fact that there are some external controls...dials and such, but I still find that there is a level of complexity to dig through layers of menues to adujust sensitivity and gain on seperate channels as well as to montitor each on seperate. Given this, it is probably the best portable unit there is out to date and a musician on the run who wants to get down some good sounding tracks or the dslr vidographer that needs a lightwietght extermal audio mixer will be pleased once they acustomize themselves with it.

Richard

Edirol/Roland R-26 Specifications

  • Tracks

    6 (3 stereo)

  • Signal Processing

    AD/DA conversion: 24 bits, 96/88.2/48/44.1 kHz

  • Data Type

    For Recording
    WAVE/BWF: Sampling Rate: 96/88.2/48/44.1 kHz, Bit Depth: 24/16 bits
    MP3 (MPEG-1 Audio Layer 3): Sampling Rate: 48/44.1 kHz, Bit Rates: 320/160/128 kbps
    WAVE + MP3: Sampling Rate: 48/44.1 kHz, Bit Depth: 16 bits, Bit Rates: 128 kbps
    For Playback
    WAVE: Sampling Rate: 96/88.2/48/44.1 kHz, Bit Depth: 24/16 bits
    MP3 (MPEG-1 Audio Layer 3): Sampling Rate: 48/44.1 kHz, Bit Rates: 32-320 kbps or VBR (Variable Bit Rate)

  • Memory Card

    SD Card (SDHC format compatible)

  • Recording Time

    Each recording time is approximate. The times may change depending on the card specifications.
    In case that there are plural files, the sum of recording time would be shorter than above.

  • Audio Inputs

    Internal Stereo Microphones: Omnidirectional (OMNI) mic, Directional (XY) mic
    Analog inputs 1/L, 2/R (XLR/TRS Combo type): XLR type (phantom powered), 1/4-inch TRS phone type (balanced/unbalanced)
    Plug-in powered mic input (Stereo miniature phone type)

  • Audio Output

    Headphone jack (Stereo miniature phone type)

  • Nominal Input Level (Variable)

    Analog inputs 1/L, 2/R:+4, -2, -8, -14, -20, -26, -32, -38, -44, -50, -56, -62 dBu
    Plug-in powered mic input: LOW -7.5 dBu, MID -21 dBu, HIGH -26 dBu

  • Input Impedance

    Analog inputs 1/L, 2/R: 5k ohms
    Plug-in powered mic input: 3k ohms (SENS = MID/HIGH), 2k ohms (SENS = LOW)

  • Maximum Input

    Analog inputs 1/L, 2/R: +24 dBu (SENS = +4 dBu)
    Plug-in powered mic input: +4 dBu (SENS = LOW)

  • Output Level

    35 mW + 35 mW (In case 16 ohms load)

  • Recommended Load Impedance

    16 ohms or greater

  • Frequency Response

    16 ohms or greater

  • Phantom Power

    48 V + or - 4 V
    10 mA or less in all channels

  • USB Interface

    Mini-B type connector
    USB mass storage device class
    USB audio (Hi-Speed USB)

  • Display

    160 x 160 dots graphic display (touch screen)

  • Power Supply

    AC adaptor
    Alkaline battery (AA, LR6) x 4
    or Rechargeable Ni-MH battery (AA, HR6) X 4

  • Current Draw

    500 mA (MAX)

  • Dimensions (W x D x H)

    82 x 180 x 41mm(8.2 x 7 x 1.6in)

  • Weight

    370 g (14 oz.)

Related Articles & Videos

Capturing Cinematic Weddings Workshop: Best Audio Practices

Capturing Cinematic Weddings Workshop: Best Audio Practices

Ray Roman of Capture Cinematic Weddings Workshop Series, provides in-depth techniques and valuable instruction to help you achieve the Best Audio Practices...

Read more

About Edirol/Roland R-26 6-Channel Digital Field Audio Recorder

The R-26 6-Channel Digital Field Audio Recorder from Roland provides a wealth of flexibility in a compact design, ideal for a variety of professional applications in music, filmmaking, journalism and more. The R-26 can simultaneously capture up to 6 tracks of audio as 3 stereo pairs. The recorder offers 2 types of built-in stereo mics; one omnidirectional and one directional. There are also 2 XLR/TRS combo inputs with 48V phantom power for external mics and a 3.5mm mic input for small stereo mics with plug-in power. The built-in mics can be used in a variety of combinations alongside external mics for amazing recording versatility.

The R-26 captures high-quality WAV/BWF files at rates up to 24-bit/96kHz. It can also capture MP3 files at rates up to 320kbps. Files are written to widely-available SD/SDHC flash memory cards for convenience and stability. A high-speed USB port allows you to transfer your recordings to a Mac or PC for convenient editing and sharing. SONAR LE software is included for manipulating your audio on a Windows PC.

The R-26 has a large touchscreen LCD display for quick and intuitive navigation of menus, customizing mic settings, editing waveforms and more. There are also large input level control knobs for making fine adjustments. The recorder can operate on 4 standard AA batteries, or via the included AC adapter. An SD card, USB cable and windscreen are also included so you can start using the recorder right out of the box.

Edirol/Roland R-26 6-Channel Digital Field Audio Recorder Features

  • Compact Design: The compact design is ideal for a variety of professional applications in music, filmmaking, journalism and more
  • 6-Channel Recording: The integrated stereo mics and Roland's unique DSP engine allow simultaneous recording of up to 6 channels as 3 stereo pairs
  • 2 Types of Built-in Mics: There is an omnidirectional stereo mic and a directional stereo mic. The mics can be combined in various ways to create a variety of patterns
  • External Mic Inputs: There are 2 XLR/TRS combo inputs with 48V phantom power for external mics and a 3.5mm mic input for small stereo mics with plug-in power
  • Ultimate Flexibility: You can capture different signals simultaneously, or capture the same source with 3 different types of mics. This allows you to choose individual tracks or composite mixes later on to suit your needs
  • Multiple File Types: The R-26 captures high-quality WAV/BWF files at rates up to 24-bit/96kHz. It can also capture MP3 files at rates up to 320kbps
  • SD/SDHC Media: Files are written to widely-available SD/SDHC flash memory cards for convenience and stability
  • High-Speed USB: A high-speed USB port allows you to transfer your recordings to a Mac/PC for convenient editing and sharing. You can also use the recorder with your computer as a live audio interface or for external storage. SONAR LE software is included for manipulating your audio on a Windows PC
  • Loop-Back Function: When using the R-26 as an audio interface, you can enable the Loop-Back function with the built-in mics or external mics to create a live video streaming setup
  • Intuitive Interface: The R-26 has a large touchscreen LCD display for quick and intuitive navigation of menus, customizing mic settings, editing waveforms and more. There are also large input level control knobs for making fine adjustments
  • Power Options: The recorder can operate on 4 standard AA batteries, or via the included AC adapter
