Atomos 4.3" Ninja 2 Video Recorder (Bare Bones Version) Bundle - SKU#1846396

Picture does not represent the actual item

See all Atomos items

Used Atomos 4.3" Ninja 2 Video Recorder (Bare Bones Version) Bundle

SKU: US1846396
(4)

This item is no longer available.

Recommended Items

undefined undefined: Picture 1 regular
Atomos CONNECT Network, Wireless & SDI Expansion for NINJA V/V+
undefined undefined: Picture 1 regular
Used Atomos Sumo 19" Touchscreen On-Set and In-Studio 4K HDR Monitor Recorder, 1920x1200
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Atomos Ninja 2 Specifications

  • Compatibility

    DSLRs and Cameras

  • Input

    Video input:
    Uncompressed 10/8-bit 4:2:2
    HDMI 1.4

    Audio input:
    2 channels on HDMI video input
    2 analog channels with gain controls

  • Output

    Video output:
    HDMI 1.4 (reclocked, ultra low jitter)

    Audio output:
    2 channels on HDMI video output
    Stereo
    Headphone

  • Supported Formats

    HD 1080i60, 1080i59.94, 1080i50, 1080p30, 1080p25, 1080p24, 1080p23.98, 1080p30(60i), 1080p25(50i), 1080p24(60i), 1080p23.98(60i), 720p60, 720p59.94, 20p50, SD 480i, 576i

  • Encoding

    Real-time hardware encoding, 1920 x 1080 8/10-bit 4:2:2 to:

    Apple ProRes:
    HQ - 220Mbps (10-bit)
    422 - 150Mbps (10-bit)
    LT - 100Mbps (10-bit)

    Avid DNxHD:
    Avid DNxHD-220X - 220Mbps (10-bit)
    Avid DNxHD-220 - 36 Mbps (8-bit)
    Avid DNxHD-145 - 36 Mbps (8-bit)

  • Screen size

    4.3" / 10.92cm diagonal

  • Screen Resolution

    800 x 480

  • Screen Aspect ratio

    16:9 native / 4:3 letterbox / SMPTE color specification

  • Screen Native frame rate playback

    48-60Hz

  • Remote Start / Stop

    HDMI start/stop flags (Canon compatible)
    LANC trigger via optional LANC adapter

  • Customizable Remote Controls

    (control all Ninja functions): System integrator custom controls available on request from ATOMOS

  • Timecode

    Sony and Canon compatible HDMI timecode in and out

  • Recording Time

    Records for the same amount of time whether onto HDDs or SSDs
    Edit formats: I-frame only, 422, 8/10-bit
    ProRes HQ (10-bit, 220Mbps): 250GB = 2.5 hrs, 500GB = 5 hrs, 1TB = 10 hrs
    Avid DNxHD-220x (10 bit, 220Mbps): 250GB = 2.5 hrs, 500GB = 5 hrs, 1TB = 10 hrs

  • Recording Time 1

    ProRes 422 (10 bit, 150Mbps): 250GB = 4 hrs, 500GB = 8 hrs, 1TB = 16 hrs
    Avid DNxHD-145 (8 bit, 145Mbps): 250GB = 4 hrs, 500GB = 8 hrs, 1TB = 16 hrs
    ProRes LT (10 bit, 100Mbps): 250GB = 5.5 hrs, 500GB = 11 hrs, 1TB = 22 hrs

  • Operating Power

    Monitoring: 3W
    Rec, Mon & Play: 6W

  • Batteries

    All 7.4V
    7.2V - 14.4V battery system compatible: 2600mAh - up to 10 hours
    Any source: 5200mAh - up to 20 hours
    NP series: 7800mAh - up to 30 hours
    DTap: AC power via adapter plate (option)
    Supporting accessories: DTap dummy battery (cables sold separately)

  • Continuous Power

    Primary-secondary battery system Change batteries without losing power Loop batteries continuously

  • Construction

    Aircraft grade aluminum Fanless for silent operation

  • Dimensions (W x H x D)

    4.5 x 3.4 x 1.6" / 11.43 x 8.64 x 4.06cm

  • Weight

    Without batteries and HDD: 0.8lbs / 0.36kg
    With batteries and HDD: 1.48lbs / 0.67kg

About Atomos 4.3" Ninja 2 Video Recorder (Bare Bones Version) Bundle - SKU#1846396

Ninja 2
Capture Apple ProRes or AVID DNxHD from HDMI Cameras direct to affordable SSD/HDD for long record times all at brocast quantity.

Record From Any Hdmi Device
Open up Apple ProRes and Avid DNxHD post production quality to thousands of devices (cameras, projectors, tablets, phones, game consoles, medical and industrial equipment).

Record From The Sensor, Assassinate Mpeg
Take your consumer camera to a truly Pro recording device. Avoid the internal MPEG compression & go from sub 30Mbps MPEG to 220Mbps ready to edit 10-bit 422 Apple ProRes HQ.

No More 30min Barrier!
Recording straight out from the sensor means no more 29.59 minute record limits on your internal recordings. Whether you're filming a soccer match or birds in the wild there is no need to worry about your recording stopping at 29.59 minutes.

Low Cost Media & Long Record Times
Record to standard 2.5" HDDs and SSDs. A 1TB HDD gives you 10+ hours of Apple ProRes HQ. Buy your choice of media that is affordable, reliable and readily available.

Used Guarantee

30-day money back!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Atomos 4.3" Ninja 2 Video Recorder with Touch Screen LCD
  • 3x Master Caddies
  • Hard Carry Case
  • D-TAP Battery Eliminator
  • SSD Reader with power cable
  • Item Note: Missing 9V AC Battery Eliminator; Sunhood; Battery Charger
