Used Blackmagic Design HyperDeck Extreme Control

SKU: US1901665 MFR: HYPERD/RSTEXCTR
Earn VIP Reward Points

Key Features

  • Enhance live production workflows with seamless RS-422 deck control outputs.
  • Achieve perfect sync with Tri-Sync or Black Burst reference input/output.
  • Enjoy versatile connectivity via 1 Gb/s Ethernet for smooth network integration.
  • Update software effortlessly using the convenient USB-C computer interface.
  • Easily monitor timecode with the bright, clear 8-digit LED display.
  • Integrate into any rack setup; this unit is 3U height, half rack width.
See More Product Details

INCLUDES FREE WARRANTY

  • This used item comes with a free 180-day warranty. ?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$103.99

3 Year

$161.99

4 Year

$220.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Blackmagic Design HyperDeck Extreme Control Specifications

Connections

Connections

Jump to...
  • Deck Control Outputs

    8x RS-422

  • Reference Input

    Tri-Sync or Black Burst

  • Reference Output

    Follows reference input

  • Ethernet

    1Gb/s

  • Computer Interface

    1x USB-C for software updates

Supported Protocols

Jump to...
  • Control Protocols

    Sony

Software

Jump to...
  • Internal Software Upgrade

    Loaded at system start, or via Blackmagic HyperDeck Setup using USB port

Operating Systems

Jump to...
  • Mac

    Mac 10.13 High Sierra, Mac 10.14 Mojave or later

  • Windows

    Windows 8.1 or Windows 10

Displays

Jump to...
  • Displays

    8 digit, 7 segment LED timecode display

Power Requirements

Jump to...
  • Power Supply

    1x Internal 100 - 240V AC
    1x 4 pin XLR 12V DC IN for external power or battery use

Physical Installation

Jump to...
  • Physical Installation

    3 rack units height, half rack width

Environmental

Jump to...
  • Operating Temperature

    0 to 40 deg. C (32 to 104 deg. F)

  • Relative Humidity

    0% to 90% non-condensing

  • Storage Temperature

    -20 to 60 deg. C (-4 to 140 deg. F)

General

Jump to...
  • Dimensions

    8.28 x 5.14 x 13.83" (21.03 x 13.06 x 35.13cm)

  • Weight

    3.53 lbs (1.60kg)

About Blackmagic Design HyperDeck Extreme Control

Blackmagic Design HyperDeck Extreme Control

Control and edit various types of footage with the new Blackmagic Design HyperDeck Extreme Control. The HyperDeck Extreme Control comes with traditional deck controls for various deck types due to its RS-422 connectivity, along with eight RS-422 ports that enable you to control up to eight decks including the HyperDeck Extreme 8K HDR. All eight of the RS-422 controls have been tested to ensure their compatibility with various legacy broadcast decks like the BVH-2000 series 1 inch C format machines, Betacam SP, D2, and Digital Betacam to name a few. It has a built-in editor which enables seamless deck-to-deck editing. It also has a high-quality search dial which has both jog and shuttle control for easier navigation. Its large timecode display indicates the timecode of the currently selected deck, allowing you to monitor and manage multiple decks easily. Edit various types of media seamlessly all in one interface using the HyperDeck Extreme Control from Blackmagic Design.

From the sophisticated design to the advanced functionality, the HyperDeck Extreme Control is a professional-grade solution for those seeking high-quality and innovative audio/video mixing capabilities. This device not only offers traditional deck control features but also integrates a built-in editor, streamlining the automation of ingesting legacy videotape-based programming. When paired with the HyperDeck Extreme, users experience a seamless and efficient editing workflow that is both familiar and cutting-edge.

The HyperDeck Extreme Control boasts a comprehensive array of transport control buttons, including rewind, fast forward, stop, play, and record, complemented by a timecode display and deck status indicators. The large search dial, complete with an electronic clutch, facilitates precise jog, shuttle, and positioning functions, enhancing the user's control over their media.

One of the standout features of this device is its ability to control up to 8 separate decks via standard RS-422 connections, ensuring compatibility with a wide range of deck types, including legacy broadcast decks like the BVH-2000 series and Betacam SP. This multi-deck capability is made possible through a built-in remote control router and 8 rear-mounted RS-422 sockets, offering unparalleled versatility in a professional setting.

Editing between different video standards is a breeze with the HyperDeck Extreme Control. Users can effortlessly up-convert old 4:3 interlaced SD masters to crisp 1080p HD in a 16:9 aspect ratio using an inline Teranex Express converter. This feature is particularly beneficial for content creators who need to deliver 1080p24 masters for streaming services, as the device can de-interlace, up-convert, aspect ratio convert, and remove pulldown during the editing process.

The familiar broadcast VTR-style design of the transport controls adds an element of elegance and ease of use. Recording is safeguarded by requiring simultaneous pressing of the REC and PLAY buttons, and the innovative search dial supports rapid movement through recordings with its twin bearings for fast jog capabilities.

For editors, the HyperDeck Extreme Control offers flexible in and out point entry, with the ability to display edit points on the time counter display and trim edit points by single frames. The pre-roll feature ensures that decks are cued accurately, with the option to cue to specific locations set via the IN or OUT points.

In summary, the HyperDeck Extreme Control is a sophisticated, professional, and advanced tool that caters to the needs of modern video production. Its high-quality construction and innovative features make it a top choice for professionals who require a versatile and reliable audio/video mixer for their projects.

Blackmagic Design HyperDeck Extreme Control Features

  • Advanced audio/video mixer with built-in editor for automating ingest of legacy videotape-based programming
  • Features traditional deck control buttons, timecode display, deck status indicators, and a large search dial for precise jog, shuttle, and positioning
  • Capable of controlling up to 8 separate decks using standard RS-422 connections, ensuring compatibility with a wide range of deck types
  • Allows editing between different video standards, including up-conversion of old 4:3 interlaced SD masters to 1080p HD in 16:9
  • Familiar broadcast VTR-style design with safeguarded recording requiring simultaneous pressing of REC and PLAY buttons
  • Offers flexible in and out point entry for editing, with pre-roll feature for accurate deck cueing

Warranty Information

This used item has a FREE 180-day warranty. See details.
