Review Summary
2023-08-29T06:20:48
Amazing Cameras. However, the viewfinder on one of them quit working after 6 months of use.
ACCOUNTS P.
2021-12-22T07:29:12
It?s great performance.
PANHARITH H.
2021-12-19T16:04:57
it's pretty much everything i expected a broadcast camera to be just with the added feature of being able to shoot in a higher resolution. having the ef mount was nice because i could at least get it up and running with my current lenses while i save up money for the fujinon b4 lens
STEVEN B.
Black
3x 1/4"-20 Female (Bottom)
1x ARRI/Hirth Rosette
32 to 104°F / 0 to 40°C up to 90% Humidity
-4 to 113°F / -20 to 45°C
13 Stops
Magnesium Alloy
100 W
2/3 inch sensor size when using 4K B4 mount (Actual sensor size 23.10mm x 12.99mm)
Electronic control via 12-pin broadcast connector. Control via EF mount pins when using URSA Mini Pro EF Mount with compatible EF lenses.
Touchscreen menus on 4 inch screen. Push buttons for other controls. 3 assignable shortcut keys and 2 assignable shortcut keys (VTR and RET) on compatible broadcast lenses.
1x 12-pin Hirose Broadcast Lens Connector
1x USB Type-C 3.1 Gen 2 with power delivery for external drive recording and connecting Blackmagic Focus and Zoom Demand. 1x USB Type-C for software updates.
Can format media to ExFAT for Windows and Mac or HFS+ for Mac (file systems).
Mac 10.15 Catalina, Mac 11.1 Big Sur or later.
Windows 10, 64-bit.
0% to 90% non-condensing
B4 2/3 inch installed
Active EF mount also included
Yes
23.1 x 12.99 mm (2/3"-Type) CMOS
No
Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Stills & Video
Electronic Rolling Shutter
Native: 400 to 3200 (100 to 25,600 Extended)
Gain: -6 to 18 Db
13 Stops
Automatic, Manual Focus
Blackmagic RAW 10-Bit
6144 x 3456 up to 50 fps (65 to 483 Mb/s)
3728 x 3104 up to 59.94 fps (36 to 265 Mb/s)
6144 x 2560 up to 59.94 fps (49 to 359 Mb/s)
3840 x 2160 up to 59.94 fps (32 to 190 Mb/s)
1920 x 1080 up to 150 fps (5.2 to 47 Mb/s)
H.265
3840 x 2160 up to 59.94 fps3.2 to 7.8 Mb/s)
ProRes 422/ProRes 422 HQ
3840 x 2160 up to 59.94 fps (73.6 to 110 Mb/s)
1920 x 1080p up to 59.94 fps (18.4 to 27.5 Mb/s)
1920 x 1080p up to 120 fps (18.4 to 27.5 Mb/s)
H.26
Yes
Stereo
ProRes: 2-Channel, 24-Bit at 48 kHz
Dual Slot: SD/SDHC/SDXC (UHS-II)
Dual Slot: CFast (CFast 2.0)
No
1x BNC (12G-SDI) Output
1x BNC (12G-SDI) Input
1x BNC (12G-SDI) Output
2x XLR 3-Pin Mic/Line Input on Camera Body (+48 V Phantom Power)
1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Input/Output on Camera Body
1x XLR 4-Pin Input
1x XLR 4-Pin (12 to 20VDC) Output
1x Molex 12-Pin Input
1x USB-C (USB 3.2 / 3.1 Gen 2) (Shared with Video Output)
1x USB-C Data Input
1x 2.5 mm Sub-Mini (LANC) Control Output
1x BNC (Reference, Sync, Timecode) Data Input
1x Hirose 12-Pin (Camera Interface) Control Output
Bluetooth
Yes: iPadOS Only
App Name: Blackmagic Camera Control App
No
Primary Monitor: Articulating 4" Touchscreen LCDStatus Display: Fixed Non-Touchscreen LCD
V-Mount
Required, included
Lithium-ion
Non-universal
1
21 x 10 x 7" / 53.3 x 25.4 x 17.8 cm
11.02 lb / 5.00 kg (Body Only)












Great camera for sports!
By ACCOUNTS P.
Amazing Cameras. However, the viewfinder on one of them quit working after 6 months of use.
Like it
By PANHARITH H.
It?s great performance.
