DJI Mini 3 Pro Specifications

Aircraft

Aircraft

Jump to...
  • Takeoff Weight

    < 8.78 oz (249g)

  • Diagonal Length

    9.72" (247mm)

  • Max Ascent Speed

    5 m/s (S Mode)
    3 m/s (N Mode)
    2 m/s (C Mode)

  • Max Descent Speed

    5 m/s (S Mode)
    3 m/s (N Mode)
    1.5 m/s (C Mode)

  • Max Speed (at sea level, no wind)

    16 m/s (S Mode)
    10 m/s (N Mode)
    6 m/s (C Mode)

  • Max Service Ceiling Above Sea Level

    With Intelligent Flight Battery: 13123.36' (4000m)
    With Intelligent Flight Battery Plus: 9842.52' (3000m)

  • Max Flight Time

    34 mins (with Intelligent Flight Battery and measured while flying at 21.6 kph in windless conditions)
    47 mins (with Intelligent Flight Battery Plus and measured while flying at 21.6 kph in windless conditions)

  • Max Hovering Time

    30 mins (with Intelligent Flight Battery, no wind)
    40 mins (with Intelligent Flight Battery Plus, no wind)

  • Max Flight Distance

    18 km (with Intelligent Flight Battery and measured while flying at 43.2 kph in windless conditions)
    25 km (with Intelligent Flight Battery Plus and measured while flying at 43.2 kph in windless conditions)

  • Max Wind Speed Resistance

    10.7 m/s (Level 5)

  • Max Tilt Angle

    Forward: 40 Degree , Backward: 35 Degree (S Mode)
    25 Degree (N Mode)
    25 Degree (C Mode)

  • Max Angular Velocity

    130 Degree /s (S Mode)
    75 Degree /s (N Mode)
    30 Degree /s (C Mode)

  • Operating Temperature

    32 Degree to 104 Degree F (0 Degree to 40 Degree C)

  • Global Navigation Satellite (GNSS)

    GPS + Galileo + BeiDou

  • Operation Frequency

    2.400-2.4835 GHz
    5.725-5.850 GHz

  • Transmitter Power (EIRP)

    2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
    5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)

  • Hovering Accuracy Range

    Vertical:
    +/-0.1 m (with vision positioning)
    +/-0.5 m (with GPS positioning)

    Horizontal:
    +/-0.3 m (with vision positioning)
    +/-0.5 m (with high-precision positioning system)

Sensing System

Jump to...
  • Forward

    Precision Measurement Range: 1.27-82.02' (0.39-25m)
    Effective Sensing Speed: Flight speed <10 m/s
    FOV: Horizontal 106 Degree , Vertical 90 Degree

  • Backward

    Precision Measurement Range: 1.18-76.77' (0.36-23.4m)
    Effective Sensing Speed: Flight speed <10 m/s
    FOV: Horizontal 58 Degree , Vertical 73 Degree

  • Downward

    ToF Effective Measurement Height: 0.32-26.2' (0.1-8m)
    Precise Hovering Range: 1.64-39.37' (0.5-12m)
    Vision Sensor Hovering Range: 1.64-98.42' (0.5-30m)

  • Auxiliary Bottom Light

    No

  • Operating Environment

    Diffuse reflective surface with a clear pattern and reflectivity >20% (such as cement pavement)
    Adequate lighting (lux >15, e.g. normal exposure environment with indoor fluorescent lamp)

  • Mechanical Range

    Tilt: -135 Degree to 80 Degree
    Roll: -135 Degree to 45 Degree
    Pan: -30 Degree to 30 Degree

  • Controllable Range

    Tilt: -90 Degree to 60 Degree

  • Stabilization

    3-axis mechanical gimbal (tilt, roll, and pan)

  • Max Control Speed (tilt)

    100 Degree /s

  • Angular Vibration Range

    +/-0.01 Degree

  • Sensor

    1/1.3" CMOS
    Effective Pixels: 48 MP

  • Lens

    FOV: 82.1 Degree
    Format Equivalent: 24 mm
    Aperture: f/1.7
    Focus Range: 1 m to Infinite

  • ISO Range

    Video:
    100-6400 (Auto)
    100-6400 (Manual)

    Photo:
    100-6400 (Auto)
    100-6400 (Manual)

  • Shutter Speed

    Electronic Shutter: 2-1/8000 s

  • Max Image Size

    4:3:
    8064 x6048 (48 MP)
    4032 x3024 (12 MP)

    16:9: 4032 x2268 (12 MP)

  • Still Photography Modes

    Single Shot

    Interval:
    JPEG: 2/3/5/7/10/15/20/30/60 s
    JPEG + RAW: 2/3/5/7/10/15/20/30/60 s

    Auto Exposure Bracketing (AEB): 3/5/7 bracketed frames at 2/3 EV Bias

    Panorama: Sphere, 180 Degree , Wide-angle, and Vertical

  • Photo Format

    JPEG/DNG (RAW)

  • Video Resolution

    4K: 3840 x2160@24/25/30/48/50/60fps
    2.7K: 2720 x1530@24/25/30/48/50/60fps
    FHD: 1920 x1080@24/25/30/48/50/60fps
    Slow Motion: 1920 x1080@120fps

  • Video Format

    MP4/MOV (H.264/H.265)

  • Max Video Bitrate

    150 Mbps

  • Zoom Range

    4K: 2x
    2.7K: 3x
    FHD: 4x

  • QuickShot Modes

    Dronie, Helix, Rocket, Circle, Boomerang, and Asteroid

  • Color Profiles

    Normal
    D-Cinelike

  • Supported File System

    FAT32 (<=32 GB)
    exFAT (>32 GB)

Video Transmission

Jump to...
  • Video Transmission System

    DJI O3

  • Live View Quality

    1080p/30fps

  • Operation Frequency

    2.400-2.4835 GHz
    5.725-5.850 GHz

  • Communication Bandwidth

    1.4MHz/3MHz/10MHz/20MHz/40MHz

  • Latency

    Aircraft + Remote Controller: Approx. 120 ms (depending on environmental conditions and mobile device)

  • Max Video Bitrate

    Aircraft + Remote Controller: 18 Mbps

  • Max Download Bitrate

    DJI O3:
    RC-N1 Remote Controller and DJI RC: 5.5 MB/s

    Wi-Fi 5:
    Max 30 MB/s

  • Signal Transmission Ranges (FCC)

    Strong Interference (urban landscape): Approx. 1-3 km
    Medium Interference (suburban landscape): Approx. 6 km
    Low Interference (suburb/seaside): Approx. 12 km

  • Antennas

    4 antennas, 2T4R

  • Audio Transmission

    No

Intelligent Flight Battery

Jump to...
  • Capacity

    2453 mAh

  • Voltage

    7.38 V

  • Charging Voltage Limit

    8.5 V

  • Battery

    LiPo 2S

  • Energy

    18.1 Wh

  • Max Charging Power

    37 W

  • Charging Time

    64 mins (with 30W charger)

  • Charging Temperature Range

    41 Degree to 104 Degree F (5 Degree to 40 Degree C)

  • Recommended Charger

    DJI 30W USB-C Charger
    or other USB Power Delivery chargers

  • Battery Info

    Required, included

  • Battery Material

    Lithium-ion

  • Battery Type

    Non universal

  • Battery Quantity

    1

  • Weight

    2.83 oz (80.5g)

Memory Cards

Jump to...
  • Supported Memory Cards

    UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below.

  • Recommended microSD Cards

    SanDisk Extreme 64GB V30 A1 microSDXC
    SanDisk Extreme 128GB V30 A2 microSDXC
    SanDisk Extreme 256GB V30 A2 microSDXC
    SanDisk Extreme 512GB V30 A2 microSDXC
    SanDisk Extreme Pro 64GB V30 A2 microSDXC
    SanDisk Extreme Pro 256GB V30 A2 microSDXC
    SanDisk Extreme Pro 400GB V30 A2 microSDXC
    SanDisk High Endurance 64GB V30 microSDXC
    SanDisk High Endurance 256GB V30 microSDXC

  • Recommended microSD Cards (Contd.)

    SanDisk Max Endurance 32GB V30 microSDHC
    SanDisk Max Endurance 128GB V30 microSDXC
    SanDisk Max Endurance 256GB V30 microSDXC
    Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
    Kingston Canvas Go! Plus 256GB V30 A2 microSDXC
    Lexar High Endurance 64GB V30 microSDXC
    Lexar High Endurance 128GB V30 microSDXC
    Lexar 667x 64GB V30 A1 microSDXC

  • Recommended microSD Cards (Contd..)

    Lexar 633x 256GB V30 A1 microSDXC
    Lexar 1066x 64GB V30 A2 microSDXC
    Lexar 1066x 128GB V30 A2 microSDXC
    Lexar 1066x 256GB V30 A2 microSDXC
    Samsung Pro Plus 128GB V30 A2 microSDXC
    Samsung EVO Plus 512GB microSDXC

  • Protocol

    802.11 a/b/g/n

  • Transmitter Power (EIRP)

    2.400-2.4835 GHz: <23 dBm (FCC), <20 dBm (CE/SRRC/MIC)
    5.150-5.250 GHz: <23 dBm (FCC/CE/SRRC/MIC)
    5.725-5.850 GHz: <23 dBm (FCC/SRRC), <14 dBm (CE)

Bluetooth

Jump to...
  • Protocol

    Bluetooth 4.2

  • Transmitter Power (EIRP)

    2.400-2.4835 GHz: <10 dBm

  • Mobile Device App

    DJI Fly

  • Required Operating System

    iOS v11.0 or later
    Android v6.0 or later

RC-N1 Remote Controller

Jump to...
  • Transmitter Power (EIRP)

    2.400-2.4835 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
    5.725-5.850 GHz: <26 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE)

  • Max Supported Mobile Device Size

    7.08 x 3.38 x 0.39" (180 x 86 x 10mm) (L x W x H)

  • Supported Port Types

    Lightning, Micro-USB (Type-B), USB-C

  • Video Transmission System

    DJI O3

  • Max Battery Time

    6 hrs (without charging any mobile device)
    4 hrs (when charging a mobile device)

  • Operating Temperature

    -10 Degree to 40 Degree C (14 Degree to 104 Degree F)

Physical

Jump to...
  • Dimensions (L x W x H)

    Folded: 5.7 x 3.54 x 2.44" (145 x 90 x 62mm)
    Unfolded: 6.73 x 9.64 x 2.44" (171 x 245 x 62mm)
    Unfolded (with propellers): 9.88 x 14.2 x 2.75" (251 x 362 x 70mm)

16 Accessories for DJI Mini 3 Pro Drone with RC-N1 Remote Controller

  • All Accessories (16)
  • Batteries & Power Supply (2)
  • Filters (5)
  • Bags & Cases (3)
  • Propellers & Guards (1)
  • Landing Gear (2)
  • Flash & Lighting (2)
  • Safety & Security Accessories (1)

About DJI Mini 3 Pro Drone with RC-N1 Remote Controller

FEATURED REVIEWS

Splendiferously awesome unit, in a fantabulously complete package!!!

By Vincent M.

This is it! An all-in-one package to get you started flying, and editing video and pictures. There's a reason DJI is the standard for so many UAV pilots and hobbyists; and here again, the Mini 3 Pro knocks it outta the park. With its compact size, 4 axis gimble, outstanding features, good flight time, and excellent video transmission quality over distance, you're ready to capture stunning images and videos out-the-box! Well... maybe after a quick firmware update. And I'm stunned at how s...

View full Review

Perfect fit for everything you will need for your DJI Mini 3 Pro drone!!

By DENNIS S.

Best bundle available. A real value for the price that comes with the most important accessories. It has the better storage backpack (a mini backpack) that is better than the Fly-More kit by DJI, although it is also included. It has the extra batteries that are a must have, the Freewell ND filters that are a must have, the propellers, landing pad....everything you need to start with great entry level or professional level video production. It's portability is key, everything in the bundle...

View full Review

Mini 3 Pro.

The DJI Mini 3 Pro is a high-powered, lightweight acrobat that fits in the palm of your hand. It's basically magic. With 4K HDR Video Recording, True Vertical Shooting that lets you record in either Portrait or Landscape, & FocusTrack for more detailed storytelling; you're about to take your content to completely new heights.

Mini 3 Pro

Remarkably Mini.

The mini-sized, mega-capable DJI Mini 3 Pro is just as powerful as it is portable. Weighing less than 249 g and with upgraded safety features, it's not only regulation-friendly, it's also the safest in its series. With a 1/1.3-inch sensor and top-tier features, it redefines what it means to fly Mini.

Packed With Performance
Mini 3 Pro sports a completely new look that is optimized to get more out of every flight. With larger propellers, an aerodynamic body tilt, and a powerful obstacle sensing system, the streamlined design allows for increased flight time and safety.

The reimagined gimbal offers a wider rotation range for low-angle shots and True Vertical Shooting, allowing endless creative opportunities. Every aspect of this facelift has been carefully considered to take Mini to never-before-seen heights.

Fold Up and Go
For creators on the move, hassle-free use is key. Weighing less than 249 g, Mini 3 Pro doesn't require registration in most countries and regions. The foldable and compact design also makes it easy to carry along with you on your next hike, beach day, or an impromptu weekend away. Be ready to capture breathtaking footage when inspiration strikes.

Sweet Air Time
Capture and explore more of your surroundings with an extended flight time of up to 34 minutes. DJI Mini 3 Pro's Intelligent Flight Battery is ultra-lightweight and has enough power to cover your aerial photography needs.

If you're the kind of person that likes to push each flight to the limit, we've got you covered too. Upgrade to the Intelligent Flight Battery Plus and enjoy care-free exploration for up to 47 minutes.

You Shot That on Mini?!

Fly by Day. Fly by Night
Capture the subtlety of light and shadows as you head out on a day trip. Shoot with clarity and less noise as evening falls. Savor the moment, stay true to your creative process, and trust Mini 3 Pro to capture your world.

Pro, and We Mean It
DJI Mini 3 Pro is outstanding in a wide range of lighting conditions, so you can always be ready to create. The 1/1.3-inch CMOS sensor features dual native ISO and supports the direct output of HDR footage. Every image is enriched with a higher dynamic range to reveal more detail in highlights and shadows.

Enjoy the highest standards of aerial photography with bigger 2.4microm pixels and an aperture ratio of f/1.7. With more light available, your images will appear true-to-life even in low-light scenes.

Aerial Photography, Done Right
Take your content to the next level with stunning 4K/60fps video and 48 Megapixel RAW photos. Marvel at the rich clarity of every image, even as you zoom in. Or slow things down as the world gets hectic with dramatic 1080p/120fps slow-motion video.

Color Outside the Lines
D-Cinelike Color mode provides more visual information, offering you richer color possibilities and more flexibility when editing.

Remarkably Mini

Peace of Mind as You Fly.

Next-Level Safety
Fly with confidence as you navigate the skies. DJI Mini 3 Pro is fully upgraded to support active obstacle sensing and stable video transmission.

Tri-Directional Obstacle Sensing
DJI Mini 3 Pro is hands-down our safest Mini to date. Equipped with forward, backward, and downward dual-vision sensors and an all-new aircraft design, it offers a broader sensing range and enhanced safety.

Did We Mention APAS 4.0?
Advanced Pilot Assistance Systems (APAS 4.0) detects objects in the aircraft's flight path in real-time. This allows DJI Mini 3 Pro to avoid obstacles, even in complicated environments.

Clear and Stable From City to Valley
DJI Mini 3 Pro boasts a flagship-level video transmission system in DJI O3. It ensures a 1080p/30fps live feed at distances of up to 12 kilometer. From city views or outdoor adventure, always fly with a crisp and reliable live feed.

Instantly Share-Worthy

Flex Your Creativity
Capture unforgettable content and instantly share your adventure on the go. DJI Mini 3 Pro offers an extensive range of intelligent features so you can add show-stopping moments and creative flair to any video.

Peace of Mind as You Fly

Instantly Share-Worthy.

Flex Your Creativity
Capture unforgettable content and instantly share your adventure on the go. DJI Mini 3 Pro offers an extensive range of intelligent features so you can add show-stopping moments and creative flair to any video.

Now That's Smart

True Vertical Shooting
Let's try that again in portrait. Quickly switch between landscape and portrait in just a tap. The re-engineered camera gimbal rotates 90 Degree , so you don't have to compromise on image quality. True Vertical Shooting gives you detailed shots, instantly ready for social media.

FocusTrack
Find creative ways to follow your subject with FocusTrack. The suite includes ActiveTrack 4.0, Spotlight 2.0, and Point of Interest 3.0, three powerful storytelling tools.

MasterShots
MasterShots is a true game-changer for any beginner aerial photographer. Simply select your subject, and Mini 3 Pro will execute a sequence of pro maneuvers, generating a short cinematic video afterward. There's a good reason why this is a fan favorite.

Timelapse
Speed up time with just a few taps by creating a striking timelapse or hyperlapse video. Capture moving traffic or rolling clouds and inject some drama into your videos.

QuickTransfer
Instantly ready to share your creations, Mini 3 Pro supports high-speed Wi-Fi downloads at up to 30Mbps.

Panorama
Capture the vastness of any landscape with 180 Degree , Wide-angle, Vertical, and Sphere panorama shots.

Digital Zoom
Get closer to your subject with 4x digital zoom. This lets you capture scenes without disturbing them and scout shots from afar.

Instantly Share-Worthy

Features.

  • Weighing less than 249g
  • Tri-Directional Obstacle Sensing
  • 4K HDR Video
  • Extended Battery Life
  • True Vertical Shooting
  • FocusTrack includes ActiveTrack 4.0, Spotlight 2.0, and Point of Interest 3.0, three powerful storytelling tools

Key Features

  • Weighing less than 249g
  • Tri-Directional Obstacle Sensing
  • 4K HDR Video
  • Extended Battery Life
  • True Vertical Shooting
  • FocusTrack includes ActiveTrack 4.0, Spotlight 2.0 & Point of Interest 3.0
