Used DZOFILM Arles Prime Cine Lens for PL Mount, Black 35mm

SKU: US1918763

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

DZOFILM Arles 14mm T1.4 Prime Cine Lens for PL Mount - Black SKU#1918763 Specifications

  • Color

    Black

  • Material

    Aluminum Alloy

  • Available Focal Lengths

    14mm, 21mm, 25mm, 35mm, 40mm, 50mm, 75mm, 100mm, 135mm, 180mm

  • Mount

    PL Mount

  • Available Aperture

    14mm: T1.9-T22
    21mm, 25mm, 35mm, 40mm, 50mm, 75mm, 100mm: T1.4-T22
    135mm: T1.8-T22
    180mm: T2.4-T22

  • Image Circle

    46.5mm (VV/FF)

  • Construction of Optics

    14mm: 15 Elements in 12 Groups
    21mm/25mm/35mm: 14 Elements in 12 Groups
    40mm: 13 Elements in 11 Groups
    50mm/75mm: 13 Elements in 9 Groups
    100mm: 13 Elements in 8 Groups
    135mm: 12 Elements in 8 Groups
    180mm: 12 Elements in 9 Groups

  • Flange Distance

    PL: 52mm

  • Angle of View

    14mm: Diagonal: 109 Degree, Horizontal: 72 Degree, Vertical: 116 Degree
    21mm: Diagonal: 89 Degree, Horizontal: 54 Degree, Vertical: 96 Degree
    25mm: Diagonal: 80 Degree, Horizontal: 47 Degree, Vertical: 87 Degree
    35mm: Diagonal: 61 Degree, Horizontal: 34 Degree, Vertical: 67 Degree
    40mm: Diagonal: 56 Degree, Horizontal: 31 Degree, Vertical: 61 Degree

  • Angle of View (Contd.)

    50mm: Diagonal: 45 Degree, Horizontal: 25 Degree, Vertical: 50 Degree
    75mm: Diagonal: 30 Degree, Horizontal: 16 Degree, Vertical: 34 Degree
    100mm: Diagonal: 23 Degree, Horizontal: 12 Degree, Vertical: 26 Degree
    135mm: Diagonal: 17 Degree, Horizontal: 9 Degree, Vertical: 19 Degree
    180mm: Diagonal: 13 Degree, Horizontal: 7 Degree, Vertical: 15 Degree

  • Close Focus (from sensor plane)

    14mm: 0.91' (0.28m)
    21mm: 1.08' (0.33m)
    25mm/35mm: 1.14' (0.35m)
    40mm: 1.31' (0.4m)
    50mm: 1.64' (0.5m)
    75mm: 2.46' (0.75m)
    100mm: 2.95' (0.9m)
    135mm: 3.21' (0.98m)
    180mm: 3.51' (1.07m)

  • Iris Control

    14mm: Manual (65 Degree)
    21mm/25mm: Manual (77 Degree)
    35mm/50mm: Manual (80 Degree)
    40mm: Manual (83 Degree)
    75mm: Manual (82 Degree)
    100mm: Manual (90 Degree)
    135mm/180mm: Manual (88 Degree)

  • Focus Control

    Manual (270 Degree)

  • Front Dia.

    3.74" (95mm)

  • Length

    14mm, 21mm, 25mm, 35mm, 40mm, 50mm, 75mm, 100mm:
    PL: 4.76" (121mm)

    135mm, 180mm:
    PL: 5.12" (130mm)

  • Iris Blade

    16

  • Filter Size

    86mm

  • Gear Pitch

    0.8 Mod

  • Focus Scales

    Imperial

  • Weight

    14mm: 3.62 lbs (1.64kg)
    21mm: 3.30 lbs (1.5kg)
    25mm: 3.28 lbs (1.49kg)
    35mm: 3.63 lbs (1.65kg)
    40mm: 3.60 lbs (1.63kg)
    50mm: 3.72 lbs (1.68kg)
    75mm: 3.66 lbs (1.66kg)
    100mm: 4.03 lbs (1.83kg)
    135mm: 4.06 lbs (1.84kg)
    180mm: 3.69 lbs (1.67kg)

About DZOFILM Arles 14mm T1.4 Prime Cine Lens for PL Mount - Black SKU#1918763

Expansive Focal Range for Unmatched Versatility

With the DZOFILM Arles Prime Cine Lens, filmmakers can achieve cinematic visual brilliance inspired by the vibrant town of Arles, France a muse for Vincent van Gogh.

This lens series, renowned for its T1.4 ultra-wide aperture, excels in capturing the dynamic interplay of light and shadow, making it ideal for low-light and complex shooting conditions. The fast aperture allows for a stunningly dreamy shallow depth of field, highlighting narrative details with precision and ensuring even brightness transitions for smooth, exquisite cinematic footage.

Versatile focal range for every vision

Covering 14mm ultra-wide to 180mm telephoto, this lens brings your creative vision to life in every frame.


From t1.4 to t2.4

With an aperture range designed for perfect exposure control, get stunning low-light performance and cinematic depth of field.


Cinema-ready image circle

Each lens boasts a maximum image circle of 46.5mm, so capture large-format visuals in detail.


0.28m minimal focus distance

Get as close as 0.28m for intimate shots without distortion.

Cinema-ready image circle

Lovely bokeh + 16-blade aperture

A 16-blade aperture ensures smooth, rounded bokeh, adding a dreamlike quality to your shots.


11 focal lengths

With 11 focal lengths from 14mm to 180mm, this lens set covers wide, standard, and telephoto.

Lovely bokeh + 16-blade aperture

Advanced aspherical elements

The use of aspherical elements in each lens corrects any optical distortion.


Uniform design for easier shoots

A unified front diameter of 95mm and interchangeable focus rings make swapping lenses fast and efficient.


Lightweight and agile

Ranging from just 1.4 to 1.9 kg, these lenses are designed for flexibility.


Cinema-standard gear

With industry-standard focus and aperture gearing, these lenses offer precise control and compatibility.

Lightweight and agile

Subtle blue coating

A low-saturation blue coating delivers beautiful color rendering and nuanced highlights.

What's in the box:

  • DZOFILM Arles Prime Cine Lens (Black)
  • Front Cap
  • PL Rear Cap
  • Shim Set
  • Support Base
  • Support Rod
