Review Summary
2024-06-26T20:00:00
After 5 months of receiving a defective plotter that could not be repaired, exchanging it for another defective plotter that also could not be repaired, after having spent hours and hours on the phone with Epson warranty people, I finally had to return both plotters. The kick in the teeth was that I had to call over, and over, and over to find out why I had not been refunded. The units were received by the Epson warehouse and I had a Fedex confirmation to prove it. But in order to process the refund Epson workers had to find and look up some number on the original unit. Yet more hours on the phone...again and again I was told that I would receive a call back in 24 hours and that they had people all over the company trying to find the unit so their internal process could be satisfied, rather than satisfying their customers. For some reason, it took 4 months to find the unit and finally the refund has been processed after yet another phone call from me. For those that think Epson's giving you a good deal, don't say you weren't warned I feel a moral sense of responsibility to warn everyone I can to avoid the pain I've experienced.
Mazkit
2023-02-06T11:11:41
Box did not come with power chord or instructions.
EFREN L.
PrecisionCore MicroTFP 4-channel, drop-on-demand printhead
2400 x 1200 dpi
A1/D-sized print: 34 seconds1
Smallest Droplet Size: 4 picoliters; Variable Droplet Technology can produce up to three different sizes per line
Black: 800 nozzles (800 nozzles x 1 channels)
Color: 2400 nozzles (800 nozzles x 3 channels)
UltraChrome XD2 pigment ink; 4-color (C, M, Y, K)
Colors (C,M,Y) 26 mL
Black (K) 50 ml
Colors (C,M,Y): 26 or 50 ml
Black (K): 50 or 80 mL
2 years from printed production date or 6 months after opened
Printer is designed for use with Epson cartridges only, not third-party cartridges or ink.
24"
8.27 x 11" (1 sheet and ASF)
Roll: 13"
Sheet: 8.26"
±0.1% or ±0.26 mm
Up to 59'8
CIS Sensor (Sheetfed)
Up to 600 dpi, reprint 2400 x 2100 dpi
Scan to Network Folder, FTP Server, Secure FTP Server, Mail Server, Secure Mail Server, USB Memory Stick (Bit Depth)
Width: Up to 24"
Length: Up to 8.9'
Up to 1.5 ips (Color)
Up to 4.5 ips (Monochrome)
10.2 mil
Up to 24" wide
Minimum 3 mm each
24" wide
2" Core Diameter: User-adjustable roll media adapters
Up to 4.6"
6.6 lb
Up to 8.6 mil
High-speed internal rotary cutter; auto or manual
The amount of remaining paper can be controlled from the control panel
4.3" Touchscreen
ESC/P raster
HP-GL/2, HP RTL
SuperSpeed USB, Wired Ethernet 100BASE-TX /1000BASE-T, Wireless LAN IEEE802.11 b/g/n, USB memory stick, Wi-Fi Direct
Printing: Approx. 24 W
Ready: Approx. 11 W
Sleep: Approx. 2 W
Power Off (Stand By): 0.2 W
Voltage: AC 110-240 V
Frequency: 50-60 Hz
Current: 1.4 A
Mac OS X (10.6.8 or later)
Windows 10, 8.1, 7 (32-bit, 64-bit)
Storage: -4 Degree to 104 Degree F (-20 Degree to 40 Degree C)
Operating: 20-80% (no condensation)
Operating (Recommended): 45-60% (no condensation)
Storage: 5-85% (no condensation)
Operating: 50 Degree to 95 Degree F (10 Degree to 35 Degree C)
Operating (Recommended): 59 Degree to 77 Degree F (15 Degree to 25 Degree C)
IEEE802.1x, SNMP 3, TLS/SSL, SMTPs, POPs, FTPs, IPsec, Administrator Mode, WPA3
USA and Canada (NRTL Certified, CSA/UL 62368-1)
Indonesia
Up to 99
25% to 400%
Up to 11" x 17"
50 pages
1GB (Printer) + 8GB (Scanner)
Operating: Approx. 47 dB(A)
Sleep: Approx. 32 dB(A)
Plain Paper, Recycled Paper, Coated Paper, Tracing Paper, Film, Blueprint, Offset Printing Paper, Carrier Sheet
JPEG, PDF (Single Page), PDF (Multi-Page), PDF/A, Encrypted PDF, TIFF
Without Stand: 38.1 x 11.5 x 19.9" (96.7 x 29.21 x 48.3cm)
With Stand: 38.1 x 19.5 x 46.9" (96.7 x 49.53 x 119.13cm)
Without Stand: 75 lbs (34kg)
With Stand: 102.3 lbs (46.5 kg)
The sleek 24" wide printer/scanner/copier for CAD, Architecture, Engineering and Corporate Graphics.
Enhance the way you work with the all-new the SureColor T3170M 24" wide MFP printer. Featuring a 24" wide printer with an integrated scanner in a sleek, ultra-small footprint up to 29% smaller than its competitors, the T3170M allows for seamless team collaboration.
Engineered for productivity, the SureColor T3170M delivers A1/D-size prints in as fast as 34 seconds, supports a variety of media - including rolls and sheets - and features integrated wireless and Wi-Fi Direct connectivity for easy printing from virtually anywhere in your home or office with a smart device. From blueprints and technical documents to renderings and graphics, the T3170M consistently delivers durable, precise prints with Epson PrecisionCore MicroTFP printhead technology and archival-quality, all-pigment-based UltraChrome XD2 inks.
24" wide printer with ultra-fast print speeds
A1/D-size prints in as fast as 34 seconds
Streamline workflow with high-detail 24" wide integrated scanner
Easily scan and share documents; up to 600 dpi scanner with highlight detection accurately scans annotated blueprints and drawings
Compact, Clean Design
Sleek, ultra-small design enhances workspaces
Durable, instant-dry prints
Archival-quality, all-pigment-based UltraChrome XD2 inks deliver brilliant color, crisp lines, and smudge and water-resistant prints
Versatile Print media handling
Accommodates rolls up to 24" wide and sheets up to 11" x 17" through the auto-sheet feeder
Easy to operate
Large, intuitive 4.3" LCD screen simplifies operation
Print from virtually anywhere in your home or office - easily print from USB thumb drives, tablets, smartphones4 and more with integrated wireless plus router-free Wi-Fi Direct printing
Extreme print quality and precision - PrecisionCore MicroTFP printhead with Precision Droplet Control for outstanding clarity; up to 2400 dpi resolution captures annotations and more with incredible accuracy
Outstanding productivity - pchange cartridges less often with high-capacity ink cartridges up to 50 ml (color) and 80 ml (Black)
Enterprise security features and protocol support - supports secure printing and scanning remotely and at home; secure PDFs and Internet servers
Note: Epson strongly recommends the use of genuine ink to ensure optimal print quality and performance.
Eco Features
RoHS compliant
Recyclable product
Epson America, Inc. is a SmartWay Transport Partner
