Review Summary
Quick Release Plate
Camera Backing Base
Lens Holder
Lens Holder Screw
3x Camera Fixed Screws
3/8"-16 to 1/4"-20 Adapter Screw
Storage Bag
Synthetic macromolecular resin, aluminum alloy
About 10.58 lbs (4.8kg) (Well balanced)
Not Water-proof
Sony, Canon, Nikon, Panasonic camera etc
14 Degree - 113 Degree F (-10 Degree - 45 Degree C)
Tilt: 340 Degree (With limitation)
Roll: 340 Degree (With limitation)
Pan: 360 Degree (Unlimited)
Tilt: +110 Degree - -45 Degree
Roll: +20 Degree - -20 Degree
Pan: 360 Degree (Unlimited)
Quick Release Plate & Camera Backing Base are compatible with Manfrotto 60 Degree quick release system.
Can be removed from the gimbal together with the camera, and fast switch between popular quick release systems without re-assembling the camera.
3/8" thread hole, with the 3/8- 1/4" thread insert
Type-C charging port
2x ARRI rosettes
2x Type-C extension port
Type-C camera control port, Type-C image transmission port
1/4" thread hole
2500mAh, built-in battery cannot be removed, charge it via the USB-C port on gimbal,support all the normal charger and quick charger which charging power <=18W
13V-16.8V
12h
About 2.75h (Using 18W fast charger)
Required, included
Lithium-Ion
-
1
Gimbal Balancing Position: 13.17 x 7.71 x 10.78" (334.6 x 195.8 x 274mm)
Gimbal Folded Position: 13.90 x 2.96 x 9.25" (353.1 x 75.3 x 234.9mm)
Quick Release Plate: 5.24 x 1.97 x 0.43" (133 x 50 x 11mm)
Camera Backing Base: 1.97 x 1.49 x 0.55" (50 x 38 x 14mm)
4.63 lbs (2.10kg) (Including quick release plate, not included other accessories and camera)
Lift and Grip Separation, All-Round Versatility
4.8kg load
1.3" touch screen
Super anti-shake
Three points of memorable follow focus
Detachable suspension handle
Flexible axis arm
Detachable Suspension Handle.
Detachable handle brings about more varied possibilities for shooting.
Somatic Remote
Handheld mode
Suspension mode
Wireless remote
Multiple Auxiliary Accessories, Easier To Install And Shoot.
Five-way center of gravity adjustment
Center of gravity memory slider
Seamless motor lock
Telescopic shaft arm
Arca Quick Release
Vertical-shoot quick install seat
Modular Design, Adaptable For Various Scenes.
The base plate is Arca Quick Release Plate with a 3/8"screw. And compatible with 1/4"screw through adapter fittings. It can be matched with different equipment to meet various shooting needs.
Monopod
Slide track
Tripod
Large Load Weight, Choose Any Camera Equipment.
4.8kg load, extendable cross arm,greatly expands the range of the camera adapter.
Two-Wheel Drive, Follow Focus And Zoom More Easily.
Touch Screen, All Under Control.
The 1.3" touch screen allows you to set all parameters easily.
Anti-Shake Technology, Extremely Stable and Smooth.
High-performance CPU with the latest W9 generation four element stabilization algorithm, Make the control more delicate,the picture more stable and smooth.
Three-Point Memory, Intelligent Trajectory.
Press the three mark buttons of the camera in turn to memorize the different focus points, so that the stabilizer completes focusing automatically. Memorize different positions by mark button to complete trajectory movement.
Flash Mode
Three-axis quickly follow hand movement,instantly capture moments, many motion footage can be captured easily.
Variety Of Play, Easily Achieved.
Panoramic photography
Time-lapse photography
Trajectory Time-lapse
Space mode
2500mAh Lithium Battery, Efficiency Upgraded.
Runtime can reach 12 hours.
Supports PD fast charging policy Charges in 2.75 hours with 18W fast charging.
