Used Litepanels Astra Soft Bi-Color Next Generation LED Light Panel, 105W

SKU: US1933116 MFR: 935-5021
Earn VIP Reward Points

Key Features

  • Adjustable color temperature from 3200K to 5600K, ideal for various lighting conditions
  • Automatic flicker-free performance at any frame rate, shutter angle, and intensity level
  • High CRI/TLCI of 98 for perfect color rendition and flattering skin tones
  • Built-in diffusion for softbox-style light, perfect for space-constrained shoots
  • Dual cooling options for efficient thermal management and noise-free operation
See More Product Details

INCLUDES FREE WARRANTY

  • This used item comes with a free 180-day warranty. ?
Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Litepanels Astra Soft Specifications

Light Fixture

Light Fixture

Jump to...
  • Number of Heads/Lights

    1

  • Fixture Type

    Light Panel

  • Photometrics

    94° at 3200K
    213fc / 2300Lux at 3.3 / 1 m
    95fc / 1022Lux at 4.92 / 1.5m
    24fc / 256Lux at 9.84 / 3m
    11fc / 114Lux at 15.09 / 4.6m
    94° at 5600K
    246fc / 2651Lux at 3.3 / 1 m
    109fc / 1178Lux at 4.92 / 1.5m
    27fc / 294Lux at 9.84 / 3m
    12fc / 131Lux at 15.09 / 4.6m

  • Color Accuracy Standard

    CRI 98, TLCI 98

  • Color Temperature

    Bi-Color

  • Color Temperature Range

    3200-5600K

  • Display

    No

  • Beam Angle

    94°

  • Built-In Flash

    No

  • Cooling System

    Fan/Passive Combo

  • Dimming

    Built-In Dimmer (Continuous)- 0 to 100%

  • Water Resistance/IP Rating

    IP20

Connectivity

Jump to...
  • Mobile App Compatible

    Yes: iOS Only

Battery

Jump to...
  • Battery Connection

    No Connection Included

  • Battery

    1x Rechargeable, 14.8 VDC (Not Included)

  • Power Source

    AC/DC

  • Power Consumption

    105 W

  • AC Input Power

    120 to 240 VAC, 50 / 60 Hz

  • DC Input Power

    13 to 24 VDC

Mounting

Jump to...
  • Fixture Mount

    1x 5/8" Receiver (Via Yoke Mount)

  • Umbrella Mount

    No

Physical Details

Jump to...
  • Panel Size

    16" x 18"

  • Dimensions

    17.7 x 16.3 x 5.3" / 45 x 41.4 x 13.5cm (Fixture)

  • Weight

    7.1lb / 3.22kg

About Litepanels Astra Soft Bi-Color Next Generation LED Light Panel, 105W

For professional photographers and videographers seeking superior lighting solutions, the Astra Soft 105W Bi-Color Next Generation LED Light Panel by Litepanels is the ultimate choice. This high-performance LED panel delivers a broad, soft, and color-accurate white light, designed to enhance your subject's natural beauty.

The Astra Soft Bi-Color LED Panel offers adjustable color temperature ranging from 3200K to 5600K, allowing you to adapt the lighting to meet your specific needs. This versatile feature, combined with its lightweight and compact design, makes it an ideal choice for both on-location and studio shoots.

This LED panel stands out for its industry-leading reliability, offering automatic flicker-free performance at any frame rate or shutter angle, and at any intensity level. Despite its low power draw of 105W, the Astra Soft Bi-Color LED Panel delivers consistent performance, whether powered by a battery on location or plugged into an AC power source in the studio.

With a high CRI/TLCI of 98, this LED panel ensures perfect color rendition, making it ideal for flattering skin tones and enveloping your subjects in unrivaled, beautiful light. It outputs an impressive 1178 Lux of soft tungsten to daylight white light, thanks to its high-performance LEDs paired with custom optics. This combination creates a longer throw over a wider field, ensuring superior color reproduction.

The Astra Soft Bi-Color LED Panel features built-in diffusion, creating a softbox-style light in a slim and highly maneuverable fixture. This feature is particularly useful when space is at a premium.

The LED panel also boasts efficient power and thermal management, ensuring low power consumption and enhanced reliability. It offers dual cooling options, allowing you to choose between ultra-quiet active cooling mode or silent passive cooling mode, ensuring no overheating or noise on set.

For added convenience, this LED panel supports remote control of parameters such as brightness, color temperature, and cooling via optional communications modules. These modules, including DMX512 RJ45, DMX512 XLR5, and wireless DMX, slide into a dedicated slot on the back of the fixture for easy integration with DMX control systems. The Bluetooth module enables remote control of multiple lights from iOS devices using the free Litepanels SmartLite Director app.

The Astra Soft Bi-Color LED Panel comes with both US and EU power cables and a universal (100-240 VAC) yoke-mounted power supply. For locations without AC power or for maximum setup speed and flexibility, the panel can run on 13-24V DC batteries with an optional Gold Mount or V-Mount battery plate.

The curved yoke design allows for a wide, unobstructed tilt range, providing plenty of clearance for light shaping accessories. Flexible mounting options include a removable 5/8" TVMP connector for hanging or stand mounting and two 1/4"-20 female taps for alternate mounting points.

The Astra Soft Bi-Color LED Panel is compatible with a wide range of light shaping tools and accessories, ensuring you can shape the light to your will. The aluminum accessory mounting points and lens/filter rails ensure stable and durable attachment of softboxes, barn-doors, and diffusers.

Litepanels Astra Soft Bi-Color Next Generation LED Light Panel, 105W Features

  • Soft, color-accurate white light
  • Automatically flicker-free at any frame rate
  • Active & Passive cooling modes
  • Fully-adjustable Daylight and Tungsten color temperature
  • High CRI output
  • AC and optional battery power

Warranty Information

This used item has a FREE 180-day warranty. See details.

Key Features

  • Adjustable color temperature from 3200K to 5600K, ideal for various lighting conditions
  • Automatic flicker-free performance at any frame rate, shutter angle, and intensity level
  • High CRI/TLCI of 98 for perfect color rendition and flattering skin tones
  • Built-in diffusion for softbox-style light, perfect for space-constrained shoots
  • Dual cooling options for efficient thermal management and noise-free operation
