ambient and flash, Incident Convertible to flat diffuser (lumisphere in down position)
Reflected 1° to 4° nine element zoom
Silicon photo diodes (incident and reflected)
Ambient light
Aperture priority metering
Shutter speed priority metering
EV metering value
Flash
With synch cord (cumulative, non-cumulative)
Without synch cord (cumulative, non-cumulative)
With radio triggering (cumulative, non-cumulative)
Ambient
Incident light: EV(-) 2 to EV22.9
Reflected light: EV3 to EV24.4
Flash
Incident light: f/0.5 to 128.9
Reflected light: f/5.6 to 128.9
+/-0.1EV or less
Digital LCD plus LCD analog
Auto backlit LCD at EV 3 or under for 20 secs
Shutter speed and aperture are displayed along the lower edge of the viewfinder
Film speeds from ISO 3-8000 (in 1/3rd steps)
Analog Display: f/1.0 to f/128 (in 1/2 steps)
E.u (underexposure) or E.o (overexposure) indication
ISO 3 to ISO 8000 (1/3 steps)
Analog display f/1.0 to f/128 (in 1/2 steps)
Digital display f/0.5 to f/128.9
EV(-) 9.9 to EV40.6 (1/10 steps)
Foot-candle 0.12 to 180,000
Lux 0.63 to 190,000
30 minutes to 1/8000 second (full, 1/2 or 1/3 stops)
1/1000 to 30 minutes (full, 1/2 or 1/3rd steps)
2, 3, 4, 6, 8, 12, 16, 18, 24, 25, 30, 32, 36, 40, 48, 50, 60, 64, 72, 96, 120, 128, 150, 200, 240, 256, 300, 360
9 readings on analog scale (f/stop and shutter speed) with memory recall and clear feature
Percentage of flash in total exposure from 0 to 100% in 10% increments
Exposure compensation +/- 9.9EV for incident and reflected independently
Calibration compensation +/- 1.0EV for incident and reflected independently
Filter compensation +/-5.0EV on ISO2
Flash or ambient light evaluation (original value vs new measurement)
Unlimited flash readings (Only last digit is displayed when more than ten flash exposures are measured.)
3.0Vx1 (CR123A lithium battery)
3.5W x 6.7H x 1.9D" (90W x 170H x 48D mm)
9.5 oz. (268g)
Average function: Flash and ambient up to 9 measurements
All weather design: JIS standard water resistance class 4, splash-proof type
Calibration constant Incident metering: Lumisphere C=340
Flat diffuser C=250
Reflected metering: K=12.5
Custom Programs 11 custom program settings
Radio Triggering (Optional)
Radio technology Complex 16/24 bit digitally coded
Range Up to 100 ft from transmitter to receiver
Channels 1-16 standard, 17 to 32 "Quad Triggering"
