This item is no longer available.
Review Summary
LED
Approx. 14.9 oz (420 g)
Approx. 3 1/5 ft. (1 m) 600 lux
Approx. 9 and 4/5 ft. (3 m) 66 lux
Approx. 16 and 1/2 ft. (5 m) 24 lux
Approx. 26 and 1/3 ft. (8 m) 9 lux
Approx. 32 and 4/5 ft. (10 m) 6 lux
Without filter: Approx. 5500 K without diffuser (when the BRIGHT dial is set toMAX at an ambient temperture of 70 °F (25 °C))
With filter: Approx. 3200 K without diffuser (when the BRIGHT dial is set to MAX at an ambient temperture of 70 °F (25 °C))
Vertical approx. 45 degrees
Horizontal approx. 60 degrees (without lens) 30 degrees (with lens)
Approx. 3 hours (when using a fully charged NP-F970 and when the BRIGHT dial is set to MAX at an ambient temperture of 70 °F (25 °C))
Approx. 2 hours (when using a fully charged NP-F770 and when the BRIGHT dial is set to MAX at an ambient temperture of 70 °F (25 °C))
DC 7.2 V InfoLITHIUM rechargeable battery pack L series NP-F900/700 range. (cannot use NP-F500/300 range)
Approx. 16 W
+32 to +104 °F (0 to +40 °C)
-4 to +140 °F (-20 to +60 °C)
The HVL-LBPA video light combines LED reliability with low power consumption. It's perfect for outside shooting in shade or sunlight and ideal for wide-angle shooting and interviews.
Wide compatibility for flexible installation
The HVL-LBPA can be attached three ways:
• 1. The cold shoe achieves a good weight balance when battery adaptor is added to the rear of the HVR-V1U camera using VCT-1BP.
• 2. The screw bolt contained inside the attachment foot can be extended with dialing screw (circled in red) for easy connection to the screw hole.
• 3. The screw hole allows easy connection to a tripod, light stand, or other device that contains a standard screw in its attachment plate.
The supplied battery adapter has a tripod screw hole and strap for flexible attachment. Use as a hand-held battery light or on top of a light stand to act as backlight.
Ideal for Wide-angle Shooting and Interviews:
The HVL-LBPA provides uniform flood-lighting over wide areas for backgrounds, and quick conversion to a focused spot-light for interviews.
Wide-angle Flood:
The HVL-LBPA is designed to provide optimum flood-light dispersion for wide-angle shooting. Uniform dispersion of illumination intensity is possible across the entire scene.
Focused Spot:
Using the attached special condensing lens, you can concentrate light in one area of the scene ideal for interviews. The attached diffuser softens shadows and reduces contrast for professional results.
Filter kit:
The HVL-LBPA comes with a filter kit to convert color temperature 5,500K to 3,200K.
Spot or flood-lighting with an attached condensing lens ON or OFF. The HVL-LBPA has a diffuser lens to soften shadows and reduce contrast in all conditions.
