Used Sony PMW-100 One 1/2.9" Exmor CMOS XDCAM HD422 Handy Camcorder

SKU: US2054942 MFR: PMW100
Earn VIP Reward Points

What`s in the box:

  • "Sony PMW100 One 1/2.9" Exmor CMOS XDCAM HD422 Handy Camcorder
  • BP-U30 Lithium-Ion Battery
  • BC-U1 Battery Charger
See more

INCLUDES FREE WARRANTY

  • This used item comes with a free 180-day warranty. ?
Overview
Compare
Accessories
Specs
Protection

Reviews about this item

Review Summary

Sony PMW-100 Specifications

  • Imaging Device

    1x 1/2.9" Exmor CMOS sensor (1920 x 1080 effective picture elements)

  • Lens

    10x optical zoom fixed lens

  • Focal Length

    5.4-54 mm (equivalent to 40-400 mm on a 35 mm lens)

  • Iris

    f/1.8-2.9; auto/manual selectable

  • Focus

    10 mm to infinity (wide), 800 mm to infinity (tele); auto/manual selectable

  • Image Stabilization

    On/off selectable; shift lens

  • Filter Diameter

    37 mm; pitch: 0.75 mm

  • Minimum Illumination

    0.40 lux (typical) in 1920 x 1080i59.94 mode, f/1.8, +18 dB gain, with 64-frame accumulation, 100% video level
    0.08 lux (typical) in 1920 x 1080i59.94 mode, f/1.8, +18 dB gain, with 64-frame accumulation, 50% video level

  • Shutter Speed

    1/32 to 1/2000 seconds

  • Slow Shutter

    2, 3, 4, 5, 6, 7, 8, 16, 32 and 64-frame accumulation

  • Slow & Quick Motion Function

    720p: 1-60 fps
    1080p: 1-30 fps

  • White Balance

    Preset (3200 K), Memory A, Memory B/ATW

  • Gain

    -3, 0, 3, 6, 9, 12, 18 dB, auto gain control

  • Gamma Curve

    Selectable

  • Viewfinder

    0.24" color LCD: 392 (H) x 224 (V), 16:9

  • LCD Monitor

    3.5" color LCD monitor: 852 (H) x 3 (RGB) x 480 (V), 16:9

  • Microphone

    Omni-directional stereo electret condenser microphone

  • Video Formats

    UDF Mode (HD Recording)
    MPEG HD422 (MPEG-2 422P@HL): CBR, 50 Mb/s
    MPEG HD420 (1440 x 1080, MPEG-2 MP@HL):
    HQ mode (VBR, maximum bit rate: 35 Mb/s)
    SP mode (CBR, 25 Mb/s) - playback only
    LP mode (VBR, maximum bit rate: 18 Mb/s) - playback only
    UDF Mode (SD Recording)
    DVCAM (CBR, 25 Mb/s)
    FAT Mode (HD Recording)
    MPEG HD420 (1920 x 1080, MPEG-2 MP@HL):
    HQ mode (VBR, maximum bit rate: 35 Mb/s)
    SP mode (CBR, 25 Mb/s)
    FAT Mode (SD Recording)
    DVCAM (CBR, 25 Mb/s)

  • Audio Formats

    UDF Mode (HD Recording)
    MPEG HD422 (MPEG-2 422P@HL): 4 channels, 48 kHz, 24-bit LPCM
    MPEG HD420 (1440x1080, MPEG-2 MP@HL): 4 channels, 48 kHz, 16-bit LPCM
    UDF Mode (SD Recording)
    DVCAM: 4 channels, 48 kHz, 16-bit
    FAT Mode (HD Recording)
    MPEG HD420 (1920 x 1080, MPEG-2 MP@HL): 2 channels, 48 kHz, 16-bit LPCM
    FAT Mode (SD Recording)
    DVCAM: 2 channels, 48 kHz, 16-bit LPCM

  • Recording Media

    SBP-8/16/32, (GB) SxS Express 34 Cards

  • Recording/Playback time: 1

    UDF Mode (HD Recording)
    50 Mb/s MPEG HD422 (MPEG-2 422P@HL):
    Approx. 120 min with SBS-64G1A (64 GB) memory card
    Approx. 60 min with SBP-32 / SBS-32G1A (32 GB) memory card
    Approx. 30 min with SBP-16 (16 GB) memory card
    35 Mb/s VBR, HQ Mode MPEG HD420 (1440x1080, MPEG-2 MP@HL):
    Approx. 180 min with SBS-64G1A (64 GB) memory card
    Approx. 90 min with SBP-32 / SBS-32G1A (32 GB) memory card
    Approx. 45 min with SBP-16 (16 GB) memory card

  • Recording/Playback time: 2

    UDF Mode (SD Recording)
    25 Mb/s DVCAM
    Approx. 220 min with SBS-64G1A (64 GB) memory card
    Approx. 110 min with SBP-32 / SBS-32G1A (32 GB) memory card
    Approx. 55 min with SBP-16 (16 GB) memory card

  • Recording/Playback time: 3

    FAT Mode (HD Recording)
    35 Mb/s VBR, HQ Mode - MPEG HD420 (MPEG-2 MP@HL):
    Approx. 200 min with SBS-64G1A (64 GB) memory card
    Approx. 100 min with SBP-32 / SBS-32G1A (32 GB) memory card
    Approx. 50 min with SBP-16 (16 GB) memory card
    25 Mb/s CBR, SP Mode - MPEG HD 420 (MPEG-2 MP@HL-14):
    Approx. 280 min with SBS-64G1A (64 GB) memory card
    Approx. 140 min with SBP-32 / SBS-32G1A (32 GB) memory card
    Approx. 70 min with SBP-16 (16 GB) memory card

  • Recording/Playback time: 4

    Fat Mode (SD Recording)
    25 Mb/s DVCAM
    Approx. 220 min with SBS-64G1A (64 GB) memory card
    Approx. 110 min with SBP-32 / SBS-32G1A (32 GB) memory card
    Approx. 55 min with SBP-16 (16 GB) memory card

  • Genlock In

    BNC x1 (switchable to Video Out), 1.0 Vp-p, 75Ohms

  • TC IN

    x1 (switchable to TC Out), SMPTE-12M-2008, 0.5-1.8 Vp-p, 10kOhms

  • Audio In

    XLR-type 3-pin (female) (x2): line, mic, mic +48 V selectable

  • SDI Out

    BNC x1, HD/SD switchable, SMPTE-292M/259M

  • Composite Video Out

    BNC x1, (switchable to Genlock In), HD-Y / Composite switchable, 1.0 Vp-p, 75Ohms

  • Audio Out

    A/V OUT jack: 10 pin connector

  • TC Out

    BNC x1 (switchable to TC In), SMPTE-12M-2008, 1.0 Vp-p, 10kOhms

  • Earphone

    Mini-jack x 1 (rear: stereo)

  • Monitor Speaker

    Monaural, 250 mW

  • i.Link

    IEEE-1394, 4-pin, (x1), HDV (HDV 1080i) / DV input/output, S400

  • USB

    USB 2.0 (device), mini-B type x1

  • Built-In Microphone

    Omni-directional stereo electret condenser microphone

  • Memory Card Slot

    ExpressCard/34 slot x 2

  • Power Requirements

    DC 12 V

  • Power Consumption

    Approx. 12 W (while recording, EVF On, LCD monitor Off, I/O Select Off)
    Approx. 14 W (while recording, EVF On, LCD monitor On, I/O Select HD SDI and HD HDMI)

  • Operating Temperature

    0 to +40 deg.C (+32 to +104 deg.F)

  • Storage Temperature

    -20 to +60 deg.C (-4 to +140 deg.F)

  • Humidity

    10 to 90% (relative humidity)

  • Continuous Operating Time

    Approx. 240 min. with BP-U60 battery

  • Dimensions (W x H x D)

    Without Protrusions: 6.6 x 6.5 x 11.0" (16.7 x 16.5 x 27.9 cm)

  • Weight

    Approx. 3 lbs, 5 oz (1.5kg) (body)
    Approx. 3 lbs, 15 oz (1.7kg) (with lens hood, eye piece, BP-U30 battery, one SxS memory card)

3 Accessories for Sony PMW-100 One 1/2.9" Exmor CMOS XDCAM HD422 Handy Camcorder

  • All Accessories (3)
  • Cables & Adapters (1)
  • Headphones (1)
  • Memory & Storage (1)Required Item

About Sony PMW-100 One 1/2.9" Exmor CMOS XDCAM HD422 Handy Camcorder

The Sony PMW100 One 1/2.9" Exmor CMOS XDCAM HD422 Handy Camcorder offers broadcast-quality 50 Mb/s MPEG-2 recording at 1920 x 1080 in a very compact form factor. Even loaded with an SXS card and the packaged Li-ion battery, the PMW-100 weighs slightly less than 4 lb. That's a crucial benefit for any mobile documentarian or news gatherer who's operating handheld over the course of long days to cover events & news stories, conduct on-the-spot interviews and capture video for just about any other professional task.

The handy PMW-100 is a comfortable companion for Sony's entire XDCAM line, including the optical-disc models and the camcorders, like this one, that record HD video to SXS cards. That's because it captures files to either FAT- or UDF-formatted cards, so you can easily integrate the PMW-100 into both XDCAM Ex and XDCAM Professional Disc workflows. With two SXS slots that accept cards with capacities up to 64 GB, you can record up to 240 minutes even at the highest quality - that would be Sony's XDCAM 422 MPEG-2 codec, at 50 Mb/s.

Built into the camcorder is a 10x zoom lens that offers a 35mm equivalent focal length range of 40-400mm. Manual control over zoom is available via a Lens Control Ring; that ring can be switched over to focus control if you'd prefer to pull focus manually. Additionally there's a dial for setting exposure manually. The PMW-100 employs a single 1920 x 1080 CMOS sensor (1/2.9" type) that's extremely sensitive, which makes the camcorder suitable for low-light videography. A NightShot function extends that functionality to complete darkness; a built-in infrared LED illuminates the dead of night.

Inputs and outputs are just what you'd expect from a professional camcorder. There's HD/SD-SDI output. For multi-camera shoots, you have timecode input/output and genlock in. There are also dual XLRs for audio, composite video out and HDMI out.

Sony PMW-100 One 1/2.9" Exmor CMOS XDCAM HD422 Handy Camcorder Features

  • Single 1/2.9-inch Exmor CMOS sensor
  • 50 Mbps MPEG HD422 recording as MXF files (UDF mode only)
  • SD Recording and Playback (DVCAM) standard
  • 10x Fixed Zoom Lens (f= 5.4 - 54 mm) (servo/manual switchable)
  • Two ExpressCard SxS Memory Card Slots
  • Record up to 4 hours 50 Mbps MPEG HD422 in camcorder using two 64 GB SxS-1A memory cards (must be purchased separately)
  • UDF (Professional Disc compatible) or FAT (XDCAM EX compatible) file format mode shooting to have similar high res files and workflows with existing Professional Disc and XDCAM EX camcorders
  • NightShot Function
  • Low power consumption
  • Compact and lightweight at under 4 lbs
  • 16:9, 3.5 inch color LCD
  • Slow & Quick motion
  • Focus Magnification for focus assistance
  • Slow Shutter Function
  • Shutter Angle Settings
  • Picture Cache Recording
  • High-quality four-channel audio recording
  • HD/SD-SDI output and composite/HD-Y output
  • USB interface for connecting camcorder as card reader
  • Six Standard Gamma settings and Four HyperGama Settings

Warranty Information

This used item has a FREE 180-day warranty. See details.
