Used Sony SNC-DH280 3MP 1080p Indoor/Outdoor Day & Night Vandal Resistant Minidome Network Camera, 2.9x Optical Zoom, 20 fps, JPEG/MPEG-4/H.264, PoE

SKU: US1284584

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

Sony SNC-DH280 Specifications

  • Image device

    1/2.8 type progressive scan Exmor CMOS sensor

  • Minimum illumination

    Color: 0.40 lx
    B/W: 0 lx (IR ON)(F1.2/View-DR OFF/XDNR ON-Middle/VE OFF/AGC High/50 IRE [IP])

  • Number of effective pixels (H x V)

    Approx. 3.27Megapixel (2096x1561)

  • Electronic shutter speed

    1s to 1/10000s

  • Gain control

    Auto (3 levels)

  • Exposure control

    Auto, EV Compensation, Auto Slow Shutter

  • White balance mode

    Auto (ATW, ATW-PRO), Preset, One-push WB, Manual

  • Lens type

    Built-in Vari-focal lens

  • Zoom ratio

    Optical 2.9X (x2 Digital Zoom)

  • Horizontal viewing angle

    88.5 to 32.3 deg.

  • Focal length

    f = 3.1 to 8.9mm

  • F-number

    F1.2 (Wide), F2.1 (Tele)

  • Minimum Object Distance

    300mm

  • Powered focus

    Yes (Easy Focus)

  • Powered zoom

    Yes (Easy Zoom)

  • IR illuminators

    Yes (Wave Length: 850nm [Typical], IR LED: 21pcs)

  • Day/Night

    Yes

  • Wide-D

    View-DR Technology (90dB)

  • Image enhancement

    Image enhancement Visibility Enhancer

  • Noise reduction

    XDNR

  • Image: Codec image size (H x V)

    1920 x 1440, 1600 x 1200, 1680 x 1056, 1920 x 1080, 1440 x 912, 1376 x 768, 1280 x 960, 1280 x 800, 1280 x 720, 1280 x 1024, 1024 x 768, 1024 x 576, 800 x 480, 768 x 576, 720 x 576, 704 x 576, 720 x 480,640 x 480, 640x 368, 384 x 288, 320 x 240, 320 x 192 (H.264, MPEG-4, JPEG)

  • Image: Video compression format

    H.264, MPEG-4, JPEG

  • Image: Codec streaming capability

    Dual streaming

  • Image: Maximum frame rate

    H264: 20fps (1920 x 1440) / 30fps (1920 x 1080)
    MPEG-4: 15fps (1920 x 1440) / 20fps (1920 x 1080)
    JPEG: 10fps (1920 x 1440) / 15fps (1920 x 1080)

  • Audio compression

    G.711/G.726

  • Scene Analytics: Motion detection

    Yes (with built-in Post Filter)

  • Scene Analytics: Rule filter

    Yes

  • Network Protocols

    IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2)

  • Network ONVIF software

    Yes

  • Network Wireless network

    No

  • Network Number of clients

    10

  • Network Authentication

    IEEE802.1X

  • Analog Monitor Output: Signal system

    NTSC / PAL

  • Analog Monitor O/P:Horizontal resolution

    600 TV lines

  • Analog Monitor Output: S/N ratio

    More than 50dB

  • Interface: Ethernet

    10BASE-T / 100BASE-TX (RJ-45)

  • Interface: Analog video output

    BNC x1

  • Interface: Analog monitor output

    Phono jack x1

  • Interface: Sensor input

    x1

  • Interface: Alarm output

    x2

  • Interface: External microphone input

    Mini-jack (Monaural)
    MIC IN/LINE IN: 2.5VDC plug-in power

  • Interface: Audio line output

    Mini-jack (Monaural)
    Max output level: 1 Vrms

  • Power requirements

    PoE, AC24V, DC12V

  • Power consumption

    29W Max.

  • Ingress protection

    IP66

  • Vandal resistant

    IK10

  • Safety Regulations

    UL2044, FCC 15B Class A, IC Class A, IEC60950-1, EN55022(A)+EN55024+EN50130-4, VCCI Class A, C-Tick Class A

  • Operating system

    Microsoft Windows XP, Windows Vista (32bit), Windows 7 (32bit)

  • Processor

    Intel Core2 Duo 2GHz or higher

  • Memory

    1GB or more

  • Web browser

    Microsoft Internet Explorer Ver. 6.0, Ver. 7.0, Ver. 8.0
    Firefox Ver.3.5 (Plug-in free viewer only)
    Safari Ver.4.0 (Plug-in free viewer only)
    Google Chrome Ver.4.0 (Plug-in free viewer only)

  • Starting temperature

    AC24V/DC12V: -4 to +122 deg. F / -20 to +50 deg. C
    PoE (IEEE802.3af): 32 to 122 deg. F / 0 to 50 deg. C

  • Working temperature

    AC24V/DC12V: -22 to +122 deg. F / -30 to +50 deg. C
    PoE (IEEE802.3af): 14 to 122 deg. F / -10 to +50 deg. C

  • Storage temperature

    -4 to +140 deg. F / -20 to +60 deg. C

  • Dimensions

    Dia. 6.62 x 4.75" / 168.15 x 120.65mm

  • Weight

    3.06lbs / 1.39kg

About Sony SNC-DH280 3MP 1080p Indoor/Outdoor Day & Night VR Minidome Camera #1284584

Network HD 1080p Vandal Resistant Minidome Camera with View-DR technology, IR Illuminator, IP66 rated with built-in heater, Dual Stream H.246/MPEG-4/JPEG, Day/Night, PoE, built-in 3.1-8.9mm auto iris lens.

Sony SNC-DH280 3MP 1080p Indoor/Outdoor Day & Night VR Minidome Camera #1284584 Features

  • Excellent 1080p HD picture quality, supporting H.264 at 30 fps
  • 3 Megapixel (1920 x 1440) maximum resolution
  • Three codecs (H.264, MPEG-4, JPEG) and dual streaming capability
  • The Exmor CMOS sensor incorporated to deliver high image quality and low noise
  • View-DR Technology -- Sony's innovative Wide Dynamic Range technology -- to capture objects clearly and adaptively even under very severe backlit or highlight conditions
  • Visibility Enhancer to optimize the brightness and color reproduction of an image dynamically on a pixel-by-pixel basis while continuously adapting to the scene, within the given dynamic range
  • Built-in IR (Infrared) illuminators to assist capturing objects in the dark even under 0 lx, up to 49 feet (15 m) away
  • IP66-rated waterproof and dust-tight feature for outdoor surveillance or indoor where water ingress may pose an issue
  • IK10-rated vandal-resistant feature to protect the camera from destructive behaviors
  • Easy Focus / Easy Zoom functions for easy installation
  • DEPA Advanced Intelligent Video and Audio Analytics to trigger an alarm, based on user-defined rules
  • Optical Day/Night function to switch to Day or Night mode depending on the light level
  • XDNR (excellent Dynamic Noise Reduction) technology for clear images without motion blur under low illumination
  • Powered by either AC 24V, DC 12V or PoE (Power over Ethernet) for easy installation
  • Equipped with a built-in heater for continued camera operation in cold weather supported (-22 deg.F to +122 deg.F/ -30 deg.C to +50 deg.C)
  • Equipped with a BNC connector and a phono jack to instantly monitor the video while installing the camera
  • ONVIF (Open Network Video Interface Forum) software that ensures greater interoperability and more flexibility in building multiple-vendor systems
  • Bi-directional audio with enhanced audio features
  • Excellent sensitivity (F1.2, AGC High, 50IRE [IP])
  • Analog video output
  • Flush mount capability using optional YT-ICB45

What's in the box:

  • Sony SNC-DH280 3MP 1080p Indoor/Outdoor Day & Night Vandal Resistant Minidome Network Camera
  • CD-ROM (User's Guide / SNC Toolbox)
  • Installation Manual
  • Wire Rope
  • M4 Screw
  • Template
