Tascam DR-680 Specifications

  • Recording/Reading Methods

    SD/SDHC Cards

  • Recording Bit Rate

    Up to 24-bit

  • Sampling Frequency

    Up to 96kHz (8 Tracks)
    Up to 192kHz (2 Tracks)

  • Number of Channels

    8

  • Connectors

    4 x XLR/TRS Mic/Line Inputs
    2 x 1/4" Mic/Line Inputs
    6 x RCA Unbalanced Outputs
    1 x S/PDIF Digital Input
    1 x S/PDIF Digital Output
    1 x USB 2.0 Port
    1 x 1/4" Headphone Output
    1 x Cascade Connector

  • Speakers

    Integrated

  • Display

    128 x 64 Backlit LCD

  • Power

    8 x AA Batteries
    AC Power

  • Dimensions (W x H x D)

    7.95 x 2.12 x 6.93" (202 x 54 x 176mm)

  • Weight

    2.65 lbs (1.2kg) (Without Batteries)

About Tascam DR-680 8-Track Portable Field Audio Recorder - SKU#1639756

Tascam's DR-680 brings multi-channel portable recording within reach of any musician for polished live, location and surround recordings. Up to eight tracks can be recorded to solid-state SD card media at 96kHz/24-bit Broadcast WAV quality. Six mic inputs provide phantom power and 60dB of gain for great-sounding recordings with your condenser microphones. Record the six microphones along with a digital S/PDIF source for 8 track recording. Each mic input has a selectable low cut filter and analog limiter for optimal sound.

Inputs can be monitored using a built-in mixer with level and pan controls for each input. The stereo mixdown can even be recorded along with the six mics for quick stereo playback of the event. There's even a Built-In Speaker to check recordings without headphones.

In addition to WAV recording up to 96kHz, the DR-680 captures stereo audio at 192kHz/24-bit for audiophile-quality masters. The DR-680 records up to four channels of MP3 audio for web-ready recordings. Two of the recorders can be connected with a cascade cable for up to 14-track recording on battery power. Multi-channel portable recording has never been as simple or affordable as the TASCAM DR-680.

Tascam DR-680 8-Track Portable Field Audio Recorder - SKU#1639756 Features

  • 8-track portable recording
  • Record eight individual inputs or six inputs plus a stereo mixdown
  • Up to 96kHz/24-bit Broadcast WAV file resolution for 8 channels
  • Stereo 192kHz/24-bit recording mode
  • 4-channel MP3 recording
  • Digital monitor mixing (level and pan) with recordable stereo mixdown
  • Ideal for surround music and effects recording
  • Cascade function for running two units together
  • Pre-recording feature
  • Auto-recording mode begins recording when the input reaches a certain level
  • Mark function during recording/playback
  • Edit functions such as divide and delete
  • 128x64 backlit LCD display
  • Powered through (8x) AA batteries or (included) PS-1225L adapter
  • Records to SD/SDHC card media (not included)
  • Premium AKM Audio4Pro 192kHz A/D converters with over 100dB signal to noise ratio

What's in the box:

  • USB Cable
  • User Manual
  • Original Box
  • Item Note: Missing Power Supply; Shoulder Strap; Box is heavily damaged
