Used Tilta Nucleus-M Wireless Follow Focus Lens Control System Partial Kit V, Includes Left & Right Wireless Handles

SKU: US1890099

This item is no longer available.

Recommended Items

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

Tilta Partial Kit V Specifications

Handgrip (Left)

Handgrip (Left)

Jump to...
  • Current

    0.1 A

  • Voltage

    Battery: 7.2 V
    External: 7.2-14.8 V

  • Port

    Power/Communication: 4-pin

  • Rotation

    85, 180, 310 Degree

  • Battery Type

    18650

  • Operating Frequency

    2.4 GHz

  • Emission Power

    10-100 MW

  • Maximum Transmission Distance

    33-328' (10-100m)

  • Operating Temperature Range

    -4 to 122 Degree F (-20 to 50 Degree C)

  • Material of Construction

    Aluminum alloy, stainless steel
    ABS plastic, rubber

  • Dimensions

    With Thumb Unit: 6.9 x 3.3 x 2.3" (17.6 x 8.5 x 6cm)
    Without Thumb Unit: 6.9 x 3.3 x 1.2" (17.6 x 8.5 x 3.1cm)

  • Weight

    With Thumb Unit: 12.5 oz (355g)
    Without Thumb Unit: 12 oz (340g)

Handgrip (Right)

Jump to...
  • Current

    0.1 A

  • Voltage

    Battery: 7.2 V
    External: 7.2-14.8 V

  • Port

    Power/Communication: 4-pin

  • Rotation

    85, 180, 310 Degree

  • Battery Type

    18650

  • Operating Frequency

    2.4 GHz

  • Emission Power

    10-100 MW

  • Maximum Transmission Distance

    33-328' (10-100m)

  • Operating Temperature Range

    -4 to 122 Degree F (-20 to 50 Degree C)

  • Material of Construction

    Aluminum alloy, stainless steel
    ABS plastic, rubber

  • Dimensions

    With Thumb Unit: 6.9 x 3.3 x 2.3" (17.6 x 8.5 x 6cm)
    Without Thumb Unit: 6.9 x 3.3 x 1.2" (17.6 x 8.5 x 3.1cm)

  • Weight

    With Thumb Unit: 12.5 oz (355g)
    Without Thumb Unit: 12 oz (340g)

FIZ Lens Control Motor

Jump to...
  • Gear Mod

    0.8

  • Gear Pitch

    32

  • Number of Gear Teeth

    35

  • Face Width

    0.4" (10mm)

  • Operating Frequency

    2.4 GHz

  • Maximum Range

    1640' (500m) (unobstructed)

  • Emission Power

    30-100 MW

  • Current

    Quiescent: 0.10 A, 14.8 V
    Conventional: 0.5 A, 14.8 V

  • Voltage

    7.2-24 V

  • Rod Compatibility

    19, 15 mm

  • Noise

    15 dB

  • Operating Temperature Range

    -4 to 122 Degree F (-20 to 50 Degree C)

  • Material of Construction

    Aluminum alloy, stainless steel, ABS plastic

  • Dimensions

    4.50 x 3.25 x 1.38" (11.43 x 8.26 x 3.49cm)

  • Weight

    6.7 oz (190g) (motor only)
    7.9 oz (225g) (with 15mm rod adapter)
    7.8 oz (221g) (with 19mm rod adapter)

DSLR Lens Follow Focus Adapter

Jump to...
  • Material of Construction

    Silicone and plastic

  • Compatibility

    Tilta Nucleus-M, Nucleus-Nano
    Most DSLR lenses

D-Tap to 7-Pin Motor Power Cable

Jump to...
  • Connectors

    D-Tap, 7-pin LEMO-type

  • Length

    23" (58.4cm)

  • Weight

    1.1 oz (32g)

ARRI-Standard Rosette Adapters

Jump to...
  • Material of Construction

    Aluminum alloy, stainless steel

  • Dimensions (LxWxD)

    2.3 x 2 x 1.5" (5.7 x 5.1 x 3.8cm)

  • Weight

    2.5 oz (72g)

Battery Charger

Jump to...
  • Power Input

    100-240 VAC, 50/60 Hz, 0.15 A
    5 VDC, 2 A

  • Power Output

    4.2 VDC, 650 mAh

  • Material of Construction

    Plastic

About Tilta Nucleus-M Wireless Follow Focus Lens Control System Partial Kit V #1890099

With the Nucleus-M Wireless Follow Focus Lens Control System Partial Kit V, experience a revolutionary, highly customizable 3-channel wireless lens control system that offers unparalleled control over focus, iris, and zoom. This versatile system allows for full control from either the FIZ hand unit or the two wireless hand grips, with the flexibility to split control between the two as needed.

Boasting a wireless range of 1,000 feet, extendable up to 1 1/4 miles with a future transmission upgrade, this system is perfect for capturing high-quality drone or car-mounted shots. The durable hand grips can be conveniently attached to the included rosette mounts for handheld operation, or to top bar-based gimbals with the included Nucleus-M Hand Grip to Gimbal Adapters.

Each motor in this compact system features a built-in motor drive that communicates directly with the hand unit and hand grips, eliminating the need for a separate MDR and allowing for a more streamlined camera setup. The motors are designed to clamp onto 15mm or 19mm rods, facilitating easy attachment and detachment without the need to remove any other accessory from your setup.

The Nucleus-M motors also offer automatic and manual calibration for lenses, ensuring precise control for both close focus and infinity shots. Powering the motors is simple, requiring only one power port on your camera rig. The hand unit and hand grips are powered by two 18650 rechargeable batteries (not included), providing up to 2 days of power for the hand grips and up to 10 hours for the hand unit.

For added functionality, the Nucleus-M system also supports remote start/stop capabilities when using a compatible Nucleus-M R/S cable. Please note, only cables developed exclusively for the Nucleus-M system should be used to ensure safety and compatibility.

Experience the versatility, reliability, and user-friendly design of the Nucleus-M Wireless Follow Focus Lens Control System Partial Kit V, a product that stands out in the photography and videography industry for its high-quality performance and innovative features.

Tilta Nucleus-M Wireless Follow Focus Lens Control System Partial Kit V #1890099 Features

  • Revolutionary 3-channel wireless lens control system for professional photography and videography
  • Versatile control options with FIZ hand unit and two wireless hand grips
  • Extended wireless range of up to 1 1/4 miles, ideal for drone or car-mounted shots
  • Durable hand grips compatible with rosette mounts and bar-based gimbals
  • Motors with built-in drive, supporting both automatic and manual lens calibration
  • Power-efficient system, with hand grips lasting up to 2 days and hand unit up to 10 hours on a single charge

What's in the box:

  • Left Wireless Handle (Finger Wheel)
  • Right Wireless Handle (Finger Wheel & Zoom Toggle)
  • Brushless Wireless Motor with 19mm Rod Support and 15mm Rod Bushings
  • (55cm) 7-Pin to 7-Pin Motor Connection Cable
  • Photographic Lens Follow Focus Adapter
  • 74cm 7-Pin to P-Tap Motor Power Cable
  • Hand Grip to Arri Standard Rosette Adapters
  • 18650 Battery Charger
  • 2x 18650 Battery
  • Item Note: MissingWireless FIZ Hand Unit Strap
