Used Yamaha PX8 2x 1050W 4 Ohms Stereo Power Amplifier

SKU: US1713291

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

Yamaha PX8 Specifications

  • Output Power

    800 W per channel at 8 Ohms
    1050 W per channel at 4 Ohms
    600 W per channel at 2 Ohms

  • Amplifier Type

    Class D, balanced output circuit (BLT)

  • THD + N

    0.1% at 1 kHz, 10 W
    0.3% at 1 kHz, half power

  • Frequency Response

    20 Hz to 20 kHz, +/-1.0 dB (1 W at 8 Ohms)

  • Crosstalk

    <= -60 dB

  • S/N Ratio

    100 dB

  • Voltage Gain / Sensitivity

    At 8 Ohms, Maximum Volume:

    32.0 dB / +8.3 dBu (Gain Setting: 32 dB)
    26.0 dB / +14.3 dBu (Gain Setting: 26 dB)
    36.3 dB / +4 dBu (Gain Setting: 4 dB)
    26.3 dB / +14 dBu (Gain Setting: 14 dB)

  • Cooling

    2 x 16-step variable-speed fan (front-to-rear flow)

  • Maximum Input Voltage

    +24 dBu

  • Input Impedance

    20 kOhms (Balanced)
    10 kOhms (Unbalanced)

  • Sampling Frequency

    48 kHz

  • Converters

    A/D: 24-bit linear, 128 times over-sampling
    D/A: 24-bit linear, 128 times over-sampling

  • Signal Processing

    Input summing
    D-contour: FOH / MAIN
    Monitor
    OFF
    Delay: 0 to 74 ms
    HPF / LPF: Cutoff frequency 20 Hz to 20 kHz with polarity control
    Speaker Processor: 6-band PEQ / limiter / delay

  • Latency

    1.5 ms (analog input to speaker)

  • User Presets

    8 user presets

  • Factory Presets

    Speaker presets for Yamaha passive speakers

  • Connectors

    Analog Input
    2 x XLR-3-31
    2 x 1/4 TRS

    Speakers
    2 x Neutrik SpeakOn NL4
    2 x pairs of binding posts
    2 x 1/4" TS

    1 x AC inlet with AC cord clamp

    1 x USB 2.0 Type-A (female)

  • AC Power Requirements

    120 V / 60 Hz

  • Power Consumption

    280 W at 4 Ohms, 1/8 maximum power
    60 W at 4 Ohms, Idle

  • Operating Temperature

    32 to 104 deg. F (0 to 40 deg. C)

  • Storage Temperature

    -4 to 104 deg. F (-20 to 40 deg. C)

  • Dimensions (WxHxD)

    18.90 x 3.46 x 15.25" (480.06 x 87.88 x 387.35mm)

  • Weight

    15.87 lbs (7.20kg)

About Yamaha PX8 2x 1050W 4 Ohms Stereo Power Amplifier - SKU#1713291

If you're seeking a powerful, high-quality, and reliable stereo power amplifier, look no further than the PX8 2x 1050W 4 Ohms Stereo Power Amplifier. This advanced audio equipment, crafted by the reputable Yamaha brand, is a testament to their commitment to superior sound quality, impressive power output, and unwavering reliability.

This amplifier is part of Yamaha's new PX series, which continues their tradition of excellence by leveraging their renowned digital signal processing technology and unmatched professional audio expertise. The PX8 2x 1050W 4 Ohms Stereo Power Amplifier is designed to deliver maximum output power to your speakers while simultaneously protecting them with optimized processing.

The heart of this amplifier is a newly-developed Class-D engine, which concentrates all necessary functions into a single custom LSI chip. This innovative design uses PLL technology to control transfer characteristics in real time, resulting in remarkable sound quality and power. This single-chip architecture offers higher output and improved performance in a lightweight, yet durable design.

The PX8 2x 1050W 4 Ohms Stereo Power Amplifier is equipped with flexible onboard PEQ, crossover, filters, delay, and limiter functions. It also features Yamaha's intelligent D-CONTOUR multi-band dynamic processing, allowing users to achieve consistent clarity and high-quality sound for either front-of-house or monitor configurations.

This amplifier is suitable for a broad range of sound reinforcement and installation environments, capable of delivering 800W x 2 at 8 Ohms and 1050W x 2 at 4 Ohms. It also offers a versatile lineup of different power output capabilities, making it a perfect fit for a wide variety of sound reinforcement applications.

The PX8 2x 1050W 4 Ohms Stereo Power Amplifier is not only powerful and efficient but also user-friendly. It offers both Basic and Advanced setup modes to accommodate users with varying levels of sound reinforcement experience. Plus, it features eight programmable presets for instant recall and reduced setup time.

In terms of connectivity, this amplifier is equipped with both XLR and TRS inputs and binding post, SpeakON, and phone outputs. Its sturdy chassis and carrying handle design ensure durability and longevity, even with extended road-use.

In summary, the PX8 2x 1050W 4 Ohms Stereo Power Amplifier is a powerful, high-quality, and reliable audio equipment that delivers superior sound quality, impressive power output, and unwavering reliability. It's the perfect choice for anyone seeking a top-notch stereo power amplifier.

What's in the box:

  • Yamaha PX8 2x 1050W 4 Ohms Stereo Power Amplifier
  • AC Power Cord
  • Item Note: missing AC Plug Clamp; Missing USB Cap.
