Used PTZOptics 2.07MP Full HD NDI|HX Broadcast and Conference 30x PTZ Camera, White

SKU: US1958534 MFR: PT30X-NDI-WH
Earn VIP Reward Points

Key Features

  • 60.7 degree wide-angle lens
  • High performance in low light scenarios with Wide Dynamic Range
  • Full 1920x1080p HD Resolutions up to 60 frames per second
  • 2D and 3D noise reduction with our latest "low noise CMOS sensor"
  • RS232 & RS485 (Serial), IP (LAN/WAN) & NDI|HX Control
  • H.264, H.265 & MJPEG streaming over RJ-45 LAN port
See More Product Details

INCLUDES FREE WARRANTY

  • This used item comes with a free 180-day warranty. ?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$103.99

3 Year

$161.99

4 Year

$220.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

2023-03-22T09:32:28

Rated 5 out of 5

Awesome Camera for Streaming

We have a few of these cameras that are used for virtual and hybrid events. They have been great, easy to use and the picture is clear.

Benjamin H.

2022-12-05T05:26:26

Rated 4 out of 5

Great camera. Easy to use and Setup

Purchased this for streaming worship services. Camera has been phenomenal. I twas incredibly easy to setup and use. I love that it is POE capable and using it with the PTZ Optics IP joystick is a piece of cake. Setup was very easy for me. If you have a basic knowledge of networking it wont be a problem. Lighting in our sanctuary made setting the exposure a little tricky but all the settings were there to adjust things properly. My biggest complaint so far is that when moving between presets the Pan/Tilt/Zoom does not seem to sync properly. The movements between presets are smooth but the timing is weird and often the zoom will finish before the pan/tilt movements finish. All in all it was a great purchase and I would recommend it to anyone. The extra price for NDI was worth it for me to make it easier for volunteers to use.

MARK S.

2022-02-27T22:39:29

Rated 5 out of 5

Best PTZ Camer

Absolutely a great camera and we are now considering purchasing another one for our ministry.

JEFFREY P.

2021-04-18T10:34:30

Rated 5 out of 5

Five Stars

Optical zoom is fantastic. Love the single cable setup with POE. NDI works flawlessly with vMix.

DANIEL A.

2020-10-10T10:40:55

Rated 5 out of 5

Very Good

Very happy with camera, although just learning how to use it effectively.

PAUL L.

2020-08-06T10:02:51

Rated 5 out of 5

Jeff

Great range and controls.

JEFF S.

2020-07-24T14:40:49

Rated 4 out of 5

Great ptz

I just got this camera and so far it has been great. There is a little learning curve but doesn't take too long to get it.

GARRETT S.

2020-06-08T08:47:07

Rated 5 out of 5

Best for price

Best in price range. I would say it even better than some more expensive brands. This is my 4th camera from Ptzoptics. No complains at all.

YURIY H.

PTZOptics NDI|HX PTZ Camera Specifications

Camera & Lens

Camera & Lens

Jump to...
  • Video Sensor

    1/2.7" CMOS, 2.07 Mega Pixels

  • Frame Rates

    1080p/60, 50, 30 & 25, 1080i/60 & 50, 720p/60, 50, 30 & 25

  • Frame Rates (CVBS)

    576i/30, 480i/30 (CVBS)

  • Focal Length

    30x, F4.42mm-132.6mm, F1.8-F2.8

  • Lens Zoom

    30x

  • Field of View

    60.7 deg.

  • Min Lux

    0.5 Lux at F1.8, AGC ON

  • Shutter Speed

    1/30s - 1/10000s

  • SNR

    >=55dB

  • Vertical Flip & Mirror

    Supported

  • Horizontal Angle of View

    2.28 deg. (tele) to 60.7 deg. (wide)

  • Vertical Angle of View

    1.28 deg. (tele) to 34.1 deg. (wide)

  • Working Environment

    Indoor

Pan & Tilt Movement

Jump to...
  • Pan Movement

    +/-170 deg.

  • Tilt Rotation

    Up: 90 deg. , Down: 30 deg.

  • Presets

    10 via IR (255 via Serial or IP)

Rear Board

Jump to...
  • Network Interface

    RJ45

  • Audio Interface

    Line In, 3.5mm (NDI, HDMI & IP Stream)

  • Communication

    RS-232, RS485, PELCO-D/P, NDI

  • Baud Rate

    2400/4800/9600 bits

  • Power Supply

    JEITA type Power Adapter (DC IN 12V)

  • 3G-SDI Interface

    BNC - 75 Ohm, Female

  • USB 2.0 Interface

    Future Use

Electrical Index

Jump to...
  • Power Supply

    12W (Max)

  • Input Voltage

    12V DC (10.8 - 13.0V DC) or PoE 802.3af

Physical

Jump to...
  • Dimensions (WxHxD)

    5.6 x 6.5 x 6.7" (142.24 x 165.10 x 170.18mm) (7.8" (198.12mm)H max with Tilt)

  • Weight

    Camera: 3.10 lbs (1.41kg)

About PTZOptics 2.07MP Full HD NDI|HX Broadcast and Conference 30x PTZ Camera, White

FEATURED REVIEWS

Awesome Camera for Streaming

By Benjamin H.

We have a few of these cameras that are used for virtual and hybrid events. They have been great, easy to use and the picture is clear.

Best PTZ Camer

By JEFFREY P.

Absolutely a great camera and we are now considering purchasing another one for our ministry.

The PTZOptics 30X-NDI is a 1080p camera with 30X optical zoom for capturing HD images at long distances. With support for NDI|HX, 3G-SDI, HDMI and IP streaming (H.264, H.265 & MJPEG), this camera is ideal for broadcasting high definition video signals for broadcast, recording or videoconferencing applications.

PTZOptics 2.07MP Full HD NDI|HX Broadcast and Conference 30x PTZ Camera, White Features

  • 60.7 degree wide-angle lens
  • High performance in low light scenarios with Wide Dynamic Range
  • Full 1920x1080p HD Resolutions up to 60 frames per second
  • 2D and 3D noise reduction with our latest "low noise CMOS sensor"
  • RS232 & RS485 (Serial), IP (LAN/WAN) & NDI|HX Control
  • H.264, H.265 & MJPEG streaming over RJ-45 LAN port
  • HDMI, 3G-SDI & NDI or IP streaming (3 simultaneously)
  • PoE (Power over Ethernet) or 12VDC
  • RTMP, RTSP and NDI|HXTM

Warranty Information

This used item has a FREE 180-day warranty. See details.

Key Features

  • 60.7 degree wide-angle lens
  • High performance in low light scenarios with Wide Dynamic Range
  • Full 1920x1080p HD Resolutions up to 60 frames per second
  • 2D and 3D noise reduction with our latest "low noise CMOS sensor"
  • RS232 & RS485 (Serial), IP (LAN/WAN) & NDI|HX Control
  • H.264, H.265 & MJPEG streaming over RJ-45 LAN port
