Matrox Multi-I/O Simultaneous 4-Channel 3G/HD/SD Card
SKU: VDMRMULTIIO
This item is no longer available.
Share:
Overview
Compare
Learn
Specs
Protection
About Matrox Multi-I/O Simultaneous 4-Channel 3G/HD/SD C
The Matrox Multi-I/O Simultaneous 4-Channel 3G/HD/SD Card is designed for optimal performance, flexibility and scalability. They share a memory centric, asynchronous architecture that provides high-speed transfers of video, audio and graphics data between I/O peripherals, co-processors, the CPU and host memory. On-board DMA engines allow data transfers to occur without any intervention from the CPU. Dedicated on-board 10-bit hardware scalars off-load CPU or GPU processes.
The full range of broadcast-quality video/audio inputs and outputs are supported in NTSC and PAL as well as 480p, 720p, 1080p and 1080i HD resolutions at all frame rates. Support for 4:3 and 16:9 aspect ratios is provided. A variety of I/O configurations are available to meet your specific application needs. All of the hardware components are supported by the Matrox SDK for Mac.
Matrox Multi-I/O Simultaneous 4-Channel 3G/HD/SD C Features
- Single-slot, 3/4 length PCI-e x8 card fits into Mac Pros and Apple Xserve systems
- 10-bit hardware scaling engine supports up to four HD streams or six SD streams
- 16 embedded audio I/O channels per SDI stream
- 4 unbalanced analog audio channels for monitoring
- Analog blackburst reference input (tri-level or bi-level) with loop through
- Automatic video bypass and A/V watchdog support
- Auto-detection of input video resolutions Onboard live video mixer with zero frame delay
- One analog LTC input
- RS-422 port for device control
