Vivotek FD8166-F6 2MP Ultra-mini Fixed Dome Network Camera with 6mm Fixed-focal Lens, 1920x1080, 15fps, H.264, MJPEG, PoE

SKU: VIFD8166F6W

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Vivotek FD8166-F6 Specifications

  • CPU

    Multimedia SoC (System-on-Chip)

  • Flash

    16MB

  • RAM

    256MB

  • Image sensor

    1/2.7" progressive CMOS

  • Maximum Resolution

    1920 x 1080

  • Lens Type

    Fixed-focal

  • Focal Length

    f=6mm

  • Aperture

    F1.6

  • Field of View

    56 deg. (horizontal)
    31 deg. (Vertical)
    64 deg. (Diagonal)

  • Shutter Time

    1/5 to 1/32,000 sec

  • Minimum Illumination

    0.18 Lux, 50 IRE

  • Pan Range

    45 deg.

  • Tilt Range

    33 to 90 deg.

  • Pan / Tilt / Zoom

    ePTZ: 48x digital zoom ( 4x on IE plug-in, 12x built-in )

  • On-board Storage

    MicroSD/SDHC/SDXC card slot

  • Video Compression

    H.264 & MJPEG

  • Maximum Frame Rate

    H.264: 15fps at 1920 x 1080, 30fps at 1280 x 800
    MJPEG: 15fps at 1920 x 1080, 30fps at 1280 x 720

  • Maximum Streams

    2 simultaneous streams

  • S/N Ratio

    Above 53dB

  • Video Streaming

    Adjustable resolution, quality and bitrate
    Configurable video cropping for bandwidth saving

  • Image Settings

    Adjustable image size, quality and bit rate
    Time stamp, text overlay, flip & mirror
    Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
    Scheduled profile set

  • Audio Capability

    Audio input

  • Audio Compression

    G.711

  • Audio Interface

    Built-in microphone

  • Effective Range

    5m / 16.40'

  • Users

    Live viewing for up to 10 clients

  • Protocols

    IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X

  • Network Interface

    10Base-T / 100BaseTX Ethernet (RJ-45)
    It is highly recommended to use standard Cat. 5e & Cat. 6 cables which are compliant with the 3P/ETL standard

  • ONVIF

    Supported

  • Video Motion Detection

    Triple-window video motion detection

  • Alarm Triggers

    Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection

  • Alarm Events

    Event notification using HTTP, SMTP, FTP and NAS server
    File upload via HTTP, SMTP, FTP and NAS server

  • Connectors

    RJ-45 for Network/PoE connection
    1 x Digital input

  • LED Indicator

    System power and status indicator

  • Power input

    802.3af Power-over-Ethernet (Class 1)

  • Power consumption

    Maximum 2.9 W

  • Safety Certifications

    CE C-Tick FCC ( Class B ) LVD VCCI

  • Operating Temperature

    32 to 122 deg. F (0 to 50 deg. C)

  • Operating System

    Microsoft Windows 7 / Vista / XP / 2000

  • Browser

    Mozilla Firefox 7 - 10 (Streaming only)
    Internet Explorer 7.x or 8.x

  • Other Players

    VLC: 1.1.11
    QuickTime: 7 or above

  • Dimensions

    Dia.: 3.54 x 1.97" (90 x 50mm)

  • Weight

    5.08 oz (144g)

About Vivotek FD8166-F6

VIVOTEK FD8166 is the world's smallest network fixed dome camera. With installation as easy as one-two-three and Power over Ethernet (PoE) functionality, setup time is completed in less than 120 seconds, making installation quick and easy. The FD8166 features a 2-Megapixel sensor enabling viewing resolution of 1920 x 1080 at 15fps and also supports the industry-standard H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth. With MJPEG compatibility also included, video streams can also be transmitted in any of these formats for versatile applications.

Designed with selectable focal lengths, FD8166 can be used in various environments, including but not limited to offices, elevators, campus, chain stores, boutique stores and health care facilities. At the size of only 90 mm in diameter, VIVOTEK FD8166 is truly an all-in-one surveillance solution that meets a wide variety of needs for indoor surveillance. The package also includes VIVOTEK's 32-channel recording software. With all this and more, the FD8166 is the ideal solution for your surveillance needs.

Vivotek FD8166-F6 Features

  • 2-Megapixel CMOS Sensor
  • 15fps at 1920 x 1080
  • Real-time H.264, MJPEG Compression (Dual Codec)
  • Built-in IEEE 802.3af Compliant PoE
  • Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
  • Compact and Stylish Design
  • Easy Installation

What's in the box:

  • Vivotek FD8166-F6 2MP Ultra-mini Fixed Dome Network Camera with 6mm Fixed-focal Lens
  • CD (User's Manual
  • Quick Installation Guide
  • Installation Wizard 2
  • ST7501 32-Channel Recording Software)
  • Focus Kit
  • Screw Pack
  • Vivotek 2 Year Warranty
