Review Summary
1/2.7" Progressive CMOS
SD: 1280 x 960
HD: 2560 x 1920
Motorized, Vari-focal, Remote Focus
f = 2.8-10mm
Wide: f/1.8
Tele: f/2.74
Fixed iris
95 Degree -41 Degree (Horizontal)
69 Degree -31 Degree (Vertical)
127 Degree -51 Degree (Diagonal)
Pan 350 Degree
Tilt: 80 Degree
Rotate: +/-175 Degree
1/5 second to 1/32,000 second
Yes
Yes
98.43' (30m)
WDR Pro
0.06 lux @ f/1.8 (Color)
0.01 lux @ f/1.8 (B/W)
0 lux with IR illumination on
MicroSD/SDHC/SDXC card slot (Built-in 256GB industrial SD Card)
15FPS
HD Video 2560 x 1920@15fps 1.2Mbps upload
SD Video 1280 x 960@15fps 300Kbps upload
One-way Audio
Built-in microphone
16.4' (5m)
IEEE 802.3af PoE Class 0
IR on: 9.7 W (Max.)
IR off: 7.3 W (Max.)
RJ-45 cable connector for 10/100 Mbps PoE network connection
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Up to 6 clients
Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
10 Base-T/100 Base-TX Ethernet (RJ-45)
Yes
Yes
Intrusion detection, Line crossing detection, Loitering detection, Unattended object detection, Missing object detection
Deep search, Scene search, Think search, Event insight
White
Plastic
Starting: 32 Degree F to 122 Degree F (0 Degree C to 50 Degree C)
Working: IR off: 14 Degree F to 122 Degree F (-10 Degree C to 50 Degree C)
IR on: 14 Degree F to 113 Degree F (-10 Degree C to 45 Degree C)
90% RH (non-condensing)
EMC: CE (EN55032, EN55024 Class B, E50121-4), FCC (FCC Part 15 Subpart B Class B), RCM (AS/NZS CISPR32 Class B), VCCI (VCCI-CISPR 32 Class B)
Safety: UL (UL62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471)
Taiwan
5.12 x 3.74" (130 x 95mm)
12.52 oz (355g)
4710469355066
Monitor Anywhere, Anytime, Any Device
VORTEX unifies surveillance extensions on one platform, offering seamless consistency with various cameras. Automate tasks for better productivity and efficiency. Enjoy seamless remote management with instant notifications to your mobile, email, sirens, and Webhooks, ensuring simplified IT maintenance.
AI Analytics for Comprehensive Surveillance
VORTEX provides real-time alerts and notifications via AI analytics like intrusion, line-crossing, and loitering detection. Its machine learning capabilities enhance accuracy over time, ensuring robust surveillance and peace of mind.
Streamline Your Surveillance with Deep Search
Quickly review camera footage with the Scene Search feature from Deep Search tab page. Use intrusion, line crossing, or loitering detection to enhance efficiency. Draw a line at any point of interest and select a timeframe to find all events where a person or vehicle crossed that line. This allows users to identify and respond to security incidents swiftly.
