Vivotek FD8373-EHV Specifications

  • CPU

    Multimedia SoC (System-on-Chip)

  • Flash Memory

    128MB

  • RAM

    256MB

  • Image Sensor

    1/3" Progressive CMOS

  • Maximum Resolution

    2048 x 1536

  • Lens Type

    Vari-focal, remote focus

  • Focal Length

    f = 2.8 - 12mm

  • Aperture

    F1.8 - F2.85

  • Auto-iris

    P-iris

  • Field of View

    29.7 - 82.6 deg. (Horizontal)
    22.4 - 61.9 deg. (Vertical)
    37.6 - 108.7 deg. (Diagonal)

  • Shutter Time

    1/5 to 1/32000sec

  • WDR Technology

    WDR Pro

  • Day & Night

    Removable IR-cut filter for day & night function
    Smart IR Technology to Avoid Overexposure

  • Minimum Illumination

    0.33 Lux at F1.8 (Color)
    0.001 Lux at F1.8 (B/W)

  • PTZ Functionalities

    ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)

  • IR Illuminators

    Built-in IR illuminators, effective up to 20m 4x IR LED, with Smart IR Technology

  • On-board Storage

    MicroSD/SDHC/SDXC card slot

  • Video: Compression

    H.264 & MJPEG

  • Video: Maximum Frame Rate

    H.264: 20fps at 2048 x 1536; 30fps at 1920 x 1080
    MJPEG: 20fps at 2048 x 1536; 30fps at 1920 x 1080

  • Video: Maximum Streams

    3 simultaneous streams

  • Video: S/N Ratio

    Above 62dB

  • Video: Dynamic Range

    100dB

  • Video: Streaming

    Adjustable resolution, quality and bitrate

  • Video: Image Settings

    Adjustable image size, quality and bit rate
    Time stamp, text overlay, flip & mirror
    Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
    Scheduled profile settings
    3D Noise Reduction
    Smart Stream Seamless recording, new text on video
    SD recording 1HR

  • Audio: Capability

    Audio input/output (full duplex)

  • Audio: Compression

    AAC, G.711, G.726

  • Audio: Interface

    External microphone input and Output

  • Network: Users

    Live viewing for up to 10 clients

  • Network: Protocols

    IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X

  • Network: Interface

    10Base-T/100 BaseTX Ethernet (RJ-45)

  • Network: ONVIF

    Supported, specification available at www.onvif.org

  • Intelligent Video: Motion Detection

    Triple-window video motion detection

  • Alarm Triggers

    Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection

  • Alarm Events

    Event notification using HTTP, SMTP, FTP, NAS server
    File upload via HTTP, SMTP, FTP and NAS server

  • Smart Focus System

    Remote focus

  • Connectors

    RJ-45 for Network/PoE connection
    Audio input
    Audio output
    AC 24V power input
    DC 12V power input
    Digital input
    Digital output

  • LED Indicator

    System power and status indicator

  • Power Input

    DC 12V
    AC 24V
    IEEE 802.3af PoE Class 3

  • Power Consumption

    DC: Max.25.2W (Heater on), 11W (Heater off)
    AC: Max. 26.25W (Heater on), 12.5W (Heater off)
    PoE: Max. 11W

  • Casing

    Weather-proof IP66-rated housing
    Vandal-proof IK10-rated metal housing

  • Safety Certifications

    CE, LVD, FCC Class A, VCCI, C-Tick, UL

  • Operating Temperature

    Starting Temperature: -40 - 50 deg. C / -40 - 122 deg. F
    PoE: -10 - 50 deg. C / 14 deg. F - 122 deg. F
    Working Temperature: -50 - 50 deg. C /-58 - 122 deg. F
    PoE: -20 - 50 deg. C / -4 deg. F - 122 deg. F

  • Operating System

    Microsoft Windows 7/Vista/XP/2000

  • Web Browser

    Mozilla Firefox 7 - 10 (Streaming only)
    Internet Explorer 7/8/9/10

  • Players

    VLC: 1.1.11 or above
    QuickTime: 7 or above

  • Dimensions (Dia. x H)

    6.81 x 4.53" / 173 x 115mm

  • Weight

    43.74oz / 1240g

  • UPC Code

    4712123674261

About Vivotek FD8373-EHV

VIVOTEK's FD8373-EHV network camera features a 3-Megapixel WDR CMOS sensor to cope with challenging lighting conditions. The WDR Pro feature allows the camera to capture both the dark and bright areas of an image and combine the differences to generate a highly realistic representation of the original scene. This feature enables the camera to provide video quality very close to the capabilities of the human eye. The FD8373-EHV can be deployed widely in high contrast outdoor environments such as parking areas and streets.

The P-iris lens controls the iris with extreme precision; with its built-in stepper motor, it maintains the iris opening at an optimal level at all times, resulting in superior image clarity and depth of field. The IP66-rated housing is designed to help the camera body withstand rain and dust and ensures smooth operation even under a multitude of harsh weather conditions while its IK10-rated housing can provide the protection against the vandal act and impact. Additionally, the wide temperature range further enhances the FD8373-EHV's performance and reliability in extremely cold environments.

Vivotek FD8373-EHV Features

  • 3-Megapixel CMOS Sensor
  • 20 fps at 2048x1536
  • Motorized, P-iris Lens
  • Smart IR Technology to Avoid Overexposure
  • Built-in IR Illuminators, Effective up to 20 Meters
  • Smart Stream
  • 3D Noise Reduction
  • Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
  • WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
  • Smart Focus System for Remote and Precise Focus Adjustment
  • Two-way Audio
  • Weather-proof IP66-rated Housing
  • Vandal-proof IK10-rated Housing

Key Features

  • 20 fps at 2048x1536
  • Smart Stream
  • 3D Noise Reduction
  • Two-way Audio

What's in the box:

  • Vivotek FD8373-EHV 3MP Day & Night Outdoor Fixed Dome Network Camera
  • CD (User's Manual / Quick Installation Guide / Installation Wizard 2 / Free ST7501 32-Channel Recording Software)
  • Alignment Sticker
  • Mounting Plate
  • L-type Hex Key Wrench
  • Desiccant Bag
  • Screws
  • Hex Nut
  • Double-Sided Tape
  • AV Cable
  • Waterproof Connector
  • Bushing
  • DC Connector
  • Software CD
  • Quick Installation Guide
  • Vivotek 3 Year Warranty
