Vivotek IB8369 2MP Day & Night Outdoor Bullet Network Camera, 1920x1080, 30fps, H.264, MJPEG, PoE

SKU: VIVIB8369

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Vivotek IB8369 Specifications

  • System: CPU

    Multimedia SoC (System-on-Chip)

  • System: Flash

    128MB

  • System: RAM

    256MB

  • Camera: Image Sensor

    1/2.7" Progressive CMOS

  • Camera: Maximum Resolution

    1920x1080 (2MP)

  • Camera: Lens Type

    Fixed-focal

  • Camera: Focal Length

    f = 3.6mm

  • Camera: Aperture

    F2.0

  • Camera: Field of View

    84 deg. (Horizontal)
    68 deg. (Vertical)
    114 deg. (Diagonal)

  • Camera: Shutter Time

    1/5 sec. to 1/32,000 sec.

  • Camera: WDR Technology

    WDR Enhanced

  • Camera: Day/Night

    Removable IR-cut filter for day & night function

  • Camera: Minimum Illumination

    0.78 Lux at F2.0 (Color)
    0.006 Lux at F2.0 (B/W)
    0 Lux at IR LED ON

  • Camera: Pan/tilt/zoom Functionalities

    ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)

  • Camera: IR Illuminators

    Built-in IR illuminators, effective up to 20 meters with Smart IR
    6x IR LED

  • Camera: On-board Storage

    MicroSD/SDHC/SDXC card slot

  • Video: Compression

    H.264 & MJPEG

  • Video: Maximum Frame Rate

    30fps at 1920x1080
    In both compression modes

  • Video: Maximum Streams

    3 simultaneous streams

  • Video: S/N Ratio

    Above 53dB

  • Video: Dynamic Range

    54.5dB

  • Video: Streaming

    Adjustable resolution, quality and bitrate
    Configurable video cropping for bandwidth saving

  • Video: Image Settings

    Adjustable image size, quality and bit rate
    Time stamp, text overlay, flip & mirror
    Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
    Scheduled profile settings, 3D Noise Reduction

  • Network: Users

    Live viewing for up to 10 clients

  • Network: Protocols

    IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP,FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP,ICMP

  • Network: Interface

    10 Base-T/100 BaseTX Ethernet (RJ-45)
    It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard

  • Network: ONVIF

    Supported

  • Intelligent Video Motion Detection

    Triple-window video motion detection

  • Alarm Triggers

    Video motion detection, manual trigger, periodical trigger,system boot, recording notification, camera tampering detection

  • Alarm Events

    Event notification using digital output, HTTP, SMTP, FTP and NAS server
    File upload via HTTP, SMTP, FTP and NAS server

  • Connectors

    RJ-45 for Network/PoE connection

  • LED Indicator

    System power and status indicator

  • Camera: Casing

    Weather-proof IP66-rated housing
    Mounting Bracket with Cable Management

  • Safety Certifications

    CE, LVD, FCC Class A, VCCI, C-Tick

  • System Requirements: Operating System

    Microsoft Windows 7/Vista/XP/2000

  • System Requirements: Web Browser

    Mozilla Firefox 7 to 10 (streaming only)
    Internet Explorer 7/8/9

  • System Requirements: Other Players

    VLC: 1.1.11 or above
    QuickTime: 7 or above

  • Power Input

    DC 12V
    IEEE 802.3af PoE Class 3

  • Power Consumption

    Max. 6.5W (DC12V)
    Max. 7.5W (PoE)

  • Operating Temperature

    Starting Temperature: -10 to 50 deg. C / 14 to 122 deg. F
    Working Temperature: -20 to 50 deg. C / -4 to 122 deg. F

  • Dimensions (Dia. x H)

    77 x 211mm / 3.03 x 8.31"

  • Weight

    Net: 720g / 25.40oz
    Bracket: 300g / 10.58oz

  • UPC Code

    4712123674070

About Vivotek IB8369

VIVOTEK IB8369 is a best-in-class, bullet-style network camera designed for diverse outdoor applications. Equipped with a 2MP sensor enabling viewing resolution of 1920x1080 at a smooth 30 fps, the IB8369 is an all-in-one outdoor camera capable of capturing high quality and high resolution video up to 2 Megapixel. In order to adapt to constantly changing outdoor lighting conditions, the IB8369 features a removable IR-cut filter as well as IR illuminators effective up to 20M for superior image quality around the clock.

For protection against harsh outdoor environments, the camera is encased in an IP66-rated housing and weather-proof casing to withstand rain and dust. The IB8369 further strengthens the robustness of the camera by protecting the cable within the bracket. The IB8369 supports the industry-standard H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth.

With H.264 & MJPEG compatibility all included, multiple streams can be simultaneously transmitted in any of these formats at different resolutions, frame rates and image qualities for versatile platforms. The streams can also be individually configured to meet different needs or bandwidth constraints, thereby further optimizing bandwidth and storage. Incorporating a number of advanced features standard for VIVOTEK cameras, including tamper detection, 802.3af compliant PoE, MicroSD/SDHC/SDXC card slot and VIVOTEK's 32-channel recording software, the IB8369 is the ideal solution for your outdoor surveillance needs.

Vivotek IB8369 Features

  • 2-Megapixel CMOS Sensor
  • 30 fps at 1920x1080
  • Real-time H.264, MJPEG Compression (Dual Codec)
  • Removable IR-cut Filter for Day & Night Function
  • Built-in IR Illuminators, Effective up to 20 Meters
  • Built-in 802.3af Compliant PoE
  • Build-in MicroSD/SDHC/SDXC card slot for On-board Storage
  • Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
  • Weather-proof IP66-rated Housing
  • Mounting Bracket with Cable Management for Protected Installation
  • 3D Noise Reduction
  • Smart IR Technology to Avoid Overexposure
  • WDR Enhancement for Unparalleled Visibility in Extremely Bright and Dark Environments

Key Features

  • 30 fps at 1920x1080
  • Mounting Bracket
  • 3D Noise Reduction

What's in the box:

  • Vivotek IB8369 2MP Day & Night Outdoor Bullet Network Camera
  • Alignment Sticker
  • Desiccant Bag
  • Cable Management Bracket
  • Screw Pack
  • Quick Installation Guide
  • CD (User's Manual & Quick Installation Guide & Installation Wizard 2 & ST7501 32-Channel Recording Software)
  • Vivotek 2 Year Warranty
