See Options
Need help? Ask our experts.
Review Summary
1/2.8" Progressive CMOS
SD: 1280 x 960
HD: 2560 x 1920
Motorized, Vari-focal, Remote Focus
f = 2.7-13.5mm
f/1.4-2.8
P-iris
95 Degree - 30 Degree (Horizontal)
70 Degree - 23 Degree (Vertical)
128 Degree - 38 Degree (Diagonal)
Pan: +/-180
Tilt: 90 Degree
Rotate: +/-180 Degree
1/5 second to 1/32,000 second
Yes
Yes
164.04' (50m)
WDR Pro
0.075 lux @ f/1.4 (Color)
<0.01 lux @ f/1.4 (B/W)
0 lux with IR illumination on
MicroSD/SDHC/SDXC card slot (Built-in 256GB industrial SD Card)
15FPS
HD Video 2560 x 1920@15fps 1.2Mbps upload
SD Video 1280 x 960@15fps 300Kbps upload
Two-way Audio (License required to enable speaker talk-down feature)
External microphone Input
External line output
AC 24V, DC 12V, IEEE 802.3at PoE Class 4 (Power Redundancy)
PoE: Max. 25W / 20W (IR on/off)
DC 12V: Max. 29.5W / 24W (IR on/off)
AC 24V: Max: 28W/22.5W (IR on/off)
RJ-45 cable connector for 10/100 Mbps PoE network connection
Audio line input
Audio line output
DC 12V power input/AC 24V power input
2x Digital input
2x Digital output
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Up to 6 clients
Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
10 Base-T/100 Base-TX Ethernet
Yes
Yes
Intrusion detection, Line crossing detection, Loitering detection, Unattended object detection, Missing object detection
Attribute search, Scene search, Re-search, Profile search, LPR search, Think search, Event insight
Facial recognition, License plate recognition
White
Metal
Starting: -14 Degree F to 140 Degree F (-10 Degree C to 60 Degree C)
Working: IR off: -22 Degree F to 140 Degree F (-30 Degree C to 60 Degree C)
IR on: -22 Degree F to 122 Degree F (-30 Degree C to 50 Degree C)
90% RH (non-condensing)
EMC: CE (EN55032 Class A,EN55035), FCC (FCC Part 15 Subpart B Class A), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A)
Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22)
Environment: IK10 (IEC 62262), IP66 (IEC 60529), IP67
Taiwan
4.65 x 11.60" (118 x 294.6mm)
3.13 lbs (1.42kg)
4710469355073
Monitor Anywhere, Anytime, Any Device
VORTEX unifies surveillance extensions on one platform, offering seamless consistency with various cameras. Automate tasks for better productivity and efficiency. Enjoy seamless remote management with instant notifications to your mobile, email, sirens, and Webhooks, ensuring simplified IT maintenance.
AI Analytics for Comprehensive Surveillance
VORTEX provides real-time alerts and notifications via AI analytics like intrusion, line-crossing, and loitering detection. Its machine learning capabilities enhance accuracy over time, ensuring robust surveillance and peace of mind.
Streamline Your Surveillance with Deep Search
Quickly review camera footage with the Scene Search feature from Deep Search tab page. Use intrusion, line crossing, or loitering detection to enhance efficiency. Draw a line at any point of interest and select a timeframe to find all events where a person or vehicle crossed that line. This allows users to identify and respond to security incidents swiftly.
Advanced Deep Search with Attributes
VORTEX's Deep Search leverages AI for efficient and enhanced search capabilities. It includes Attribute Search, Scene Search, and Re-Search. Using metadata-defined attributes and rules eliminates the need to scroll through footage, enabling faster, smarter, and easier video evidence searches. Quickly find the target person or vehicle by setting criteria such as gender or license plate number.
