Vivotek C-Series IB9380-HTV-V2 5MP AI Outdoor Network Bullet Camera with Night Vision, Black/White

SKU: VIVIB9380HTV MFR: IB9380-HTV-V2
Earn VIP Reward Points

Key Features

  • Experience crystal-clear 5MP video quality, ensuring every detail is captured for your peace of mind.
  • Advanced night vision with Smart IR provides superior security, even in complete darkness, up to 30 meters.
  • Benefit from intelligent motion detection, instantly alerting you to any activity around your property.
  • Enjoy convenient remote access to your security camera feed from anywhere, using your smartphone or tablet.
  • The weatherproof design ensures reliable performance in any climate, protecting your home year-round.
  • Installation is a breeze with this user-friendly security camera, getting you set up quickly and efficiently.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Vivotek C-Series IB9380-HTV-V2 Specifications

System
  • CPU

    Multimedia SoC (System-on-Chip)

  • Flash

    256MB

  • RAM

    512MB

  • Image Sensor

    1/2.7" Progressive CMOS

  • Max. Resolution

    2880x1616 (5MP)

  • Lens Type

    Motorized, Vari-focal, Remote Focus

  • Focal Length

    f = 2.7 - 13.5mm

  • Aperture

    f/1.6 - f/3.1

  • Iris Type

    Fixed iris

  • Field of View

    111 Degree - 32.2 Degree (Horizontal)
    57 Degree - 18 Degree (Vertical)
    136 Degree - 37 Degree (Diagonal)

  • Shutter Time

    1/5 sec. to 1/32,000 sec.

  • WDR Technology

    WDR Pro

  • Day/Night

    Yes

  • Removable IR-cut filter

    Yes

  • Illuminators

    Built-in IR Illuminator up to 30 meters with Smart IR, 2x IR LED

  • Minimum Illumination

    0.04 lux @ F1.6 (Color)
    0.005 lux @ F1.6 (B/W)
    0 lux with IR illumination on

  • Tilt Range

    90 Degree

  • Rotation Range

    180 Degree

  • Storage

    Seamless Recording to MicroSD/SDHC/SDXC card (1TB capacity supported) and recording to network-attached storage (NAS)

  • Built-in Installation Aids

    Pixel Calculator

  • Compression

    H.265, H.264, MJPEG

  • Maximum Frame Rate

    30 fps @ 2880x1616

  • Maximum Streams

    3 video streams (Up to 7 configurable profiles)

  • Main Stream

    30fps @2880x1616, 2688x1512, 2560x1440, 1920x1080, 1600x904, 1360x768, 1280x720, 640x360 (16:9)

  • 2nd Stream

    30fps @1920x1080, 1600x904, 1360x768, 1280x720, 640x360 (16:9)

  • 3rd Stream

    30 fps @ 1280x720, 640x360, 480x272 (16:9)

  • S/N Ratio

    52 dB

  • Dynamic Range

    120 dB

  • Video Streaming

    Adjustable resolution, quality and constant bit rate control, Smart Stream III

  • Image Settings

    General settings: Video title and time stamp overlay, video orientation (flip, mirror, rotation), day/night settings
    Illuminators: Illuminators, anti-overexposure/smart IR
    Image settings: White balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curve), defog, 3DNR
    Exposure: BLC, HLC, exposure control (exposure level, exposure time, gain control), AE speed adjustment, WDR Focus: zoom, focus
    Privacy mask
    Pixel calculator
    Scheduled profile settings

  • Audio Capability

    Two-way Audio

  • Compression

    MPEG-2 AAC-LC, G.711, G.726

  • Interface

    Built-in microphone
    External line Input
    External line output

  • Effective Range

    16.4' (5m)

Network

Jump to...
  • Users

    Live viewing for up to 10 clients

  • Security

    Access list, CSRF protection, digest authentication, HTTPS , IEEE 802.1x, Password protection, signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), user access log, user account management

  • Protocols

    802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2/1.3, UDP, UPnP

  • Interface

    10 Base-T/100 Base-TX Ethernet (RJ-45)

  • ONVIF

    Profile G, S, T supported, Onvif 21.06

AI Analytics

Jump to...
  • Compute Capability

    SoC with built-in hardware deep learning accelerator

  • Vision Object Analytics

    Object Detection: People, Vehicle (4-wheeled), Human / Vehicle Bestshot, Path Extraction

  • Application

    Deep Learning VCA (Smart Motion Detection, Smart VCA)
    Smart VCA - Group 1: Smart Motion Detection (Five-window video motion detection, People detection, Vehicle detection, Time filter), Smart VCA (Intrusion detection, Loitering detection, Line crossing detection)

Solution Integration

Jump to...
  • VADP Package

    Trend Micro (Default, 1-year free trial)

  • Video Motion Detection

    Motion Detection (Five-window video motion detection)

Alarm and Event

Jump to...
  • Event Trigger

    Periodically trigger, system boot, manual trigger, digital input, motion detection, tampering detection, recording notification

  • Event Action

    Event notification via camera link, email, HTTP, FTP/SFTP, NAS server, SD card
    File upload via email, HTTP, FTP, NAS server, SD card

System Requirements

Jump to...
  • Operating System

    Microsoft Windows 10/8/7
    Mac 10.12 (Chrome only)

  • Web Browser

    Chrome 58.0 or above

  • Other Players

    VLC: 1.1.11 or above

DORI (EN 62676-4 Standard)

Jump to...
  • Detection (25PPM/ 8PPF)

    Wide: 219.9' (67m)
    Tele: 674.8' (205.7m)

  • Observation (63PPM/ 19PPF)

    Wide: 87.5' (26.7m)
    Tele: 267.8' (81.6m)

  • Recognition (125PPM/ 38PPF)

    Wide: 43.7' (13.3m)
    Tele: 134.4' (41m)

  • Identification (250PPM/ 76PPF)

    Wide: 21.7' (6.6m)
    Tele: 67.1' (20.5m)

General

Jump to...
  • Color

    Black/White

  • Connectors

    RJ-45 cable connector for 10/100/100 Mbps Network/PoE connection
    Audio line input
    Audio line output
    DC 12V power input
    1x Digital input
    1x Digital output

  • LED Indicator

    System power and status indicator

  • Power Input

    IEEE 802.3af PoE Class 3
    DC 12V

  • Power Consumption

    DC12V: Max. 7.44W
    PoE: Max. 7.77W, typical 3.5W

  • Certifications

    EMC: CE (EN 55032/EN 55035 Class A), UKCA (BS EN 55032/BS EN 55035 Class A), FCC (FCC Part 15 Subpart B Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7, Class A)
    Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22,IEC/EN 62471), LVD (IEC/EN 62368-1), UKCA (BS EN 62368-1)
    Environment: IK10 (IEC 62262), IP66,IP67 (IEC 60529)
    IA: BSMI (EMC: CNS 15936, Safety: CNS 15598-1)

  • Operating Temperature

    Starting/Working: -22 Degree F - 140 Degree F (-30 Degree C - 60 Degree C)

  • Humidity

    90% RH (non-condensing)

  • Country of Origin

    Taiwan

  • Dimensions (Dia. x L)

    3.58 x 7.68" (91 x 195mm)

  • Weight

    26.7 oz (757g)

  • UPC Code

    4710469356179

About Vivotek C-Series IB9380-HTV-V2

See More Details with Robust Design

Clear details in 5MP resolution
With 5MP resolution and 30 fps recording, capture sharp, detailed footage without frame loss. High-resolution video offers enhanced visibility and stronger evidence for investigations.

Clear vision in high-contrast conditions
Powered by WDR Pro, the camera delivers sharp, high-quality images, ensuring accurate detail capture in difficult high-contrast conditions for comprehensive surveillance.

Balanced IR in nighttime
VIVOTEK's Smart IR technology optimizes infrared intensity to ensure optimal exposure, capturing details in low-light conditions. With an effective IR range of up to 30M, it delivers reliable nighttime vision.

Metal housing with IK10 certification
IK10 metal housing safeguards the camera from vandal attacks and retains its color for a long-lasting, polished look.

Built for Everyone: Smart, Secure, and Everyday-Ready Solution

Focus on people and vehicle
Effortlessly detect and distinguish people, vehicles with Vision Object Analytics-designed to prioritize what truly matters.

Accurate alarm with Smart VCA
VIVOTEK Smart VCA offers precise object tracking, detects specified abnormal behavior, and provides detailed video analytics for targeted monitoring and real-time alarm.

Easy operation with cloud solution
VORTEX integration via the V-series embedded NVR offers plug-and-play convenience and cloud-based push notification, supporting fast response from any device. The xLite license plan provides free cloud access, scalable expansion, and unified remote management.

End-to-end security, secured operation
VIVOTEK safeguards your surveillance system with layered security. From device-level protection with Trend Micro, Secure Boot, and Signed Firmware, to cloud-level safeguards like AES-256 encryption, TLS 1.2, and MFA authentication-your data and access are fully secured across the entire ecosystem.

Vivotek C-Series IB9380-HTV-V2 Features

  • Detect people & vehicles with Vision Object Analytics
  • Accurate alarm with Smart VCA
  • Built-in IRs up to 30M with Smart IR
  • Metal housing with IK10 certification
  • Cyber protection via Trend Micro IoT Security

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Experience crystal-clear 5MP video quality, ensuring every detail is captured for your peace of mind.
  • Advanced night vision with Smart IR provides superior security, even in complete darkness, up to 30 meters.
  • Benefit from intelligent motion detection, instantly alerting you to any activity around your property.
  • Enjoy convenient remote access to your security camera feed from anywhere, using your smartphone or tablet.
  • The weatherproof design ensures reliable performance in any climate, protecting your home year-round.
  • Installation is a breeze with this user-friendly security camera, getting you set up quickly and efficiently.

What's in the box:

  • Vivotek C-Series IB9380-HTV-V2 5MP AI Outdoor Network Bullet Camera
  • Alignment Sticker
  • Screw Set
  • Cable Gland
  • User Manual
  • Vivotek 3 Year Limited Warranty
