Vivotek IP8133W Specifications

  • Lens

    f=3.45mm
    F 2.4
    Board lens
    Fixed

  • Field of View

    47.4 deg. (Horizontal)
    30.6 deg.(Vertical)
    54.7 deg. (Diagonal)

  • Shutter Time

    1/5 to 1/25000sec

  • Image Sensor

    1/4" CMOS in 1280 x 800 Resolution

  • Minimum Illumination

    3.0 Lux at F2.4 (Color)

  • Video: Compression

    H.264, MPEG-4 & MJPEG

  • Video: Streaming

    Simultaneous multiple streams
    H.264 streaming over UDP, TCP, HTTP or HTTPS
    H.264/MPEG-4 multicast streaming
    MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
    MJPEG streaming over HTTP or HTTPS

  • Video: Frame rates

    H.264: Up to 30 fps at 1280x800
    MPEG-4: Up to 30 fps at 1280x800
    MJPEG: Up to 30 fps at 1280x800

  • Video: Image Settings

    Adjustable image size, quality, and bit rate
    Time stamp and text caption overlay
    Flip & mirror
    Configurable brightness, contrast, saturation, sharpness, white balance and exposure control
    AGC AWB AES
    Supports privacy masks
    BLC (Backlight compensation)

  • Video: Support

    Supports activity adaptive streaming for dynamic frame rate control
    Supports 3GPP mobile surveillance

  • Audio: Compression

    GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
    G.711 audio encoding, bit rate: 64 kbps, mu-Law or A-Law

  • Audio: Interface

    Built-in microphone
    Built-in speaker

  • Audio: Support

    Supports two-way audio, Supports audio mute

  • Network: Interface

    10/100 Mbps Ethernet, RJ-45
    Built-in 802.11b/g/n WLAN

  • Network: Protocols

    IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X

  • Network: ONVIF

    Supported, specification available at www.onvif.org

  • Alarm and Event Management

    Triple-window video motion detection
    1 D/I & 1 D/O for external sensor and alarm
    Event notification using HTTP, SMTP, FTP
    Local recording of MP4 files
    Tamper Detection
    PIR (Passive Infrared Sensor) for human detection
    White-light illuminators for low light condition when event triggered

  • Security

    Multi-level user access with password protection
    IP address filtering
    HTTPS encrypted data transmission
    Wireless: WEP, WPA-PSK, WPA2
    WPS - Wi-Fi Protected Setup

  • Users

    Live viewing for up to 10 clients

  • LED Indicator

    System power and status indicator
    System activity and network link indicator
    Privacy button on

  • Power

    5V DC

  • Power consumption

    Max. 4.7W
    802.3af Power-over-Ethernet (Class 2)

  • Approvals

    CE, LVD, FCC, VCCI, C-Tick

  • Operating Environments

    Temperature: 0 to 40 deg. C / 32 to 104 deg. F
    Humidity: 90%

  • Operating System

    Microsoft Windows 7/Vista/XP/2000

  • Browser

    Mozilla Firefox
    Internet Explorer 7.x or above

  • Players

    VLC: 10.5 or above
    QuickTime: 6.5 or above
    Cell phone: 3GPP player
    Real Player: 10.5 or above

  • Installation Management and Maintenance

    Installation Wizard 2
    ST7501 32-channel recording software
    Supports firmware upgrade

  • Applications

    SDK available for application development and system integration

  • Dimensions (D x W x H)

    1.26 x 3.11 x 3.15" / 32 x 79 x 80mm

  • Weight

    195g / 6.88oz

About Vivotek IP8133W

VIVOTEK IP8133(PoE)/33W(Wireless) are easy-to-use network cameras specifically designed for home security applications with compact, stylish exteriors. Equipped with a 1MP sensor enabling viewing resolution of 1280x800 at 30 fps, users need to look no further for an all-in-one camera capable of capturing high quality, high resolution video. The cameras support the industry-standard H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth. With MPEG-4 and MJPEG compatibility also included, video streams can also be transmitted in any of these formats for versatile applications.

The IP8133 & IP8133W add advanced functions such as PIR, white light LED and speaker. The wireless model IP8133W is embedded with dual antennas and IEEE 802.11n wireless technology, which greatly enhances the transmission and range of the wireless connection. Moreover, the WPS button ensures a minimum of configuration time for wireless connections. The cameras also include VIVOTEK's free ST7501 32-channel recording software. With all this and more, any user can quickly and easily view children, the elderly or even pets with live, clear videos while away from home.

Vivotek IP8133W Features

  • 1-Megapixel CMOS Sensor
  • Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
  • Privacy Button to Pause Monitoring
  • Tamper Detection for Unauthorized Changes
  • Built-in PIR Sensor for Unauthorized Intruder Detection
  • Built-in White-light Illuminators for Event Triggering
  • Built-in 802.11b/g/n WLAN
  • Wi-Fi Protected Setup (WPS) for Easy and Secure Wireless Network Connection
  • Built-in Microphone and Speaker for Two-way Audio
  • Compact, Elegant Design

Key Features

  • 1-Megapixel CMOS Sensor
  • Built-in 802.11b/g/n WLAN
  • Compact, Elegant Design

What's in the box:

  • Vivotek IP8133W 1MP Indoor Compact Fixed Network Camera
  • Power Adapter & Ferrite Core
  • Camera Stand
  • Screws
  • 2x Antenna
  • Software CD
  • Quick Installation Guide
  • Vivotek 2 Year Warranty
