Multimedia SoC (System-on-Chip)
8GB
2GB
1/2.8" Progressive CMOS
2560x1920 (5MP)
30x Optical Zoom, Auto Focus
4.94-148.24mm (30x zoom)
f/1.3-4.6
DC-Iris
54.1 Degree - 1.9 Degree (Horizontal)
41.2 Degree - 1.4 Degree (Vertical)
65.7 Degree -2.4 Degree (Diagonal)
1 sec. to 1/100,000 sec.
WDR Pro
Yes
Yes
0.045 lux @ F1.3 (Color)(30IRE)
<0.005 lux @ F1.3 (B/W)(30IRE)
0.05 Degree - 450 Degree /sec
360 Degree endless
0.05 Degree - 450 Degree /sec
-20 Degree - +90 Degree
Effective tilt coverage 220 Degree via auto flip
256 preset locations
128 presets per tour
8x digital zoom
Auto Pan mode
Auto Patrol mode
Mechanical Auto flip
Seamless Recording to MicroSD/SDHC/SDXC card (1TB capacity supported) and recording to network-attached storage (NAS)
Remote focus, remote zoom
H265, H264, MJPEG
30 fps @ 2560x1920 (WDR Pro on)
30 fps @ 2560x1440 (WDR Pro on)
60 fps @ 1920x1080 (WDR Pro off)
3 video streams (Up to 8 configurable profiles)
74 dB
120 dB
Adjustable resolution, quality and constrained bit rate control, Smart Stream III
General settings: video title and time stamp overlay, video orientation (flip, mirror), day/night settings
Image settings: white balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curve), defog, HLM, 3DNR, EIS, scene mode (auto, deblur)
Exposure: BLC, HLC, exposure control (exposure level, iris adjustment, exposure time, gain control, iris mode), AE speed adjustment, WDR
Focus
Privacy mask
Scheduled profile settings
Pixel calculator
Two-Way Audio (full duplex)
MPEG-2 AAC-LC, G.711, G.726
External line input
External line output
Live viewing for up to 10 clients
Access list, Account block, Audit log, Configurable password strength protection, CSRF protection, Digest authentication, Dos Protection, HTTPS, IEEE 802.1x, Secure boot, Session timeout, Signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), User access log, User account management
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2/1.3, UDP, UPnP
10 Base-T/100 Base-TX Ethernet (RJ-45)
Profile G, S, T, M supported
SoC with built-in hardware deep learning accelerator
Object Detection: People, Vehicle (4-wheeled, 2-wheeled), Human / Vehicle Bestshot, Path Extraction
Attribute Extraction: People (gender, clothing color, bag, hat), Vehicle (bike, bus, car, motorcycle, truck, color)
Human face Bestshot, Re-Search Extraction
Deep Learning VCA (Smart Tracking Advanced)
Smart VCA - Group 1: Smart VCA (Intrusion detection, Loitering detection, Line crossing detection, face detection)
Smart VCA - Group 2: Unattended object detection, Missing object detection
Smart VCA - Group 3: Parking Violation Detection, Restricted Zone Detection
Trend Micro IoT Security (3-year free trial)
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, smart tracking advanced trigger, system boot, preset reached
Event notification via audio clip, camera link, digital output, email, HTTP, FTP/SFTP, NAS server, SD card, push notification
File upload via email, HTTP, FTP/SFTP, NAS server, SD card
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only)
Chrome 58.0 or above
VLC: 1.1.11 or above
Wide: 341.8' (104.2m)
Tele: 11278.6' (3437.7m)
Wide: 136.5' (41.6m)
Tele: 3667.8' (1118m)
Wide: 68' (20.7m)
Tele: 1879.8' (573m)
Wide: 33.9' (10.3m)
Tele: 972.3' (296.4m)
White
RJ-45 cable connector for 10/100Mbps Network/PoE connection
Audio line input
Audio line output
DC 48V power input
AC 24V power input
2x Digital input
1x Digital output
1x RS-485
System power and status indicator
AC 24V, DC48V, IEEE 802.3 at PoE class 4 (Simultaneous Power Redundancy Supported)
PoE: Max: 22.5W/25.5W (Heater & Fan off/on)
DC 48V: Max: 22.5W/25.5W (Heater & Fan off/on)
AC 24V: Max: 22.5W/25.5W (Heater & Fan off/on)
EMC: CE (EN 55032 Class A, EN55035, EN50121-4), UKCA (BS EN 55032: 2015 +A11: 2020 , BS EN 55035: 2017), FCC (FCC Part 15 Subpart B Class A), IC (ICES-003:2020 Issue7, Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A)
Safety: UKCA (BS EN 62368-1:2014+A11:2017), UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471)
Environment: IK10 (IEC 62262), IP66 (IEC 60529), NEMA (NEMA 250 Type 4X
IA: BIS (IS 13252), BSMI (EMC: CNS 15936, Safety: CNS 15598-1)
Starting/Working Temperature: -40 Degree F - 131 Degree F (-40 Degree C - 55 Degree C)
98% RH (non-condensing)
Taiwan
6.85 x 10.87" (174x 276mm)
9.92 lbs (4.5kg)
4710469357152
Stay Alert while Patrolling with AI
Smart Tracking Advanced combines autonomous patrolling with AI detection to deliver continuous full scene coverage. The camera instantly locks onto and tracks abnormal events until they leave the frame, ensuring faster response and enhancing overall security operations.
Exceptional Imaging Performance in Any Distance
This camera is powered by Sony Starvis II sensors, delivering clear imaging and intelligent tracking in any scenario. With 30x optical zoom, it enables users to capture both wide-area overviews and fine details from a distance. It also features WDR Pro, providing sharp, high-quality images that preserve accurate detail even in challenging high-contrast conditions.
Effortless and Flexible Deployment
This camera's compact, lightweight design makes it easier to install without drawing attention or taking up space. With less power consumption, it runs on standard PoE without requiring additional high-wattage equipment, cutting both hardware and labor costs. Built with industry-grade durability, it delivers reliable performance indoors, semi-outdoors-offering users a flexible and cost-efficient surveillance solution.
From Any Platform to Instant Insight
Easy integrate with any surveillance systems, whether manage cameras on-premises VMS - VAST Security Station(VSS) or on cloud platform-VORTEX, both provide a consistent user experience, including intuitive AI-powered search features and case management, users can quickly locate, consolidate, and manage footage. This reduces manpower and maintenance costs, and enables faster, more effective responses to incidents across any deployment scenario.
