This item is no longer available.
• 3G SDI LEVEL A/B (YCbCr, RGB 4:4:4) Support
• 12bit to 10bit Dithering / 10 bit Wide Gamut Panel
• Selectable Y/R/G/B Histogram (SD/HD SDI )
• Y Clip Guide Min/Max Select (SD/HD SDI)
• SDI Embedded 16CH Audio Level Meter / 2CH Select Audio Waveform
• Field Color Calibration Software (option) support
• RJ-45 Remote Control
• False Color(SD/HD SDI)
• DSLR Scaling (HDMI)
• Embedded SDI to HDMI Converter
• Focus Assist(SD/HDSDI)
• 3G-SDI: 3-Gbps (3G)-SDI, Automatically adapts to SMPTE and ITU digital video standards for 3G-SDI, HD-SDI and SDI.
• 3D LUT: 3D LUT improves the monitors additive color mixture (combination of RGB), a key factor in their ability to display neutral gray tones.
• Waveform: Display the Luma(Y), Chroma(Cb/Cr) and RGB Components of the input video signal.
• Vector Scope: Display an X-Y plot of two signals, revealing the detailed relationship between two signals. On screen display of chrominance information in Cb and Cr channels. Display can be opaque or solid against the visual display.
• JOG dial: Use JOG dial button (or the Up and Down cursor buttons) to highlight the function, display the items and change the setting value you want to change.
• UMD Dynamic: Supports Under Monitor Display function, using TSL Protocol.
• Closed Caption: Decoder supports CEA-608(ANC, Line21) / 708; Time Code: Support for VITC and LTC timecode display
• Color Calibration: By using the ViewZ VZ-CSP software along with relatively inexpensive colorimeter such as I-One and K-10A, you can get calibration results as close to using the actual CS-2000 hardware.
