ViewZ VZ-55UNBS 55" Full HD LED Video Wall Monitor with Daisy Chain
See all ViewZ items

ViewZ VZ-55UNBS 55" Full HD Ultra Narrow Bezel LED Video Wall Monitor with Daisy Chain, 1920x1080

SKU: VWVZ55UNBS

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

ViewZ VZ-55UNBS Specifications

Display

Display

Jump to...

  • Screen Size

    55"

  • Max Resolution

    1920 x 1080 at 60Hz

  • Pixel Pitch

    0.630 x 0.630mm

  • Brightness

    450cd/m2 (Typical)

  • Contrast Ratio

    5000:1

  • Aspect Ratio

    16:9

  • Viewing Angle (H/V)

    178 deg. /178 deg.

  • Display Color

    16.7M

  • Response Time

    < 8 ms

  • Active Display area (HxV)

    1209.6 x 680.4mm

Interface

Jump to...

  • Interface

    1x VGA In (15Pin D-Sub)
    1x DP In
    1x Component (Y, Pb, Pr - BNC) In
    1x DVI-D In
    1x DVI-D In
    1x HDMI In / 1x HDMI Out
    1x USB In (Upgrade)
    1x Serial (RJ-45) In / 1x Serial (RJ-45) Out
    1x RS-232 (RJ-45) In
    1x Audio Out

Support Refresh Rate

Jump to...

  • Support Refresh Rate

    HDMI (2.0) In / Out: 3840 x 2160 at 60Hz
    DP In: 3840 x 2160 at 30Hz
    DVI-D In: 3840 x 2160 at 30Hz
    VGA In: 1920 x 1080 at 75Hz

Special Functions

Jump to...

  • Bezel Width

    Bezel Width - TOP and LEFT Side: 0.096" (2.3mm)
    Bezel Width - BOTTOM and RIGHT Side: 0.053" (1.2mm)
    Bezel Width - ACTIVE to ACTIVE AREA: 0.149" (3.5mm) (Bezel to Bezel)

  • Advanced Anti-Image Residual Function

    Support

  • 3D Comb filter

    Support

  • Language

    English, Spanish, French and Portuguese

Mount

Jump to...

  • VESA

    600 x (100 x 4) mm / M6 x L12 screws

General

Jump to...

  • Transmitter - IR Remote Control

    Yes

  • Power

    Electrical Ratings: AC 100-240V, 50/60Hz
    Consumption: <= 180W (Max) / 2W (Standby)

  • Regulations

    FCC(A), RoHS

  • Operating Temperature/Humidity

    32 to 122 deg. F (0 to 50 deg. C)
    20% to 80% RH

  • Storage Temperature/Humidity

    32 to 140 deg. F (0 to 60 deg. C)
    10% to 90% RH

  • Compatible Mounts

    Wall: VZ-XMS, VZ-WM71
    Ceiling: VZ-CMK04, VZ-CMKiT-04

  • Dimensions (WxHxD)

    47.77 x 26.93 x 4.55" (121.34 x 68.40 x 11.56cm)

About ViewZ VZ-55UNBS

With a bezel thinner than 2 stacked quarters, the ViewZ UNBS security video wall monitors display brilliant HD images across multiple screens with virtually seamless gaps in-between. Designed to work with ViewZ PRO video wall processor series.

ViewZ VZ-55UNBS Features

  • Full HD 1080p CCTV LED Monitor / 1.07B color IPS Panel
  • 55" Black All Metal 1.2 mm Ultra-narrow Seamless Bezel
  • 1.07 Billion Color IPS Panel (10 bit)
  • 4K (3840x2160) Resolution / 16:9
  • HDMI (2.0) / DVI-D / DP / VGA
  • 3D Comb Filter / De-Interlace
  • Auto Power and Source Recovery
  • Daisy Chain System - HDMI up to 15 x 15
  • Frame Comp Function
  • Mullion Compensation Applied
  • Advanced Heat Management
  • AC100 to 240V (50/60Hz)
  • 3-Year Warranty

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • ViewZ VZ-55UNBS 55 " Full HD Ultra Narrow Bezel LED Video Wall Monitor
  • Remote Control
  • IR Receiver
  • AC Power Adapter
  • HDMI Cable
  • CAT5 Cable
  • Serial Cable
  • Manual
  • ViewZ 3 Year Warranty
