ViewZ VZ-PRO-4 4-Channel Full HD Video Wall Controller, 512GB

ViewZ VZ-PRO-4 4-Channel Full HD Video Wall Controller, 512GB

SKU: VWVZPRO4
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

ViewZ VZ-PRO-4 Specifications

General

General

Jump to...

  • Processor

    Intel Xeon E5 series processor

  • Storage

    2x 256GB SSD

  • RAM

    8GB DDR3 (option: 16GB available)

  • Graphic

    1x VIA uD8-42(output) & 1x VIA cP4(input) PCI-E graphic cards

Interface

Jump to...

  • DVI (uD8) Input

    4

  • HDMI (DMS-59) Output

    4

  • USB 3.0 / 2.0

    2 / 2

  • Serial Port

    1

  • Network (RJ-45)

    2 - 10/100/1000 Base-T

  • VGA Output (Onboard Video)

    1

Resolution

Jump to...

  • Per Channel / Display

    Up to 1920 x 1080 (4 output = 4K (3840 x 2160))

Media Support

Jump to...

  • Video Codec

    H.264, MPEG-4, VC-1, WMV9

  • Video File Format

    WMV, AVI, MKV, ASF, FLV, MOV

  • Image File Format

    JPEG, BMP, PNG, TIFF

Mount

Jump to...

  • Server Chassis

    3U (19")

Power

Jump to...

  • Power Supply

    2 x 920W PSU

  • Power Input

    100 - 240V AC

Enviromental

Jump to...

  • Operating Temperature

    41 Degree F - 95 Degree F (5 Degree C - 35 Degree C)

  • Operating Humidity

    0 - 90% RH

Physical

Jump to...

  • Dimensions (W x H x D)

    17.2 x 25.5 x 5.2" (437 x 648 x 132mm)

  • Weight

    54.4 lbs (24.67kg)

About ViewZ VZ-PRO-4

The PRO Video Wall Controller series maximizes visual performance and flexibility from video inputs to array of displays. Your display setup becomes an open canvas which allows for combination of inputs or archived media to be displayed in any variation across all screens.

ViewZ VZ-PRO-4 Features

  • Up to 4 Full HD video inputs and outputs
  • Flexible video processing
  • Simultaneous 1080p video playback support
  • Spectacular Ultra HD (4K) support for outstanding visual experiences
  • Content management software
  • Designed to operate 24/7/365 in mission-critical installations
  • Available HDCP compatibility add-on option
  • Industrial grade highperformance systems based on Intel Xeon CPU, Windows 7 Professional OS
  • Redundant power supply and RAID options for maximum reliability
  • Max bit rate - 100Mbps (4 channel)
  • Multiple IP cameras can be displayed
  • Display Multiple Input Sources

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Up to 4 Full HD video inputs and outputs
  • Flexible video processing
  • Simultaneous 1080p video playback support
  • Spectacular Ultra HD(4K) support for outstanding visual experiences
  • Content management software
  • Designed to operate 24/7/365 in mission-critical installations

What's in the box:

  • VZ-PRO-4 4-Channel Full HD Video Wall Controller
  • Optical Mouse and Keyboard
  • 4x SATA Cables
  • 4x uD-HDMI Cable
  • 2x cP4 Cable
  • 2x Power Cable
  • Mount Bracket Set
  • 2x License Key USB
  • Manual
  • ViewZ 3 Year Warranty
