Walkera Scout X4 GPS Brushless Quadcopter with Devo F12E Transmitter, iLook+ Camera, 3D Gimbal and Ground Station RTF, FPV2 Version, White

SKU: WASCTX4FPV2

This item is no longer available.

Overview
Compare
Specs
Q&A

Questions & Answers

Shopper : Does this come with case ??ANDREW R : What's in the box: Walkera Scout X4 GPS Brushless Quadcopter Devo F12E Transmitter Flight Controller GPS Module Receiver G-3D Gimbal iLook+ Camera Ground Station Battery Charger Walkera Warranty

Reviews about this item

Review Summary

Walkera Scout X4 Specifications

  • Receiver

    DEVO-RX707(CE) / RX709(FCC)

  • Brushless motor

    500KV WK-WS-34-002

  • Brushless ESC

    WST-16AH (R/G)

  • Main Rotor Blade Length

    233mm / 9.17"

  • Main controller

    FCS-X4

  • Battery

    22.2V 6S 5400mAh Li-Po

  • Ground station

    GCS

  • 2.4G bluetooth datalink

    BT-2401A(FCC) / 2401B(FCC); BT-2402A(CE) / 2402B(CE)

  • Main rotor diameter

    244mm / 9.61"

  • Dimensions

    335 x 335 x 275mm / 13.19 x 13.19 x 10.83"

  • Takeoff Weight

    <2270g / <80.07oz

  • Weight

    1770g / 62.43oz (Battery included)

  • UPC Code

    679856035414

About Walkera Scout X4

Features such as waypoint mission planning (total of 128 waypoints), designated flight, follow me mode, follow record track back to home, real time telemetry monitoring, multi-purpose plane (can change from 4 motors to 8 motors) and a flight time up to 25min will make the Walkera Scout x4 Quadcopter a keeper. The built-in battery charge status lets you know how much power you have left before flight. This helps to promote a safe and convenient flight experience.

Pilot the Walkera Scout x4 Quadcopter with the DEVO F12E Remote. The DEVO F12E Remote displays your flight experience on a monitor that's embedded within the remote. It can be customized to show different languages to meet multinational user needs (English, Deutsh, Francais and Espanol).

Other features like the Telemetry function shows the voltage, temperature, GPS coordinates, altitude, distance, etc., all in real-time. The gimbal knob control has a comfortable ergonomic design which makes it easy when handling your gimbal. You'll be able to reach up to 1.5Km in transmit distance with the long range video transmitter. The DEVO F12E Remote is compatible with Walkera's helicopter, airplane and glider. It can memorize 15 model data, performs wireless transmission and has selectable TX power. It also has 32 channels built-in to receive 5.8GHz real-time images.

You'll have more control over your aerial shots with the G-3D Gimbal. The G-3D Gimbal provides a stable and simple operation for shooting videos. Made out of aluminum, the high precision brushless motor, drives the control system to give you excellent stability. The G-3D Gimbal supports several cameras such as iLook, iLook+, GoPro3 and GoPro3+ (iLook, GoPro3 and GoPro3+ Camera not included).

Combine your gimbal with the iLook +1080p HD camera. The iLook +1080p HD camera is equipped with a wide angle lens designed for aerial sport shots. It has a 5.8G real-time image transmission with an image transmission range up to 1km.

iLook +1080p HD Specs:
• Video Resolution: HD 1920 x 1080p
• Video Frame Rate: 30FPS
• Video Compressing Format: H.264
• Image Pixel: 300
• Resolution: 4032 x 3024 Pixels
• Video Format: MJPG

Waypoint mission planning
in line accordance with the fact of flight requirements to set airline and flying over the horizon (OTH). Toal 128 waypoint.

Designated Flight
Touch Mobile Screen and set take-off point and destination, it will under control anytime.

Follow me mode
Pre-set the object ti follow, no matter wherever it go, the plane will follow it and won't lost

Follow record track back to home
According to the pre-set airline , click the back button, the plane will turn back along the route.

Real time telemetry monitoring and iPad holder with back-up power
Real time elemetry monitoring: Using iPad holder is compatible with tablet phone, iPad, etc. Back-up power can extend the time of power supply.

Multi-purpose plane
can change from 4 motors into 8 motors, can improve the loaded ability.

Flight time of Up to 25 minutes
utilizing advanced high-capacity 22, 2V 5400mAh Lipo-Battery build in battery charge status monitoring promote safe and convenient flight operations.

GPS position Hold
New GPS flight control system featuring more accurate flight and GPS position hold.

Hyper IOC function
With the new advanced intelligent Orientation Control the h500 can start and fly in any orientation completely solving pilot "loss of orientation" problems.

Object round flight
The scout x4 can circle a GPS waypoint.

One key to start
Under the GPS mode, the copter can achieve one key to start and altitude hold, easy and convenient to operate.

One key go home
Support the "one key go home" function during flying.

Failsafe Return to home
Advanced RHT protects the aircraft in a case of loss of control signal, the h500 will automatically attempt to return to its starting position for a safe landing. Advanced GPS system protect your investment.

What's in the box:

  • Walkera Scout X4 GPS Brushless Quadcopter
  • Devo F12E Transmitter
  • Flight Controller
  • GPS Module
  • Receiver
  • G-3D Gimbal
  • iLook+ Camera
  • Ground Station
  • Battery
  • Charger
  • Walkera Warranty
