Wooden Camera Advanced Accessory Kit for Sony FS700 Camera, Includes Top Plate, Quick Base, 2x 15mm Rod (15"), NATO Handle Kit (Plus, 70mm), 1/4-20 Hot Shoe

The Sony FS700 Camera Accessory Kit (Advanced) is an advanced camera support package designed for the Sony FS700 cameras. The FS700 accessory package includes: Top Plate (FS700) camera cheeseplate for secure accessory attachment, the Quick Base (FS700), a quick release baseplate for holding the two 15mm Rods (15") at the correct lens height, NATO Handle Kit (Plus, 70mm), a quick release handle that attaches to the top plate, has a rotating top grip, multiple mounting points for accessories, integrated shoe mount and a 15mm/19mm rod opening and a 1/4-20 Hot Shoe for mounting accessories like microphones and camera flashes.

Top Plate (FS700)
Top plate for Sony NEX-FS700 camera. Arrays of 1/4-20 holes in Standard spacing. Multiple 3/8-16 holes for large accessories. Remove tape hook and install on side of Top Plate. Great for mounting EVF Mounts, Handles, external monitors and more.

Quick Base (FS700)
Quick Base (FS700) is a quick release baseplate for the Sony FS700 camera that provides lightweight 15mm pass through rods. The baseplate can attach to any tripod plate or ARRI standard bridgeplate such as Bridgeplate (19mm) or Bridgeplate (15mm Studio). When studio rods are not needed, a Dovetail Clamp can be added instead to interface with 2060 Dovetails, Safety Dovetails or Shoulder Rigs. Additional Rod Clamp (15mm LW) can be attached to rear of Quick Dovetail for independent rear rod support. To quick release out of dovetail/baseplate, turn thumbscrew and depress pin, move camera toward rear and remove.

• 1/4-20 and 3/8-16 holes for attaching accessories
• Quick release slot based on ARRI standard dovetail
• 1/4-20 and 3/8-16 holes on bottom for attaching to tripod or bridgeplate

Additional Options
• Rosette Bracket - attaches to Quick Base front, provides ARRI standard rosettes for attaching handles and extensions
• GO Shoulder - attaches to Quick Base rear, low profile shoulder pad for run and gun shooting

15mm Rod
15mm diameter iris rods used for mounting accessories like follow focus, matte box, lens support, servo motors and more.

NATO Handle Kit (Plus, 70mm)
The NATO Handle Kit (Plus, 70mm) is a quick release top handle that attaches and detaches without screws. Includes NATO Handle (Plus) and Safety NATO Rail (70mm) at a reduced package price. To attach to camera, slide onto NATO rail and turn thumbscrew to lock in place. Loosen top knob to adjust grip rotation. Sideways 15mm tube clamp allows for attachment of UVF Mount v2 (No Clamp). Forward facing 15mm rod opening and 19mm rear rod opening for attaching single rods for focus motors, etc. Integrated shoe mount for attaching on camera lights, microphone shock mounts, etc. 1/4-20 and 3/8-16 holes on grip area for attaching additional accessories. 1/4-20 holes on handle front for attaching Rod Clamps which allow for pass through rods front to back.

Safety NATO Rail (70mm), included in kit, attaches to two 1/4-20 screw points spaced up to 42mm apart center to center. Since NATO Handle (Plus) has integrated 15mm clamp mechanism, it goes great with UVF Mount (No Clamp) versions:
• UVF Mount (No Clamp)
• UVF Mount (F55/F5, No Clamp)
• UVF Mount (LCD, No Clamp)

1/4-20 Hot Shoe
Replicates the flash shoe found on still cameras. Attaches to any 1/4-20 threaded hole. Great for mounting on-camera lights, microphone shock mounts, flashes and more.
