WD VelociRaptor WD5000HHTZ 500GB Workstation Hard Drive
See all WD items

WD VelociRaptor WD5000HHTZ 500GB 3.5" Workstation Hard Drive, 10,000 RPM, SATA 6 Gb/s

SKU: WD5000HHTZ
(1)

This item is no longer available.

Recommended Alternatives

WD : Picture 1 regular
WD Gold Enterprise Class 3.5" SATA III Internal Hard Drive
$169.99
WD Blue: Picture 1 regular
WD Blue 3.5" SATA III Internal Desktop Hard Drive
$79.99
WD Red Plus: Picture 1 regular
WD Red Plus 3.5" SATA III Internal NAS Hard Drive
$84.99
WD Red Pro NAS HDD: Picture 1 regular
WD Red Pro 3.5" SATA III Internal NAS Hard Drive
$149.99
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

2013-10-23T21:00:00

Rated 5 out of 5

Screaming fast and lots of space!

Love this super fast hard drive. It's a nice complement to the PCIe solid state drive and another SSD drive in my MacPro.

Mike

WD WD5000HHTZ Specifications

  • Interface

    SATA 6 Gb/s

  • Formatted capacity

    500GB

  • User sectors per drive

    976,773,168

  • Advanced Format (AF)

    Yes

  • SATA latching connector

    Yes

  • Form factor

    3.5-inch

  • RoHS compliant

    Yes

  • Data transfer rate (max) Buffer to host

    6 Gb/s

  • Host to/from drive (sustained)

    200 MB/s

  • Cache (MB)

    64

  • Rotational speed (RPM)

    10,000

  • Average drive ready time (sec)

    8

  • Load/unload cycles

    600,000

  • Non-recoverable read errors per bits

    <10 in 1016 (per bits read)

  • Power Management 12VDC (A, max)

    1.8

  • Av Power Reqs: Random Read/Write

    5.1

  • Av Power Reqs: Sequential Read/Write

    5.8

  • Av Power Reqs: Idle

    4.2

  • Av Power Reqs: Standby and Sleep

    1.1

  • Temperature (deg.C) Operating

    5 to 55

  • Temperature (deg.C) Non-operating

    -40 to 70

  • Shock (Gs) Operating (2 ms, read/write)

    30

  • Shock (Gs) Operating (2 ms, read)

    65

  • Shock (Gs) Non-operating (2 ms)

    300

  • Average acoustics (dBA) Idle mode

    30

  • Performance seek mode

    37

  • Dimensions (H x L x W)

    1.028" x 5.79" x 4" / 26.11 x 147.07 x 101.6 mm

  • Weight

    1.10 lbs / 0.50 kg

  • UPC Code

    718037788074

About WD WD5000HHTZ

FEATURED REVIEWS

Screaming fast and lots of space!

By Mike

Love this super fast hard drive. It's a nice complement to the PCIe solid state drive and another SSD drive in my MacPro.

The WD WD5000HHTZ 500 GB VelociRaptor Workstation Hard Drive drives offer an unmatched combination of high performance and high reliability, perfect for workstations, high-end video and photo editing, low-end servers and performance enthusiasts' systems. It comes with a 3.5" mounting frame for easy installation into today's high-performance systems and chassis.

WD WD5000HHTZ Features

  • Ultra fast: Designed around a 10,000 RPM spin speed, these SATA 6 Gb/s drives include a 64 MB cache and deliver the ultimate performance for photo and video editing
  • Rock-solid reliability: With 1.4 million hours MTBF, this drive have the highest available reliability rating on a high capacity SATA drive
  • High capacity: State-of-the-art technology delivers a balance of high performance and high capacity perfect for data-intensive workloads that require large amounts of storage such as video editing, 3D rendering and scientific modeling
  • Ultra-cool operation: Consumes less idle power and uses similar active power as the previous generation WD VelociRaptor, while offering double the capacity and higher performance
  • Advanced Format (AF): Technology adopted by WD and other drive manufacturers as one of multiple ways to continue growing hard drive capacities. AF is a more efficient media format that enables increased areal densities
  • IcePack mounting frame: The 2.5-inch WD VelociRaptor is enclosed in a backplane-ready 3.5-inch enterprise-class mounting frame with a built-in heat sink that keeps this powerful little drive extra cool when installed in high-performance desktop chassis
  • Rotary Acceleration Feed Forward (RAFF): Optimizes operation and performance when the drives are used in vibration prone, multi-drive chassis
  • NoTouch ramp load technology: The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit
  • Environmentally conscious: In addition to being ROHS compliant, this generation of WD VelociRaptor is also a halogen free design
  • Pre-emptive Wear Leveling (PWL): Ensures reliability for applications that perform a high incidence of read/write operations at the same physical location on the disk
