WD 750GB SATA 2.5" Internal Hard Drive, SATA 3 Gb/s, 16MB Cache

SKU: WD7500BPKT

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

2014-02-10T19:00:00

Rated 5 out of 5

Great product, flawless HDD upgrade

well built SFF HDD with a 5 yr (rated for 1.2x10^6 hr MTBF!) warranty. clone software to allow Notebook upgrade worked perfectly. 240GB of data on a 250GB HDD was cloned in ~2.2 hrs. it doesn't get any easier, & surely the new drive will last a long time. Keep it up, WD !

Engineer D.

WD 750GB SATA 2.5" Internal Hard Drive Specifications

  • Interface

    SATA 3 Gb/s

  • Formatted capacity

    750,156 MB

  • User sectors per drive

    1,465,149,168

  • Form factor

    2.5-inch

  • Advanced Format (AF)

    Yes

  • RoHS compliant

    Yes

  • Data transfer rate (max)

    Buffer to host: 3 Gb/s
    Host to/from drive (sustained): 160 MB/s

  • Cache

    16 MB

  • Average latency (ms)

    4.2

  • Rotational speed

    7200 RPM

  • Average drive ready time

    4 sec

  • Load/unload cycles

    600000

  • Non-recoverable read errors /bits read

    <1 in 1014

  • 5VDC +/-10% (A, peak)

    1.15

  • Average power requirements (W)

    Read/Write: 1.75
    Idle: 0.8
    Standby: 0.2
    Sleep: 0.2

  • Operating Temperature

    0deg.C to 60deg.C

  • Non-operating Temperature

    -40deg.C to 70deg.C

  • Operating Shock (2 ms)

    350 Gs

  • Non-operating Shock (2 ms)

    1000 Gs

  • Acoustics (dBA)

    Idle: 28
    Seek (average): 28

  • Dimensions (H x L x W)

    0.374 x 3.94 x 2.75" / 9.50 x 100.20 x 69.85 mm

  • Weight

    0.25 lb / 0.115 kg

  • UPC Code

    718037771151

About WD 750GB SATA 2.5" Internal Hard Drive

FEATURED REVIEWS

Great product, flawless HDD upgrade

By Engineer D.

well built SFF HDD with a 5 yr (rated for 1.2x10^6 hr MTBF!) warranty. clone software to allow Notebook upgrade worked perfectly. 240GB of data on a 250GB HDD was cloned in ~2.2 hrs. it doesn't get any easier, & surely the new drive will last a long time. Keep it up, WD !

WD 750GB SATA 2.5" Internal Hard Drive is designed with top-of-the-line notebook computers in mind, this high performance drive delivers the capacity and speed needed to supercharge a notebook PC without compromising battery life or quiet acoustics. Features like this also make this drive an outstanding option for compact desktops, external hard drives and gaming systems.

WD 750GB SATA 2.5" Internal Hard Drive Features

  • Desktop-class performance for notebook computers: With 7200 RPM spin speed,16 MB cache and capacities up to 750 GB, these drives enable you to have the best of both worlds: the capacity and performance of a desktop PC with the convenience and portability of a notebook
  • Massive capacity: WD's 750 GB 2.5-inch drives offer huge capacity for space-hungry operating systems with plenty of room left over for photos, music and video
  • Tested for compatibility: WD perform tests on hundreds of systems and a multitude of platforms in the FIT Lab and Mobile Compatibility Lab to give WD customers confidence that the drives will work in their systems
  • Reliable and rugged: WD's ShockGuard technology protects the drive mechanics and platter surfaces from shocks during shipping and handling and in daily operation. WD's SecurePark parks the recording heads off the disk surface during spin up, spin down and when the drive is off
  • Low power consumption: With technologies like IntelliSeek, which calculates optimum seek speeds to lower power consumption and SecurePark, which reduces power by parking the heads during low power idle mode, this drive delivers 5400 RPM-equivalent power consumption in a 7200 RPM drive
  • Advanced Format (AF): Technology being adopted by WD and other drive manufacturers as one of multiple ways to continue growing hard drive capacities. AF is a more efficient media format that enables increased areal densities
