What is the purpose of Western Digital's AllFrame technology in the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD?

Western Digital's AllFrame technology enhances video capturing and reduces errors, pixelation, and video interruptions that could occur in a video recorder system. It also improves ATA streaming, reduces frame loss, and enhances overall video playback.

How many cameras can the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD support?

The WD Purple 8TB SATA III 3.5' Internal Surveillance HDD is designed to support systems designed for 24x7 video recording with up to 64 cameras.

What is the workload rating of the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD?

The WD Purple 8TB SATA III 3.5' Internal Surveillance HDD features an enhanced workload rating that can handle the unique demands of modern video surveillance DVR and NVR systems.

What is IntelliSeek technology in the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD?

IntelliSeek technology in the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD calculates optimum seek speeds, keeping power consumption low and reducing ambient noise and vibrations.

Can the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD be integrated into any surveillance system?

Yes, the WD Purple 8TB SATA III 3.5' Internal Surveillance HDD is built with compatibility in mind, allowing for quick and seamless integration into your surveillance system with a wide range of industry-leading enclosures and chipsets supported.

Reviews about this item

Review Summary

2025-04-08T20:00:00

Rated 5 out of 5

Easy to install

Perfect addition to my system, it has doubled the recording capacity, it was very easy to install and it self installs the software.

jose l.

2025-03-10T20:00:00

Rated 5 out of 5

I definitely recommend upgrading your storage capacity.

Great option to add additional storage to your overall system.

B2C C.

2024-12-14T19:00:00

Rated 1 out of 5

This product does not work

This product does not work with the system I purchased , even thou Lorex sale person recommend it?. I had to return it, seems to me that lorex sales personal need to be more educated on their systems!!

Ignacio D.

2024-11-23T19:00:00

Rated 5 out of 5

It's just what I needed.

It's just what I needed.

Justin P.

2024-06-18T20:00:00

Rated 5 out of 5

Works

Hard drive works like it's supposed to. Easy fix besides replacing the whole DVR

Richard B.

2024-06-12T20:00:00

Rated 5 out of 5

Plug and Play, easy installation!

Watched a YT video that gave me step by step instructions. Very easy. Works as expected.

Mark C.

2024-03-04T19:00:00

Rated 5 out of 5

Hard drive

Installed easy.Fired right up and still running fine.

Tim H.

2024-02-27T19:00:00

Rated 5 out of 5

Hard drive

It's working perfectly. The hard drive is saving over two weeks of recordings.

TERRANCE W.

2024-02-21T19:00:00

Rated 5 out of 5

Hours and hours of storage

Hours and hours of storage space

Francis S.

2023-11-09T19:00:00

Rated 5 out of 5

Hard drive Upgrade

Replacing the hard drive was relatively easy. The extra capacity is well needed to extend the recording time.

Wally G.

2023-10-15T20:00:00

Rated 4 out of 5

Works good will consider additional

Works good will consider additional purchases.

brice t.

2023-09-25T20:00:00

Rated 5 out of 5

Professional installed 4 weeks ago

Professional installed 4 weeks ago and working as designed.

Mark J.

2023-08-02T20:00:00

Rated 5 out of 5

Upgraded from 2TB drive to 4TB

Installation was easy and the drive started working as soon as I powered up the NVR. It's been a few weeks and everything is working perfectly. Now I get seven days of 24-7 high-definition recording on six 4K cameras.

Jeffrey Y.

2023-06-13T20:00:00

Rated 5 out of 5

Installer

Great quality hard drive at a good price

Installer B.

2023-06-09T20:00:00

Rated 5 out of 5

Excelente

Excelente

fernando m.

2023-04-05T20:00:00

Rated 5 out of 5

easy to install

Easy to install and adds a lot of storage space

Bunker Y.

2023-03-28T20:00:00

Rated 5 out of 5

Thank you

Thank you

rick s.

2023-03-27T20:00:00

Rated 4 out of 5

Hard drive.

Works great.

m h.

2023-03-26T20:00:00

Rated 5 out of 5

Very happy

100% happy!!

William A.

2023-01-07T19:00:00

Rated 5 out of 5

William G

Very easy to install

william g.

2022-10-31T20:00:00

Rated 2 out of 5

lll

take too long to ship out;;take too long to ship out

llllll

2022-08-30T20:00:00

Rated 4 out of 5

Extra

Very easy too install

Rob M.

2022-08-23T20:00:00

Rated 4 out of 5

added memory

I am satisfied with this add on memory

Gary B.

2022-08-17T20:00:00

Rated 3 out of 5

Ok

Ok

Dave G.

2022-05-09T20:00:00

Rated 5 out of 5

Great system. Still learning how

Great system. Still learning how to use everything

Kenny T.

2022-05-04T20:00:00

Rated 5 out of 5

Great products!

Great products!

Todd M.

2022-04-28T20:00:00

Rated 5 out of 5

Nice pictures!

Nice pictures!

daniel s.

2022-04-27T20:00:00

Rated 5 out of 5

holds over a months worth

holds over a months worth of video in our warehouse

Albert C.

2022-04-27T20:00:00

Rated 5 out of 5

Awesome just what I needed

Awesome just what I needed

Anthony C.

2022-04-23T20:00:00

Rated 5 out of 5

Hard Drive Upgrade

Easy install and working great extending full video HD recording

Henry B.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

WD Purple Specifications

Storage

Storage

Jump to...
  • Capacity

    8 TB

  • Buffer

    256 MB

Performance

Jump to...
  • Write Speed

    Sequential: 213 MB/s

  • Read Speed

    Sequential: 213 MB/s

Physical

Jump to...
  • Drive Type

    HDD

  • Form Factor

    3.5"

  • Noise Level

    29.0 dB (Active)
    27.0 dB (Idle)

HDD Specs

Jump to...
  • Spindle Speed (RPM)

    5400 rpm

Reliability

Jump to...
  • Endurance (Total Bytes Written)

    360 TB

  • Load/Unload Cycles

    300000

  • Mean Time Between Failures (MTBF)

    1.5 Million Hours

  • Non-Recoverable Read Errors

    Per Bits Read: < 1 in 1015

Electrical

Jump to...
  • Power Draw

    8.6 W (Active)
    7.4 W (Idle)
    0.4 W (Standby)

Environmental

Jump to...
  • Operating Shock

    30 G / 2.0 ms

  • Storage Shock

    250 G / 2.0 ms

  • Operating Temperature

    32 to 149 Degree F (0 to 65 Degree C)

  • Storage Temperature

    -40 to 158 Degree F (-40 to 70 Degree C)

General

Jump to...
  • Certifications

    RoHS, as per Manufacturer

  • Dimensions (H x L x W)

    1.06 x 5.79 x 4.02" (27 x 147 x 102mm)

  • Weight

    1.59 lbs (721.2g) ( +/- 10%)

  • UPC Code

    718037887906

About WD Purple

FEATURED REVIEWS

holds over a months worth

By Albert C.

holds over a months worth of video in our warehouse

Easy to install

By jose l.

Perfect addition to my system, it has doubled the recording capacity, it was very easy to install and it self installs the software.

With the Purple 8TB SATA III 3.5" Internal Surveillance HDD, 5400 RPM, Western Digital offers a reliable, durable, and high-performance storage solution for your surveillance needs. This spacious and affordable hard drive is engineered for 24/7, always-on, high-definition security systems, making it a trusted choice for businesses and individuals alike.

The WD Purple drives are equipped with Western Digital's exclusive AllFrame technology, enhancing video capturing and reducing errors, pixelation, and video interruptions that could occur in a video recorder system. This technology ensures smooth, high-quality video playback, making it a vital component of any security system.

With an impressive storage capacity of 8TB, this hard drive can accommodate a significant amount of data. It supports systems designed for 24x7 video recording with up to 64 cameras, making it a versatile solution for both small and large-scale surveillance setups.

The WD Purple drives are designed to withstand high temperatures and constant operation, ensuring reliable video playback when you need it most. Whether you're safeguarding your loved ones or monitoring your business, the WD Purple drives offer performance you can trust.

The AllFrame technology also improves ATA streaming, reducing frame loss and enhancing overall video playback. It also increases the number of hard drive bays supported within a Network Video Recorder (NVR), making your surveillance solution future-ready.

The WD Purple 8TB drive features AllFrame AI technology, enabling recording from up to 64 cameras and supporting an additional 32 streams for Deep Learning analytics within the system. This enhanced workload rating allows the drive to handle the unique demands of modern video surveillance DVR and NVR systems.

Each WD Purple drive is optimized to support up to 64 cameras, providing flexibility to upgrade or expand your security system in the future. With an MTBF of up to 1.5 million hours, these drives are engineered for mainstream surveillance DVRs and NVRs that operate 24/7.

The WD Purple drives are built with compatibility in mind, allowing for quick and seamless integration into your surveillance system. With a wide range of industry-leading enclosures and chipsets supported, you can find the DVR or NVR configuration that's right for you.

With Western Digital's exclusive IntelliSeek technology, the WD Purple drives calculate optimum seek speeds, keeping power consumption low and reducing ambient noise and vibrations. This high-efficiency, low-power solution ensures a quiet and energy-efficient operation.

Western Digital puts their products through extensive Functional Integrity Testing (F.I.T.) prior to any product launch, ensuring the highest quality and reliability standards. With a detailed Knowledge Base and customer support lines, you can trust in the Western Digital advantage for your surveillance storage needs.

WD Purple Features

  • 8TB Storage Capacity
  • Support for up to 64 cameras per drive
  • AllFrame Technology
  • Up to 16 AI channels for Deep Learning analytics on AI-enabled NVRs
  • MTBF of up to 1.5 million hours

Key Features

  • High-capacity 8TB surveillance hard drive for 24/7, always-on, high-definition security systems
  • Supports systems designed for 24x7 video recording with up to 64 cameras
  • Built with compatibility in mind for seamless integration into various surveillance systems

What's in the box:

  • WD Purple 8TB SATA III 3.5" Internal Surveillance HDD
  • WD 3 Year Limited Warranty
