Wharfedale Diamond 12.C Dual 5" 2-Way Center Channel Speaker, White, Single

SKU: WFD12CWHT

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?CHARLIE P : Needed a matching cente and this fit the bill perfectly.

Reviews about this item

Review Summary

2021-03-23T08:25:53

Rated 5 out of 5

Great compliment to the 12.2 bookshelf speakers

Great compliment to the 12.2s. The overall combination is very true for sound and movies. Glad I added the center.

Sean B.

2021-02-17T04:47:17

Rated 4 out of 5

Almost as good as it looks

I had high hopes for this center to match the 12.1 series. However, they have quite a different sound to them. My guess is because it is a sealed design, instead of ported. Visually it matches perfect, and I plan to keep it, but I can't help but wish it sounded the same as the 12.1s.

Charlie P.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Wharfedale Diamond 12.C Specifications

  • Color/Finish

    White

  • Speaker Type

    2-way Center Channel Speaker

  • Enclosure type

    Closed box system

  • Transduce complement

    2-way

  • Bass Driver

    5" (130mm) Advanced PP cone

  • Treble Drive

    1" (25mm) Textile Dome

  • AV shield

    No

  • Sensitivity (2.83V @ 1m)

    90dB

  • Recommended amp power

    20-120W

  • Peak SPL

    96dB

  • Nominal impedance

    8 Ohm compatible

  • Minimum Impedance

    4 Ohm

  • Frequency Response (+/-3dB)

    90Hz-20kHz

  • Bass Extension (-6dB)

    80Hz

  • Crossover Frequency

    2.2kHz

  • Cabinet Volume

    8.7L

  • Dimensions (H x W x D)

    7.08 x 18.8 x 8.18" (180 x 480 x 208mm)

  • Weight

    18.73 lbs (8.5kg) (Each)

  • UPC Code

    840117503977

About Wharfedale Diamond 12.C

FEATURED REVIEWS

Great compliment to the 12.2 bookshelf speakers

By Sean B.

Great compliment to the 12.2s. The overall combination is very true for sound and movies. Glad I added the center.

When Wharfedale pioneered the blueprint for modern 'budget' hi-fi speakers in the early 1980s with the first-ever DIAMOND, it set a new standard in the audio industry. Today, the Wharfedale DIAMOND 12.C Dual 5" 2-Way Center Channel Speaker continues this legacy of innovation and excellence. This speaker, part of the most successful and enduring DIAMOND line, is a testament to Wharfedale's commitment to delivering high-quality audio equipment that offers exceptional value for money.

The DIAMOND 12.C speaker is the result of a collaboration with renowned loudspeaker designer Karl-Heinz Fink. It boasts a sleek, modern design that is distinctly Wharfedale, and its sound quality sets a new benchmark in the 'budget' category, thanks to its advanced acoustic design and engineering.

Key features of the DIAMOND 12.C speaker include the NEW Klarity cone material, a blend of Polypropylene and mica that adds stiffness to reduce flexing. This results in a lightweight cone with high rigidity, low coloration, and a lightning-fast response. The Klarity cone is fitted with a low-damping surround, achieving both low coloration and expressive dynamics.

The speaker also features a precision-made magnet system with an aluminum compensation ring to minimize the effect of variations in inductance as the voice coil travels. This contributes to an absence of distortion and intermodulation generated by the 'motor system'. The voice coil itself is wound on a high-power epoxy/glass fiber bobbin, a feature rarely seen in speakers at this price level.

The DIAMOND 12.C speaker is equipped with a 25mm dome made from a woven polyester film with a high-loss coating, delivering open and smoothly extended high frequencies. The crossover network uses an acoustic LKR 24dB topology, including air core inductors typically found in high-end speakers, resulting in fast, clean bass with no distortion from the inductor.

Inside the cabinet, Intelligent Spot Bracing connects opposite walls with a specific form of wood brace to achieve optimal reduction of cabinet resonance. This speaker is available in a choice of black, white, light oak, or walnut, ensuring it will complement any home theater system.

In conclusion, the Wharfedale DIAMOND 12.C Dual 5" 2-Way Center Channel Speaker is a testament to Wharfedale's commitment to innovation, quality, and value, offering an exceptional audio experience for any home theater enthusiast.

Wharfedale Diamond 12.C Features

  • Klarity affords focus - NEW Klarity cone material
  • A Magnet of forces - A precision-made magnet system with an aluminum compensation ring
  • A voice coil beyond this class - The voice coil is wound on a high-power epoxy/glass fiber bobbin
  • DIAMOND Highs - The 25mm dome is made from a woven polyester film with a high-loss coating
  • A crossover of style - The crossover network uses an acoustic LKR 24dB topology
  • Intelligent Spot Bracing connects opposite walls with a specific form of wood brace
  • Always on trend - Finished in White

Key Features

  • Features NEW Klarity cone material for high rigidity, low coloration, and lightning-fast response
  • Precision-made magnet system with aluminum compensation ring for minimal distortion
  • High-power epoxy/glass fiber bobbin for greater power handling and rigidity
  • Equipped with a 25mm dome for open and smoothly extended high frequencies
  • Intelligent Spot Bracing inside the cabinet for optimal reduction of cabinet resonance
  • Available in a choice of black, white, light oak, or walnut to match any home theater system

What's in the box:

  • Diamond 12.C Dual 5" 2-Way Center Channel Speaker (White)
  • Wharfedale 5 Year Limited Warranty
