Williams Sound PLA 240 Small Room Loop Amplifier, Silver
See all Williams Sound items

Williams Sound PLA 240 Small Room Loop Amplifier, Silver

SKU: WSPLA240
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Williams Sound PLA 240 Specifications

  • Power

    Unit Input: 12-24VDC, 2A
    Power Supply Output: 18V, 1.5A

  • Controls

    Rotary Volume Control
    Rotary Tone Control
    On/Off Power Switch
    Source Selector Switches
    Priority Switch

  • Input Connections

    Digital Audio TOSlink/Coaxial
    2x Microphone inputs. 3.5 mm mono jack plug. DC powered 5 V for Electret Microphones
    2x Aux In Left/Right Line Inputs. Phono/RCA jacks. For direct connection to a TV sound output or other sound source via SCART or other suitable jack

  • Output Connections

    Push grip connectors for loop cable (labelled: "loop cable"). Loop will give full output with loop resistance between 0.5 and 1.5Ohms

  • Loop output

    3.0A output current at 100Hz - 5KHz. Meets BS EN60118-4: 2006 for a loop not exceeding 6.5 m (20 ft) in width. Suitable for areas up to 540 sq. ft (50 m2)

  • Loop cable

    Single turn loop cable. System supplied with 40m (131.23') of 24 ga/0.2 mm (0.75 mm2) single core PVC insulated cable. Min cable length 36' (10.97m) = 0.5Ohms

  • Indicators

    Blue/Red LEDs

  • Dimensions (WxHxD)

    Height without rubber feet: 17.8 x 2.86 x 15.24cm (7.01 x 1.13 x 6.00")
    With rubber feet: 17.8 x 0.32 x 15.24cm (7.01 x 0.13 x 6.00") (Depth includes front controls and rear jacks)

  • Weight

    1.6 lbs (0.73kg)

  • UPC Code

    952913309070

About Williams Sound PLA 240

The PLA 240 is able to supply living quarters or small conference rooms up to approx. 540 sq. ft. (50 sq.m) with inductive audio signals via the loop connected. The system includes 120' (37 m) induction loop wire. In addition to settings for basic volume and tone, the digitally controlled induction loop amplifier uses Automatic Gain Control to stabilize the volume for fluctuating input levels. The device is able to accommodate the connection of up to 5 audio sources. The desired source can be selected at the touch of a button. An included remote control provides power, volume, tone and input selection.

Williams Sound PLA 240 Features

  • Magnetic signal couples directly to hearing aids equipped with telecoils (T-Coils)
  • Headphone output for monitoring audio output
  • Can be used with optional loop receivers
  • Mic, line and digital inputs
  • Automatic gain control
  • Volume and tone controls
  • Loop status light
  • Compact and lightweight
  • Remote Control with battery

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Williams Sound PLA 240 Small Room Loop Amplifier
  • Power Supply with Line Cord
  • Mic with 14' (4.27m) Cable
  • 122' (37.19m) of 18ga Standard Wire (0.75mm2) and Cable Clips
  • RCA Audio Input Cable
  • Remote Control with Battery
  • Williams Sound 2 Year Warranty
