Whirlwind ES4 2-RU Digital Snake Receiver for Madi, 16 Line Outputs, 8 Line Inputs, DB25 Connectors, 20Hz-20kHz Frequency Response, 200 Ohms Output Impedance

SKU: WWES4RM MFR: ES4RM
Earn VIP Reward Points

Key Features

  • Experience pristine audio fidelity with this digital snake receiver's wide 20Hz-20kHz frequency response.
  • Achieve superior sound clarity with a THD+N of <0.0024%, ensuring minimal distortion in your audio.
  • Enjoy balanced input with a 20 kOhms impedance, perfect for professional audio setups and stage boxes.
  • Easily monitor signal levels with precise LED indicators for optimal audio performance during any event.
  • Ensure reliable power with a wide 100-240 VAC compatibility, ideal for global audio applications.
  • This durable Whirlwind digital snake offers MADI connectivity for seamless integration in complex systems.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$179.99

3 Year

$249.99

5 Year

$489.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Whirlwind ES4 Specifications

  • Frequency Response

    Input (Line/Mic): +/-0.5 dBV 20 Hz to 20 kHz
    Control in detent position
    Output: +/-0.1 dBV 20 Hz to 20 kHz

  • THD + N

    Input Line Mode: <0.0012% 20 Hz to 20 kHz
    Output: <0.0024% 20 Hz to 20 kHz

  • Total Gain

    20 dBV

  • Range of Level Pot

    -20 to 20 dBV

  • Common Mode Rejection

    >60 dB

  • Maximum Input Level

    19 dBV

  • Input Impedance

    20 kOhms balanced

  • Noise at unity gain

    Line: -105 dBfs (potentiometer at center):

  • Noise Output

    -95 dBV

  • Isolation

    Between Input Channels: 122 dB
    Between Output Channels: 124 dB

  • Digital Conversion

    24 bit / 48 kHz

  • Maximum Output Level

    12 dBV balanced

  • Output Impedance

    200 Ohms balanced

  • LED Thresholds

    Red LED: -2 dBfs, +/- 1 dBfs, Green LED: -30 dBfs, +/- 3 dBfs

  • Power Consumption

    0.47 A at 120 VAC maximum
    0.26 A at 120 VAC minimum

  • Power Requirement

    100 to 240 VAC 50/60 Hz

  • Internal Mains Fuse

    2 A slow blow type 3AG

  • AC Dropout Voltage

    90V AC

  • Dimensions (H x W x D)

    3.5 x 19 x 12.5" / 88.9 x 482.6 x 317.5mm

  • Weight

    9.5lbs / 4.31kg

  • UPC Code

    69246502288

About Whirlwind ES4

When seeking a robust and high-quality solution for your audio networking needs, consider the Whirlwind ES4 2-RU Digital Snake Receiver for Madi. This advanced receiver boasts 16 line level outputs and 8 line level inputs, providing ample connectivity for professional audio setups.

Designed and manufactured in the USA, this reliable receiver offers 16 channels of superior microphone preamplification, coupled with 8 line level return channels. These features are available through a selection of digital transport formats, with the ES4R receiver specifically configured for the Cobranet format.

The ES4 2-RU Digital Snake Receiver is not just about power and performance, but also about user-friendly operation. All inputs come with variable gain controls and LED level monitoring, ensuring ease of use and precise control over your audio signals.

With a wide frequency response range of 20Hz-20kHz, this receiver can handle a broad spectrum of audio signals, making it an ideal choice for professional audio applications. Additionally, its high output impedance of 200 Ohms ensures that it can drive long cable runs without any signal loss, ensuring consistent audio quality across all channels.

The unit also features durable DB25 connectors, further enhancing its reliability and longevity. Whether you're setting up a recording studio, a live performance venue, or a broadcast station, the Whirlwind ES4 2-RU Digital Snake Receiver for Madi is a versatile and dependable choice that delivers exceptional audio performance.

Whirlwind ES4 Features

  • Advanced Whirlwind ES4 2-RU Digital Snake Receiver for professional audio setups
  • Offers 16 line level outputs and 8 line level inputs for comprehensive connectivity
  • Features superior microphone preamplification and return channels via digital transport formats
  • Wide frequency response range of 20Hz-20kHz for handling a broad spectrum of audio signals
  • High output impedance of 200 Ohms for long cable runs without signal loss
  • Durable DB25 connectors and LED level monitoring for ease of use and reliability

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience pristine audio fidelity with this digital snake receiver's wide 20Hz-20kHz frequency response.
  • Achieve superior sound clarity with a THD+N of <0.0024%, ensuring minimal distortion in your audio.
  • Enjoy balanced input with a 20 kOhms impedance, perfect for professional audio setups and stage boxes.
  • Easily monitor signal levels with precise LED indicators for optimal audio performance during any event.
  • Ensure reliable power with a wide 100-240 VAC compatibility, ideal for global audio applications.
  • This durable Whirlwind digital snake offers MADI connectivity for seamless integration in complex systems.

What's in the box:

  • Whirlwind ES4 Digital Snake Receiver for Madi
  • Whirlwind 5 Year Limited Warranty
